AXIS Q2112-E 10 mm 30 fps Thermal Camera (02604-001)
[shortdesc] Outdoor-ready thermal camera with a 10 mm F1.2 lens, 63° wide field of view, 640×480 thermal sensor, <20 mK sensitivity, and up to 30 fps thermal imaging powered by the ARTPEC-8 SoC with deep learning processing unit. [/shortdesc]
[properties]
| Model | AXIS Q2112-E 10 mm 30 fps Thermal Camera (02604-001) |
| Product Type | Thermal Camera |
| Image Sensor | Uncooled microbolometer, 640×480 pixels, 17 μm; spectral range 8–14 μm |
| Lens | Athermalized 10 mm, F1.2; horizontal FOV 63°; vertical FOV 46°; near focus distance 2.8 m (9.2 ft) |
| Sensitivity | NETD <20 mK @25 °C, F1.0 |
| Frame Rate | Up to 30 fps thermal imaging |
| System on Chip | ARTPEC-8 with deep learning processing unit (DLPU) |
| Memory | 2048 MB RAM, 8192 MB Flash |
| Power | PoE IEEE 802.3af/802.3at Type 2 Class 4; typical 5.2 W, max 25.5 W; 10–28 V DC (typical 4.6 W, max 25.5 W) |
| Connectors | RJ45 10/100/1000 PoE; terminal block for 2 supervised and 2 unsupervised I/O (12 V DC out, 50 mA); 3.5 mm mic/line in; 3.5 mm line out; 2× RS485/RS422; DC input |
| Operating Conditions | -40 °C to 60 °C; maximum 74 °C per NEMA TS 2; humidity 10–100% RH (condensing) |
| Storage Conditions | -40 °C to 65 °C; humidity 5–95% RH (non-condensing) |
| Casing | IP66/IP67, IK10, and NEMA 4X-rated aluminum housing; white NCS S 1002-B |
| Dimensions | See datasheet dimension drawing; EPA 0.05 m² (0.48 ft²) |
| Weight | 3.3 kg (7.3 lb) |
| Storage | microSD/microSDHC/microSDXC support; AES-XTS-Plain64 256-bit SD encryption; NAS recording |
| Certifications | CSA, UL/cUL, CE, KC, VCCI, RCM; CISPR 32/35; EN 50121-4; FCC Part 15 Class A; IEC 62236-4 |
| Safety | CAN/CSA/IEC/EN/UL 62368-1 ed.3; IS 13252 |
| Environmental Ratings | IEC 60068-2-1/-2/-6/-14/-27/-78; ISO 21207 Method B; IP66/IP67; IK10; NEMA 4X; NEMA TS 2; MIL-STD-810H (505.7, 506.6, 507.6, 509.7, 510.7, 512.6, 521.4) |
| Cybersecurity | Axis Edge Vault (TPM 2.0), secure boot, signed firmware, encrypted filesystem, secure keystore, Axis device ID, OAuth 2.0, brute force delay protection |
[/properties]
[specifications]
| Video | H.264, H.265, Motion JPEG; 640×480 scalable to 800×600; up to 30 fps; up to 20 streams; Zipstream; VBR/ABR/MBR; controllable frame rate |
| Image Settings | Contrast, brightness, sharpness, exposure zones, local contrast, compression; rotation 0°/90°/180°/270°; corridor format; mirroring; overlays; polygon privacy masks; EIS; thermal color palettes |
| Audio | Two-way audio; AGC; EQ; external mic input; line in/out; network speaker pairing; LPCM, AAC-LC, G.711, G.726, Opus |
| Networking Protocols | IPv4/IPv6, HTTP/HTTPS/HTTP2, TLS, FTP/SFTP, CIFS/SMB, SMTP, mDNS/Bonjour, UPnP, SNMP v1/v2c/v3, DNS, NTP, PTP, RTSP/RTP/SRTP, TCP/UDP, IGMP, MQTT, SSH, LLDP, CDP, secure syslog |
| System Integration | VAPIX, ACAP, ONVIF Profiles G/M/S/T; one-click cloud; AXIS Camera Station & third-party VMS support |
| Event Conditions | Audio detection; device status changes; IP address changes; storage conditions; I/O events; tampering; MQTT subscribe; bitrate degradation; scheduling |
| Event Actions | Audio clip play/stop; toggle I/O; MQTT publish; HTTP/HTTPS/TCP/email notifications; text overlay; pre/post-alarm buffering; SD/NAS recording; FTP/SFTP/HTTP uploads; SNMP traps; LED flash |
