[properties]

Properties	MX2020-PREMIUM2-AC
Description	20 slot MX2020 premium 2 chassis with optimized AC power
Product Family	MX2000 Series
Product Type	Router
DPCs and/or MPCs per chassis	20 (MPC only)
Maximum Line-Rate Port Density
with MPC11E 100GbE	800
with MPC11E 400GbE	160
with MPC9E 10GbE	1920
with MPC9E 40GbE	480
with MPC9E 100GbE	320
Physical dimensions (W x D x H)	78.75 x 36.2 x 17.5 in (200 x 91.95 x 44.45 cm)
Approximate maximum weight	1,500 lbs (680.39 kg)
Rack units	45
Number of fan trays	4
System mounting	Four-post rack mounting
Power options	AC/DC: -40 to -72 V DC 100-240 V AC
Air flow	Front to back

[/properties] [specifications]

Specifications	MX2020-PREMIUM2-AC
Slots	20
Per slot capacity	4 Tbps
System throughput	80 Tbps
Power-to-throughput efficiency ratio (max)	0.25W/GbE
Operating temperature	32°F (0°C) to 104°F (40°C)
Humidity	5% to 90% noncondensing humidity

[/specifications] [accesories] [/accesories] The SDN-ready MX2020 Universal Routing Platform is the industry's highest-capacity edge router. It delivers 80 Tbps of system capacity and supports up to 800 100GbE interfaces, 320 200GbE interfaces, or 160 400GbE interfaces in a single chassis when used with the Modular Port Concentrator 11E (MPC11E) line card.
