[shortdesc]

• Switch, Managed, 24x 10/100/1000 Ethernet ports, 4x 1G SFP uplinks

[/shortdesc] [specifications]

Specifications	C1000-24T-4G-L
Console Ports	1x RJ-45 (console) 1x USB-A port for storage and Bluetooth console
CPU	ARM v7 800 MHz
DRAM	512 MB
Flash Memory	256 MB
Forwarding Bandwidth	28 Gbps
Switching Bandwidth	56 Gbps
Forwarding Rate (64-byte L3)	41.67 Mpps
MAC addresses	16000
Maximum Active VLANs	256
Operating Temperature	0 to 40 °C
Altitude	Up to 10,000 ft (3,000 m)
Safety	UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1, IEC 62368-1, UL 62368-1, GB 4943.1-2011
EMC: emissions	47CFR Part 15 Class A, AS/NZS CISPR32 Class A, CISPR32 Class A, EN55032 Class A, ICES-003 Class A, VCCI-CISPR32 Class A, EN61000-3-2, EN61000-3-3, KN32 Class A, CNS13438 Class A
EMC: immunity	EN55024 (including EN 61000-4-5), EN300386, KN35
Environmental	Reduction of Hazardous Substances (RoHS), including Directive 2011/65/EU
Telco	Common Language Equipment Identifier (CLEI) code
U.S. Government certifications	USGv6 and IPv6 Ready Logo
Ethernet interfaces	10BASE-T: RJ-45, 2-pair Cat 3/4/5 UTP cabling 100BASE-TX: RJ-45, 2-pair Cat 5 UTP cabling 1000BASE-T: RJ-45, 4-pair Cat 5 UTP cabling 1000BASE-X SFP-based uplinks
Telnet - SSH	Yes
TACACS, TACACS+, Radius	Yes

[/specifications]

[properties]

Properties	C1000-24T-4G-L
Description	24x 10/100/1000 Ethernet ports, 4x 1G SFP uplinks
Product Family	Catalyst 1000
Product Type	Ethernet Switch
Number of Ports	24
Uplink Interfaces	4 × 1G SFP
Available PoE power	No
Fanless	No
Height	1.712"
Depth	16.14"
Width	17.29"

[/properties]

[accesories]

Part Number	Description
CAB-CONSOLE-RJ45	Console Cable 6 Feet with RJ-45
CAB-CONSOLE-USB	Console Cable 6 Feet with USB Type A and mini-B Connectors
PWR-CLP	Power Cable Restraining Clip
RCKMNT-1RU-2KX	Rackmount kit for 1 RU for C1000, 2960-X, and 2960-XR (19/23/24/ETSI)

[/accesories]

Cisco Catalyst C1000-24T-4G-L Switch

The Cisco Catalyst C1000-24T-4G-L Switch is a reliable and efficient networking solution designed for small to medium-sized businesses and branch offices. With 24 Gigabit Ethernet ports and 4 SFP uplinks, this switch provides high-performance connectivity for various network devices. The fan design and ample airflow support dependable operation in office environments, while advanced security features safeguard your network infrastructure.

Key Features:

• 24 x Gigabit Ethernet Ports: Provides fast and reliable network connectivity for a wide range of devices.
• 4 x SFP Uplinks: Dedicated 1G fiber uplinks for easy aggregation and scalable expansion.
• Simple Management: Web UI and CLI, with optional Bluetooth console and SNMP for monitoring.
• Traffic Visibility: SPAN and sFlow support for diagnostics and performance analysis.
• Enhanced Security: 802.1X, BPDU Guard, and ACLs to protect the access layer.

Technical Overview:

• Ports: 24 x 10/100/1000BASE-T downlinks, 4 x 1000BASE-X SFP uplinks.
• Switching Capacity: 56 Gbps.
• Forwarding Rate: 41.67 Mpps.
• Management: RJ-45 console, USB-A (storage/Bluetooth); Web UI / CLI; SNMP.
• Dimensions (W × D × H): 17.29" × 16.14" × 1.712".
• Operating Range: 0 to 40 °C; up to 10,000 ft (3,000 m) altitude.

You can check the related tab for the C1000-24T-4G-L datasheet.