| Analytics | Included: Motion Detection, Motion Guard, Fence Guard, Loitering Guard, tampering alarm, audio detection; Supported: AXIS Perimeter Defender; ACAP applications |
| Pan/Tilt Support | Supports guard tours when used with an external positioning unit (up to 256 presets) |
| Security | TPM 2.0, secure boot, encrypted storage, MACsec, TEE, TLS v1.2/v1.3, 802.1X, password protection, brute force delay protection |
[/specifications]
[accesories]
| Included | Camera, installation guide, terminal block connectors, connector guard, cable gaskets, owner authentication key |
| Optional Accessories | AXIS TQ1818-E Positioning Unit; AXIS TQ1003-E Wall Mount; additional accessories available on the Axis support page |
[/accesories]
The AXIS Q2112-E 10 mm 30 fps Thermal Camera delivers smooth, high-frame-rate thermal imaging for monitoring wide outdoor areas with improved tracking and motion clarity. With its wide 63° horizontal field of view, it is ideal for covering open perimeters, facility boundaries, and broad surveillance zones with fewer devices. The 640×480 thermal sensor, combined with exceptional <20 mK sensitivity, ensures high-quality contrast in complete darkness and challenging environmental conditions.
Powered by the ARTPEC-8 SoC with a deep learning processing unit, the camera supports advanced edge analytics such as AXIS Motion Guard, Fence Guard, Loitering Guard, and AXIS Perimeter Defender. Its rugged IP66/IP67, IK10, NEMA 4X, and MIL-STD-810H ratings ensure long-term reliability. Strong cybersecurity protections and broad protocol support make it easy to integrate into secure, enterprise-grade thermal monitoring systems.
High-Frame-Rate Thermal Imaging for Wide-Area Surveillance
- Up to 30 fps thermal imaging improves clarity when tracking movement across wide scenes.
- 63° wide horizontal field of view reduces camera count for large-area coverage.
- 640×480 resolution with <20 mK sensitivity delivers strong contrast and consistent detection performance.
- ARTPEC-8 with DLPU supports advanced on-edge analytics and accurate event detection.
- IP66/IP67, IK10, NEMA 4X, and MIL-STD-810H durability ensure reliable outdoor operation.
- Robust cybersecurity stack including TPM 2.0, secure boot, MACsec, and encrypted storage.
- Comprehensive ONVIF and VAPIX support ensures seamless integration with leading VMS platforms.
Ideal Use Cases
- Wide-area perimeter protection requiring smoother motion capture.
- Logistics yards, open industrial sites, and large outdoor campuses.
- Thermal monitoring in fog, smoke, haze, or low-light environments.
- Border zones and open landscapes requiring broad thermal situational awareness.
- Analytics-driven detection where high-frame-rate thermal data improves event clarity.
Technical Specifications Summary
- Image sensor: 640×480 uncooled microbolometer, 17 μm
- Lens: Athermalized 10 mm F1.2; HFOV 63°; VFOV 46°; near focus 2.8 m
- Sensitivity: NETD <20 mK @25 °C
- Video: Up to 30 fps; H.264/H.265/MJPEG; Zipstream
- Analytics: Motion Guard, Fence Guard, Loitering Guard; Perimeter Defender support
- Power: PoE Type 2 Class 4; 10–28 V DC
- Durability: IP66/IP67, IK10, NEMA 4X, MIL-STD-810H
- Cybersecurity: TPM 2.0, secure boot, encrypted storage, MACsec
Upgrade Your Operations
Enhance wide-area thermal monitoring with smooth, high-frame-rate imaging and powerful edge analytics.
