HPE Aruba Networking JL675A CX6100 48G Class4 PoE+ Switch
- Managed, Rack-mountable, 48 x 1G PoE+ ports, 4 x 1G/10G SFP+ Uplinks, PoE+ (370W), Layer 2 with Static Routing
[properties]
| Properties | HPE Aruba Networking CX 6100 48G Class4 PoE 4SFP+ 370W Switch (JL675A) |
| Description | Entry-level access switch with 48 Gigabit PoE+ ports, 4 x 10GbE SFP+ uplinks, supporting static routing for secure branch and SMB networks. |
| Product Family | CX 6100 Switch Series |
| Product Type | Ethernet Switch |
| Ports and Slots | 48x 10/100/1000BASE-T Class 4 PoE Ports 4x 1G/10G SFP+ ports 1x USB-C Console Port 1x USB Type-A Host port |
| Power Supply | Fixed internal power supply |
| Fans | Fixed internal fans |
| Input Voltage | 100-127 VAC / 200-240 VAC |
| Power Consumption | Max Power (without PoE): 45W Max Power (with PoE): 480W |
| PoE Capability | 370W Class 4 PoE/PoE+ |
| Dimensions | 1.73(h) x 17.4(w) x 12.0(d) in (4.4 x 44.2 x 30.5 cm) |
| Weight | 5.0 kg (11.07 lbs) |
[/properties][specifications]
| Specifications | CX6100-JL675A |
| CPU | Dual Core ARM Cortex A9 @ 1016 Mhz |
| Memory and Flash | 4 GB DDR3 16 GB eMMC |
| Performance | |
| Switching Capacity | 176 Gbps |
| Throughput | 98.6 Mpps |
| Latency | 1 Gbps: 1.9 µs 10 Gbps: 1.8 µs |
[/specifications]
HPE Aruba Networking CX 6100 48G Class4 PoE 4SFP+ 370W Switch (JL675A)
The HPE Aruba CX 6100 48G PoE+ 4SFP+ Switch (JL675A) is a modern access switch designed for branch offices, SMBs, and mid-market enterprises. With 48 Gigabit PoE+ ports delivering up to 370W Class 4 PoE power and 4 high-speed 10GbE SFP+ uplinks, it ensures reliable connectivity for IP phones, access points, and security cameras.
Built on the Aruba CX architecture, this Layer 2 switch includes static routing, robust QoS, ACLs, and IPv6 support, simplifying traffic management while maintaining enterprise-grade security. With Aruba Central cloud management, intuitive Web GUI, and industry-standard CLI, it offers flexible deployment and simplified operations.
Key Features:
- 48 x Gigabit PoE+ Ports: Provides up to 370W of Class 4 PoE for powering access points, IP phones, and IoT devices.
- 4 x 10GbE SFP+ Uplink Ports: Offers high-speed fiber uplinks to eliminate bottlenecks at the access layer.
- Layer 2 with Static Routing: Delivers enterprise-class Layer 2 capabilities with support for static routing, ACLs, robust QoS, and IPv6.
- Simplified Management: Provides flexibility to manage with HPE Aruba Networking Central, an easy-to-use Web GUI, or industry-standard CLI.
- License-Free: Simplifies ownership with no switch software licensing or subscriptions required.
Technical Overview:
- Recommended for: Branch offices, mid-market enterprise, and SMB networks.
- Ports: 48 x 10/100/1000 Mbps Class 4 PoE ports.
- Uplinks: 4 x 1G/10G SFP+ ports.
- PoE Power Budget: 370W.
- Switching Capacity: 176 Gbps.
- Forwarding Rate: 98.6 Mpps.
