APC SRT3000RMXLA-NC - Smart-UPS On-Line 3kVA 2U Rackmount
[shortdesc] 3000VA / 2700W, Double-Conversion Online, 2U Rackmount, Sine Wave Output, 8x NEMA 5-20R + 1x NEMA L5-30R, Network Management Card [/shortdesc]
[properties]
| Brand | APC by Schneider Electric |
| Model | SRT3000RMXLA-NC |
| Product Type | Smart-UPS On-Line, Double Conversion |
| Form Factor | Rackmount 2U |
| Dimensions (H x W x D) | 3.3" x 17.0" x 25.0" (85 x 432 x 635 mm) |
| Weight | 69 lb (31.3 kg) |
| Color | Black |
| Number of Rack Units | 2U |
| Cable Length | 8 ft (2.4 m) |
| Cooling | Not specified |
[specifications]
| Capacity | 3000 VA / 2700 W |
| Input Voltage | 120 V |
| Input Connection Type | NEMA L5-30P |
| Input Frequency | 40–70 Hz auto-sensing |
| Output Voltage | 120 V |
| Output Connections | 8 × NEMA 5-20R, 1 × NEMA L5-30R |
| Waveform Type | Sine wave |
| Topology | Double Conversion On-Line |
| Transfer Time | 0 ms (on-line) |
| Bypass Type | Internal (Automatic and Manual) |
| Crest Factor | 3:1 |
| Harmonic Distortion | <2% |
| Battery Type | Lead-Acid • Voltage: 96 V • Recharge time: 3 h • Life: 3–5 years • RBC Qty: 1 • Replacement: APCRBC152 • Charge power: 151 W rated |
| Extendable Runtime | Yes |
| Surge Energy Rating | 340 J |
| Acoustic Noise | 55 dBA |
| Thermal Dissipation | 805 BTU/h |
| Operating Temperature | 0–40 °C (32–104 °F) |
| Operating Humidity | 0–95% non-condensing |
| Altitude | 0–10,000 ft operating |
| Communications | USB, EPO, Audible/visible alarms, Pre-installed Network Management Card 3 with environmental monitoring |
| Certifications | ENERGY STAR V2.0 (USA) |
| Warranty | 3 years repair or replace (UPS), 2 years (battery) |
[accesories]
| Warranty Card | Included in the box |
| Rack Mounting Brackets | Included in the box |
| Rack Mounting Support Rails | Included in the box |
| USB Cable | Included in the box |
| Documentation | CD with software, Documentation CD, Installation guide |
| Network Management Card | Pre-installed in the unit |
Overview
The APC SRT3000RMXLA-NC is a high-density, double-conversion online UPS engineered for enterprise-grade reliability. Offering 3kVA/2700W of clean sine wave power, it protects servers, networking gear, and storage systems against outages and fluctuations. With scalable runtime, a 2U rackmount design, and a pre-installed Network Management Card, it ensures efficient power continuity with advanced remote monitoring.
Key Features & Benefits
- 3kVA / 2700W Capacity: Supports critical loads with continuous online protection.
- Double-Conversion Design: Ensures pure sine wave power independent of input fluctuations.
- 2U Rackmount Form Factor: Compact, high-density installation for enterprise racks.
- Versatile Outlet Set: 8× NEMA 5-20R + 1× NEMA L5-30R for mixed IT hardware.
- Status/Control Interface: Front-panel status and controls for quick system visibility.
- Pre-installed Network Card: NMC 3 with environmental monitoring provides remote management.
Technical Deep Dive
True Online Topology: The SRT3000RMXLA-NC uses double-conversion architecture, converting incoming AC to DC and back to AC, ensuring stable sine wave output regardless of input anomalies.
Power Quality & Performance: With less than 2% total harmonic distortion and a crest factor of 3:1, the UPS supports modern PFC power supplies while maintaining power integrity. Internal bypass (automatic and manual) enhances availability during maintenance or overload scenarios.
Runtime & Recharge: Equipped with a 96V lead-acid battery, it offers scalable runtime via external modules and recharges in approximately three hours.
Ideal Applications
- Enterprise data center servers and storage
- Core networking and telecom systems
- Healthcare and critical infrastructure environments
- Financial systems and branch office deployments
Frequently Asked Questions (FAQs)
Q1: How is the SRT3000RMXLA-NC installed?
A: It is a 2U rackmount UPS shipped with support rails and a front status/control interface for simplified deployment.
Q2: What performance should I expect?
A: Rated at 3000VA/2700W with sine wave output. Runtime depends on connected load and external battery options.
Q3: How can the unit be managed?
A: It includes a pre-installed Network Management Card 3 with environmental monitoring, plus EPO and USB for local and remote control.
