Properties	MikroTik hAP ax3 (C53UiG+5HPaxD2HPaxD-US)
Description	A powerful home access point with AX wireless technology for high-speed, secure connectivity. Featuring a quad-core ARM CPU, 1GB RAM + 128 MB NAND memory, and advanced RouterOS v7 updates including WPA3 encryption support, hAP ax3 ensures smooth browsing, streaming, and gaming. With up to 40% higher speed in the 5 GHz spectrum and 4x Gigabit Ethernet ports plus an ultra-fast 2.5 Gigabit port, it's the ultimate choice for your home network.
Product Family	MikroTik hAP ax3
Product Type	Router
Included parts	24 V 1.5 A power adapter Fastening set HGO indoor antenna kit Case base

[/properties] [specifications]

Specifications
Product code	C53UiG+5HPaxD2HPaxD-US
CPU	Quad-Core IPQ-6010 1.8 GHz
CPU architecture	ARM 64bit
Size of RAM	1 GB
Storage	128 MB, NAND
Number of 1G Ethernet ports	4
Number of 2.5G	Ethernet ports 1 (supports PoE-in/out)
USB	1 USB 3 type A
Switch chip model	IPQ-6010
Wireless interface model	QCN-5022 (2.4 GHz), QCN-5052 (5 GHz)
Wireless	2.4 GHz 802.11b/g/n/ax dual-chain, 5 GHz 802.11a/n/ac/ax dual-chain
Wireless antenna max gain	2.4 GHz (3.3 dBi), 5 GHz (5.5 dBi)
Dimensions	251 x 130 x 39 mm
Operating system	RouterOS, License level 6
Operating temperature	(-40°C to +70°C)
Powering
Number of DC inputs	2 (PoE-in, DC jack)
PoE-in input Voltage	18-28 V
DC jack input Voltage	12-28 V
PoE-out	Passive PoE Ether1, max out per port output (input < 30 V): 0.625 A
PoE-out total output power	15 W
Power adapter nominal voltage	24 V
Power adapter nominal current	1.5 A
Max power consumption (without attachments)	15 W
Max power consumption	38 W
Wireless specifications
1MBit/s	Tx (dBm): 27 Rx (dBm): -100
11MBit/s	Tx (dBm): 27 Rx (dBm): -94
6MBit/s	Tx (dBm): 29 Rx (dBm): -96
54MBit/s	Tx (dBm): 27 Rx (dBm): -80
MCS0	Tx (dBm): 29 Rx (dBm): -96
MCS7	Tx (dBm): 26 Rx (dBm): -75
MCS9	Tx (dBm): 24 Rx (dBm): - 70
MCS11	Tx (dBm): 22 Rx (dBm): -67

[/specifications] [accesories] [/accesories]

MikroTik's hAP ax router series comprises a selection of home Wi-Fi routers that incorporate Wi-Fi 6 technology. Tailored for use in small residences, apartments, and small-scale office environments, this series presents a variety of models to address diverse requirements. These routers have robust wireless chips that deliver enhanced speed and signal strength across both the 2.4 and 5 GHz frequency bands. Additionally, they feature contemporary CPUs, generous memory capacity, and multiple Ethernet ports, guaranteeing seamless and dependable connectivity for various activities.

Quick Specs:

• IPQ-6010, 4 core, (864-1800) MHz CPU
• 1GB RAM
• 4x 10/100/1000 Ethernet Ports (1x 1G Ethernet port with PoE-out)
• 1x 2.5G Ethernet Port



Please see the related tabs for the C53UiG+5HPaxD2HPaxD-US datasheet and compatible accessories.
