Mikrotik CCR2004-16G-2S+ Router
- This powerful and affordable router crushes all previous CCR models in single-core performance. 16x Gigabit Ethernet ports, 2x10G SFP+ cages, active cooling and the best single-core performance per watt & best overall performance per watt among all the CCR devices.
[properties]
| Properties | CCR2004-16G-2S+ |
| Description | The Connectivity Router - your best companion with 18 wired ports, including 16x Gigabit Ethernet ports and two 10G SFP+ cages |
| Product Family | CCR Series |
| Product Type | Ethernet Router |
| 10/100/1000 Ethernet ports | 16 |
| 10G SFP+ | 2 |
| Serial console port | RJ45 |
| Extras | CPU temperature monitor PCB temperature monitor Voltage Monitor |
| Dimensions | 443 x 210 x 44 mm |
| Number of AC inputs | 2 |
| Frequency (Hz) | 50-60 |
| AC input range | 100-240 |
| Max power consumption | 48 W |
| Max power consumption without attachments | 35 W |
| Cooling type | 2 fans |
| Included | 2 IEC cords Screw and feet kit (K10) Rackmount bracket |
[/properties][specifications]
| Specifications | CCR2004-16G-2S+ |
| Memory | 4 GB |
| NAND Storage size | 128 MB |
| CPU | AL32400 1700 MHz |
| CPU core count | 4x 64-bit ARMv8-A Cortex-A57 |
| OS | MikroTik RouterOS v7, Level 6 license, free product lifetime upgrades |
| MTBF | Approximately 200.000 hours at 25C |
| Temperature | -20°C to 60°C tested |
| IPsec hardware acceleration | IP20 |
| Certification | CE, EAC, ROHS |
[/specifications]
MikroTik CCR2004-16G-2S+ Router
The CCR2004-16G-2S+ features the Amazon Annapurna Labs Alpine v2 CPU with 4x 64b-bit ARMV8-A Cortex-A57 cores running at 1,7 GHz. The CCR2004-16G-2S+ has 18 wired ports in total, including 16x Gigabit Ethernet ports and two 10G SFP+ cages and with such a diverse set of ports, you can easily tackle data-intensive jobs while still achieving lightning-fast data transfers across wired connections. It also demonstrates the highest single-core performance efficiency and overall performance efficiency among all CCR devices in terms of power consumption.
Quick Specs:
- 16x 10/100/1000 Ethernet Ports
- 2x 10G SFP+ ports uplink
- 4 GB DDR4 RAM
- AL32400, 4 core, 1700 MHz CPU
Please see the related tabs for the CCR2004-16G-2S+ datasheet and compatible accessories.
