APC SRT8KRMXLT - Smart-UPS SRT 8000VA Rackmount Online
[shortdesc] 8000VA / 8000W, Online Double-Conversion UPS, Scalable Runtime, Extended Battery Options, LCD Display, Rackmount 6U [/shortdesc]
[properties]
| Brand | APC by Schneider Electric |
| Model | SRT8KRMXLT |
| Product Type | Smart-UPS On-Line, Double Conversion |
| Form Factor | Rackmount 6U |
| Dimensions (H x W x D) | 10.4" x 17.0" x 28.1" (263 x 432 x 715 mm) |
| Weight | 245.99 lb (111.58 kg) |
| Color | Black |
| Number of Rack Units | 6U |
| Cable Length | — |
| Cooling | — |
[specifications]
| Capacity | 8000 VA / 8000 W |
| Input Voltage | 208 V (other: 240 V) • Adjustable: 100–275 V |
| Input Connection Type | Hard Wire 3-wire (2PH + G) |
| Input Frequency | 40–70 Hz auto-sensing |
| Output Voltage | 208 V (other: 240 V) |
| Output Connections | 4 × NEMA L6-20R, 2 × NEMA L6-30R, 1 × Hard Wire 3-wire (2PH + G) |
| Waveform Type | Sine wave |
| Topology | Double Conversion On-Line |
| Transfer Time | 0 ms (on-line) |
| Bypass Type | Internal (Automatic and Manual) |
| Crest Factor | 3:1 |
| Harmonic Distortion | <2% |
| Battery Type | Lead-Acid • Voltage: +/-192 V • Recharge: 1.5 h • Life: 3–5 years • RBC Qty: 2 • Replacement: APCRBC140 • Charge power: 1136 W rated |
| Extendable Runtime | Yes |
| Surge Energy Rating | 480 J |
| Acoustic Noise | 55 dBA |
| Thermal Dissipation | 1712 BTU/h |
| Operating Temperature | 0–40 °C (32–104 °F) |
| Operating Humidity | 0–95% non-condensing |
| Altitude | 0–10,000 ft operating |
| Communications | USB compatible, EPO, Audible/visible alarms, Pre-installed Network Management Card 3 with environmental monitoring, SmartSlot (1 free) |
| Certifications | ENERGY STAR V2.0 (USA), FCC Part 15 Class A, NOM, UL 1778 |
[accesories]
| Rack Mounting Hardware | Included in the box |
| Rack Mounting Brackets | Included in the box |
| Rack Mounting Support Rails | Included in the box |
| Temperature Probe | Included in the box |
| USB Cable | Included in the box |
| Documentation | CD with software, Documentation CD, Installation guide, Warranty card |
| Web/SNMP Management Card | Pre-installed in the unit |
Overview
The APC Smart-UPS SRT8KRMXLT delivers 8000VA/8000W of true online double-conversion power protection in a 6U rackmount form. Designed for high-density IT and mission-critical systems, it stabilizes power fluctuations, ensures consistent uptime, and supports scalable runtime with external battery packs. Featuring an intuitive LCD interface and remote management, this UPS is engineered for enterprise-grade reliability.
Key Features & Benefits
- Double-Conversion Online: Provides zero transfer time and maximum protection for sensitive equipment.
- Scalable Runtime: Add external battery packs for extended backup tailored to business needs.
- High Power Density: 8000W capacity supports servers, storage, and demanding IT environments.
- LCD Interface: Offers real-time monitoring and simplified configuration.
- Rackmount 6U Design: Efficient use of rack space in data centers and server rooms.
Technical Deep Dive
The Smart-UPS SRT8KRMXLT employs double-conversion technology, continuously converting incoming AC to DC and back to AC, ensuring pure and consistent power. This architecture eliminates voltage fluctuations and frequency variations, safeguarding sensitive IT hardware against even the most severe electrical disturbances.
With scalable runtime, businesses can extend backup by adding compatible battery packs. This flexibility makes the unit adaptable for short-duration bridging as well as extended outages. The hot-swappable battery design further enhances availability, enabling replacements without interrupting power to critical loads.
An advanced LCD panel provides intuitive access to system information, offering clear visibility into power conditions, runtime, and diagnostics. Combined with remote management via the pre-installed Network Management Card 3—and a SmartSlot (1 free) for additional options—IT teams gain comprehensive control across distributed deployments.
Ideal Applications
- Enterprise servers and storage arrays
- Mission-critical data center racks
- Network infrastructure and edge computing nodes
- Healthcare, finance, and industrial control systems
Frequently Asked Questions (FAQs)
Q1: How is the SRT8KRMXLT installed?
A: It is a 6U rackmount UPS that integrates seamlessly into standard racks with included mounting hardware.
Q2: What performance can I expect?
A: The UPS delivers 8000VA/8000W with online double-conversion protection. Runtime depends on load and can be extended with external battery packs.
Q3: How can the UPS be managed?
A: It features an LCD interface for local access and includes a pre-installed Network Management Card 3 for remote monitoring and control; a SmartSlot (1 free) supports additional options.
