APC SRT1000RMXLA - Smart-UPS On-Line 1000VA Rackmount 2U UPS
[shortdesc] 1000VA / 900W, Double-Conversion Online, 2U Rackmount, 6x NEMA 5-15R Outlets, SmartSlot Expandability [/shortdesc]
[properties]
| Brand | APC by Schneider Electric |
| Model | SRT1000RMXLA |
| Product Type | Smart-UPS On-Line, Double Conversion |
| Form Factor | Rackmount 2U |
| Dimensions (H x W x D) | 3.3" x 17.008" x 20.0" (85 x 432 x 508 mm) |
| Weight | 48.5 lb (22 kg) |
| Color | Black |
| Number of Rack Units | 2U |
| Cable Length | 6 ft (1.8 m) |
| Cooling | Not specified |
[specifications]
| Capacity | 1000 VA / 900 W |
| Input Voltage | 120 V • Adjustable: 100–275 V • Operating: 80–150 V |
| Input Connection Type | NEMA 5-15P |
| Input Frequency | 40–70 Hz auto-sensing |
| Output Voltage | 120 V |
| Output Connections | 6 × NEMA 5-15R |
| Waveform Type | Sine wave |
| Topology | Double Conversion On-Line |
| Transfer Time | 0 ms (on-line) |
| Bypass Type | Built-in Bypass |
| Crest Factor | 3:1 |
| Harmonic Distortion | <2% |
| Battery Type | Lead-Acid • Voltage: 48 V • Recharge: 3 h • Life: 3–5 years • RBC Qty: 1 • Replacement: APCRBC155 • Charge power: 102 W rated |
| Extendable Runtime | Yes |
| Surge Energy Rating | 432 J |
| Acoustic Noise | 50 dBA |
| Thermal Dissipation | 317 BTU/h |
| Operating Temperature | 0–40 °C (32–104 °F) |
| Operating Humidity | 0–95% non-condensing |
| Altitude | 0–10,000 ft operating |
| Communications | USB, EPO, Audible/visible alarms, SmartSlot (1 free) |
| Certifications | ENERGY STAR V2.0 (USA) |
[accesories]
| Rack Mounting Hardware | Included in the box |
| Rack Mounting Brackets | Included in the box |
| Rack Mounting Support Rails | Included in the box |
| USB Cable | Included in the box |
| Documentation | CD with software, Documentation CD, Installation guide, Warranty card |
Overview
The APC SRT1000RMXLA is a high-density 2U rackmount UPS delivering 1000VA / 900W of reliable double-conversion online protection. With pure sine wave output, extendable runtime, and SmartSlot expandability, it helps keep business-critical IT and network devices powered under adverse conditions.
Key Features & Benefits
- Double-Conversion Online: Provides continuous, clean power by isolating connected loads from utility disturbances.
- Pure Sine Wave Output: Ensures compatibility with sensitive IT and network equipment.
- SmartSlot Capability: Enables integration of network management cards for remote monitoring.
- Compact 2U Design: Saves rack space while delivering 1000VA / 900W performance.
- Scalable Runtime: Supports external battery packs to meet extended backup needs.
Technical Deep Dive
The SRT1000RMXLA employs double-conversion online topology, constantly converting incoming AC to DC and regenerating stable AC for uninterrupted sine wave output.
It features a 48V lead-acid battery with a typical 3-hour recharge time, supporting extended runtime options with external packs. Intelligent battery management provides temperature-compensated charging and proactive replacement notifications.
With SmartSlot expandability, administrators can integrate advanced monitoring tools for remote power visibility and control.
Ideal Applications
- Rack servers and storage appliances
- Network hardware and communication systems
- Healthcare IT and financial systems
- Edge deployments requiring compact backup power
Frequently Asked Questions (FAQs)
Q1: How is the SRT1000RMXLA installed?
A: It is a 2U rackmount UPS, supplied with rails and brackets for straightforward rack integration.
Q2: What performance can I expect?
A: It provides 1000VA / 900W with pure sine wave output. Runtime varies by load and can be extended with external batteries.
Q3: How can it be managed?
A: Management is supported via USB. SmartSlot expansion allows advanced network management integration.
