APC SMX2000LV - Smart-UPS X 2000VA Rack/Tower 4U
[shortdesc] 2000VA / 1800W, Line-Interactive UPS, 4U Rack/Tower Convertible, 6x NEMA 5-15R + 3x NEMA 5-20R + 1x NEMA L5-20R Outlets, AVR, LCD Console, SmartSlot [/shortdesc]
[properties]
| Brand | APC |
| Model | SMX2000LV |
| Product Type | Smart-UPS X Rack/Tower Convertible |
| Form Factor | Rackmount 4U / Tower Convertible |
| Color | Black |
| Dimensions (H x W x D) | 17.01 x 7.01 x 19.02 in (43.2 x 17.8 x 48.3 cm) |
| Weight | 85.19 lb (38.64 kg) |
| Mounting Type | Rack-mounted / Tower Convertible |
[specifications]
| Input Voltage | 120 V (100 V / 110 V / 127 V compatible) |
| Input Frequency | 50/60 Hz ±3 Hz auto-sensing |
| Plug Type | NEMA 5-20P |
| Output Voltage | 120 V (100 V / 110 V / 127 V compatible) |
| Power Capacity | 1920 VA / 1800 W |
| Output Connections | 6 x NEMA 5-15R, 3 x NEMA 5-20R, 1 x NEMA L5-20R |
| Topology | Line Interactive |
| Waveform | Sine wave |
| Transfer Time | 4 ms typical, 8 ms maximum |
| Battery Type | Lead-Acid |
| Recharge Time | 3 hours typical |
| Battery Life | 3–5 years |
| Replacement Battery | APCRBC143 |
| Surge Protection | 540 J |
| Operating Temperature | 0…40°C |
| Operating Humidity | 0…95% |
| Warranty | 3 years repair or replace (excluding battery) and 2 years for battery |
[accesories]
| CD with Software | Included in the box |
| Documentation CD | Included in the box |
| Installation Guide | Included in the box |
| Rack Mounting Hardware | Included in the box |
| Rack Mounting Brackets | Included in the box |
| Rack Mounting Support Rails | Included in the box |
| Removable Support Feet | Included in the box |
| RS-232 Cable | Included in the box |
| USB Cable | Included in the box |
Overview
The APC Smart-UPS X SMX2000LV provides 2000VA / 1800W of reliable backup power in a versatile 4U rack/tower convertible design. With line-interactive topology, Automatic Voltage Regulation (AVR), and pure sine wave output, it ensures consistent and high-quality power for IT infrastructure. Featuring SmartSlot expandability, an intuitive LCD control panel, and support for extended runtime through external battery packs, this UPS is built for enterprise-grade performance and scalability.
Key Features & Benefits
- 2000VA / 1800W Capacity: Provides dependable power for servers, storage, and network devices.
- Pure Sine Wave Output: Maintains compatibility with sensitive IT equipment and active PFC power supplies.
- Automatic Voltage Regulation (AVR): Stabilizes voltage during fluctuations without discharging the battery.
- Extended Runtime Support: Connects with external battery modules for scalable backup during long outages.
- SmartSlot Expansion: Enables integration of network management and monitoring accessories.
- 4U Convertible Design: Deployable as either rackmount or tower with included hardware for flexibility.
- LCD Status Console: Provides clear visibility into UPS performance, alarms, and configuration settings.
Technical Deep Dive
The SMX2000LV uses a line-interactive design with AVR to regulate input voltages between 75–154V without engaging the battery, reducing wear and extending lifecycle performance. With a transfer time of just 2–4ms, it guarantees smooth transitions and uninterrupted operation during voltage disturbances.
Delivering pure sine wave output at up to 1800W, the UPS protects mission-critical IT loads, from enterprise servers to edge devices. Its scalable design allows connection of external battery packs, enabling organizations to tailor runtime based on business continuity needs. Recharge cycles are optimized to complete within 3 hours, ensuring readiness for subsequent events.
Equipped with a SmartSlot, the unit supports optional network management cards that enhance visibility and control. Combined with the front-panel LCD, administrators gain comprehensive tools for monitoring and management, both locally and remotely, strengthening IT resilience.
Ideal Applications
- Enterprise and branch office servers
- Networking devices including routers, switches, and firewalls
- Retail point-of-sale and back-office IT systems
- Healthcare and financial IT requiring extended runtime
Frequently Asked Questions (FAQs)
Q1: How is the SMX2000LV installed?
A: It is a 4U rack/tower convertible UPS that includes rack mounting hardware, support rails, and removable support feet for flexible installation.
Q2: What performance can I expect?
A: The UPS provides 2000VA / 1800W of pure sine wave output. Runtime depends on connected load but can be expanded with optional external battery packs. Refer to APC runtime charts for detailed values. Actual performance depends on load and battery condition.
Q3: How can the UPS be managed?
A: Local management is handled through the LCD console, while advanced remote monitoring can be achieved via SmartSlot cards, providing network and environmental control.
