Broadcom 9400-16e Tri-Mode Storage HBA
- Tri-Mode SerDes Technology, which enables a single controller to operate in all three modes concurrently, providing maximum flexibility and scalability.
- Up to 12Gb/s throughput per port.
- Support for up to 1024 SAS/SATA devices or 24 NVMe devices per controller.
- PCIe 3.1 x8 host bus interface.
- SFF-8485 Compliant, SGPIO.
- Lane and polarity reversal.
- Variable PCIe bandwidth negotiation
| Product Name | Broadcom 9400-16E Tri-Mode Storage Adapter | |
| Product Description | PCIe 3.1 HBA with 8 external ports, designed for large-scale external storage enclosures in data centers, providing high bandwidth and flexibility. | |
| Interface | PCIe 3.1 x8 | SATA 6 Gbps |
| Port Configuration | 8 external ports | |
| Supported Devices | Supports up to 1024 SAS/SATA devices | |
| Connector Type | 4 (x4) SFF-8644 connectors | |
| Controller Type | SAS3416 | |
| Compatibility | Tri-Mode SerDes Technology for NVMe, SAS, and SATA devices | |
| Performance Feature | Up to 12Gb/s throughput per port | |
| Cable Support | Passive Copper, Active Copper, Active Optical | |
| Intended Application | Large-scale external storage enclosures in data centers | |
| PCIe Features | Variable PCIe bandwidth negotiation, lane, and polarity reversal | |
[specifications]
| Interface Type | PCIe 3.1 x8 |
| External Ports | 8 |
| Connector Type | 4 (x4) SFF-8644 connectors |
| Device Compatibility | SAS, SATA, and NVMe (Tri-Mode support) |
| Maximum Device Support | SAS/SATA: 1024 |
| Controller Type | SAS3416 |
| Data Throughput | Up to 12Gb/s per port |
| Power Consumption | Typical 11.18W |
| Operating Voltage | 12V ±8%; 3.3V ±9% |
| Reliability | MTBF > 4,500,000 hours at 40°C |
| Management Software | LSA, StorCLI, HII |
| OS Compatibility | Windows, VMware vSphere/ESXi, Red Hat, SUSE, Ubuntu, Citrix XenServer, CentOS, Debian, Oracle Linux, Fedora, FreeBSD |
| Certifications | FCC 47 CFR part 15 Subpart B, class B |
| Physical Dimensions | 6.600 in x 2.712 in (167.65 mm x 68.90 mm) |
| Operating Temperature Range | 0°C to 55°C |
[/specifications]
Broadcom 9400-16E Tri-Mode Storage
The 9400-16e Tri-Mode Storage Adapter is specifically engineered for use in large-scale external storage enclosures, offering enhanced connectivity and optimal performance to accommodate the flexibility of data centers. Compared to its predecessors, this adapter boasts increased bandwidth and IOPS performance, making it well-suited for critical applications that require high performance and scalability. Equipped with 16 external ports and 4 (x4) SFF-8644 connectors, the 9400-16e supports various cable types, including passive copper, active copper, and active optical.
Quick Specs:
- PCIe 3.1 Host Interface
- SAS/SATA: 1024
- 4x SFF-8643 for connectors
- 16 internal ports
Please see the related tabs for the 9400-16e datasheet and compatible accessories.
