[shortdesc]

• Managed, Rack-mountable, 24 x 10/100 Fast Ethernet ports, 2 x 1G SFP & RJ-45 combo + 2 x 1G SFP uplinks, No PoE (Data Only), Layer 2

[/shortdesc] [properties]

Properties	C1000FE-24T-4G-L
Description	24x 10/100 Ethernet ports, 2x 1G SFP & RJ-45 combo uplinks and 2x 1G SFP uplinks
Product Family	Catalyst 1000
Product Type	Ethernet Switch
Number of Ports	24
Uplink Interfaces	2 SFP/RJ-45 combo and 2 SFP
Available PoE power	No
Fanless	Yes
Width	17.32"
Depth	11.34"
Height	1.73"

[/properties] [specifications]

Specifications	C1000FE-24T-4G-L
Console Ports	1x RJ-45 Ethernet 1x USB-A port for storage and Bluetooth console
CPU	ARM v7 800 MHz
DRAM	512 MB
Flash Memory	256 MB
Forwarding Bandwidth	FE: 6.4 Gbps
Switching Bandwidth	FE: 12.8 Gbps
Forwarding Rate (64-byte L3)	FE: 9.52 Mpps
MAC addresses	16000
Maximum Active VLANs	256
Operating Temperature (Sea level)	-5 to 50 °C
Operating Temperature (Up to 5,000 ft / 1500 m)	-5 to 45 °C
Operating Temperature (Up to 10,000 ft / 3000 m)	-5 to 40 °C
Safety	UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1, IEC 62368-1, UL 62368-1, GB 4943.1-2011
EMC: emissions	47CFR Part 15 Class A, AS/NZS CISPR32 Class A, CISPR32 Class A, EN55032 Class A, ICES-003 Class A, VCCI-CISPR32 Class A, EN61000-3-2, EN61000-3-3, KN32 Class A, CNS13438 Class A
EMC: immunity	EN55024 (including EN 61000-4-5), EN300386, KN35
Environmental	Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU
Telco	Common Language Equipment Identifier (CLEI) code
U.S. Government certifications	USGv6 and IPv6 Ready Logo
Ethernet interfaces	10BASE-T ports: RJ-45 connectors, 2-pair Category 3, 4, or 5 UTP cabling 100BASE-TX ports: RJ-45 connectors, 2-pair Category 5 UTP cabling 1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Category 5 UTP cabling
Telnet - SSH	Yes
TACACS, TACACS+, Radius	Yes

[/specifications] [accesories]

Part Number	Description
CAB-CONSOLE-RJ45	Console Cable 6 Feet with RJ-45
PWR-CLP	Power Cable Restraining Clip
RCKMNT-19-CMPCT	19" Rack Mount bracket for C1000, 3560-CX and 2960-CX
RCKMNT-23-CMPCT	23" and 24" Rack Mount bracket for C1000, 3560-CX and 2960-CX

[/accesories]

Cisco C1000FE-24T-4G-L Switch

The Cisco C1000FE-24T-4G-L is a quiet, fanless Fast Ethernet access switch for small and medium businesses that need reliable Layer 2 connectivity with simple management. It provides twenty-four 10/100 access ports and four 1-Gigabit SFP uplinks (two SFP/RJ-45 combo plus two dedicated SFP) to scale out cleanly while keeping costs down.

Key Features:

• 24 x Fast Ethernet Access: Solid 10/100 connectivity for clients, printers, phones, and IoT endpoints.
• 4 x 1G Uplinks: Two SFP/RJ-45 combo plus two dedicated SFP uplinks for flexible aggregation.
• Silent Operation: Fanless hardware suited for deskside, retail, classroom, and branch spaces.
• Simple Management: Intuitive web UI and CLI for quick setup, monitoring, and troubleshooting.
• Security Controls: 802.1X, port security, and TACACS+/RADIUS support to harden the edge.

Technical Overview:

• Model: C1000FE-24T-4G-L, Layer 2.
• Ports: 24 x 10/100 FE access, 2 x 1G SFP/RJ-45 combo, 2 x 1G SFP.
• Performance: 12.8 Gbps switching capacity, 6.4 Gbps forwarding bandwidth, 9.52 Mpps forwarding rate.
• Hardware: ARM v7 800 MHz CPU, 512 MB DRAM, 256 MB flash; 16K MAC, 256 active VLANs.
• Environment: Operating temperature: −5 to 50 °C (sea level), −5 to 45 °C (≤1500 m), −5 to 40 °C (≤3000 m).
• Dimensions: 17.32" W x 11.34" D x 1.73" H.

You can check the related tab for the C1000FE-24T-4G-L datasheet.
