APC SRT1000RMXLA-NC - Smart-UPS On-Line 1000VA 2U Rackmount
[shortdesc]
1000VA / 900W, Double Conversion Online, 6x NEMA 5-15R, Pre-installed Network Card, Extended Runtime
Please note: An additional shipping fee may apply to this product. Kindly contact us regarding the shipping fee after placing your order.
[/shortdesc]
[properties]
| Brand | APC by Schneider Electric |
| Model | SRT1000RMXLA-NC |
| Product Type | Smart-UPS On-Line, Double Conversion |
| Form Factor | Rackmount 2U |
| Dimensions (H x W x D) | 3.3" x 17.008" x 20.0" (85 x 432 x 508 mm) |
| Weight | 48.5 lb (22 kg) |
| Color | Black |
| Number of Rack Units | 2U |
| Cable Length | 6 ft (1.8 m) |
| Cooling | Active (Fan-cooled) |
[specifications]
| Capacity | 1000 VA / 900 W |
| Input Voltage | 120 V • Input window: 80–150 V (full load), 50–150 V (≤40% load) |
| Input Connection Type | NEMA 5-15P |
| Input Frequency | 40–70 Hz auto-sensing |
| Output Voltage | 120 V |
| Output Connections | 6 × NEMA 5-15R |
| Waveform Type | Sine wave |
| Topology | Double Conversion On-Line |
| Transfer Time | 0 ms (on-line) |
| Bypass Type | Built-in Static Bypass |
| Crest Factor | 3:1 |
| Harmonic Distortion | <2% |
| Battery Type | Lead-Acid • Voltage: 48 V • Recharge: 3 h • Life: 3–5 years • RBC Qty: 1 • Replacement: APCRBC155 • Charge power: 102 W rated |
| Extendable Runtime | Yes |
| Surge Energy Rating | 432 J |
| Acoustic Noise | 50 dBA |
| Thermal Dissipation | 317 BTU/h |
| Operating Temperature | 0–40 °C (32–104 °F) |
| Operating Humidity | 0–95% non-condensing |
| Altitude | 0–10,000 ft operating |
| Communications | USB, EPO, Audible/visible alarms, 1 free SmartSlot, Pre-installed Network Management Card 3 with environmental monitoring |
| Certifications | ENERGY STAR V2.0 (USA) |
| Warranty | 3 years repair or replace (excluding battery) and 2 years for battery |
| Output Frequency | 50/60 Hz ±3 Hz, synchronized to mains |
[accessories]
| Rack Mounting Hardware | Included in the box |
| Rack Mounting Brackets | Included in the box |
| Rack Mounting Support Rails | Included in the box |
| USB Cable | Included in the box |
| Temperature Probe | Included in the box |
| Documentation | CD with software, Documentation CD, Installation guide, Warranty card |
Overview
The APC Smart-UPS On-Line SRT1000RMXLA-NC delivers continuous double-conversion protection in a 2U rackmount form factor. Offering 1000VA / 900W of clean sine wave power, it is built for high-availability environments such as enterprise servers, storage systems, and networking hardware. With a pre-installed Network Management Card 3 and environmental monitoring, this UPS provides dependable operation and scalable runtime options.
Key Features & Benefits
- Double Conversion Online: Consistent, clean 120V output regardless of input disturbances.
- Extended Runtime: Supports external battery packs for longer backup.
- Integrated Network Card: Enables secure remote monitoring and environmental sensing.
- 2U Rackmount Design: Space-efficient installation for racks and edge IT.
- Energy Efficient: ENERGY STAR® V2.0 certified to help reduce operating costs.
- Robust Protection: Built-in static bypass and 432 J surge rating help maintain continuity.
Technical Deep Dive
Continuous AC–DC–AC conversion isolates connected equipment from voltage sags, surges, and line noise, delivering a low-distortion sine wave. The wide input window (80–150 V at full load, 50–150 V at ≤40% load) and built-in automatic static bypass enhance availability. Intelligent battery management supports a typical 3-hour recharge and long service life.
The pre-installed Network Management Card 3 enables remote visibility and control, while audible/visible alarms with severity prioritization provide prompt notification of state changes.
Ideal Applications
- Rack-mounted servers and enterprise storage
- Mission-critical network and communications gear
- Healthcare and financial environments requiring high uptime
- Edge computing and branch office deployments
Frequently Asked Questions (FAQs)
Q1: How is the SRT1000RMXLA-NC installed?
A: It’s a 2U rackmount UPS supplied with brackets, support rails, and mounting hardware.
Q2: What performance can I expect?
A: 1000VA / 900W online power. Runtime depends on load and any added battery packs.
Q3: How can I manage the UPS?
A: Via the pre-installed Network Management Card 3 for remote access, plus local USB and alarms.
