[shortdesc]

• True to life, 180-degree coverage, no blind spots, 7 MP multisensor camera with one IP address, 180 degrees horizontal, 90-degree vertical coverage, Seamlessly stitched realistic images, Support for advanced analytics, Horizon straightening

[/shortdesc]
[properties]

Properties	AXIS P3827-PVE Panoramic Camera
Description	The AXIS P3827-PVE Panoramic Camera provides true-to-life 180° coverage with no blind spots. Featuring a 7 MP resolution and seamless stitching of four images, it delivers detailed, high-quality footage at up to 30 fps. With 180° horizontal and 90° vertical coverage, it eliminates blind spots, and you can mount two cameras back-to-back for a complete 360° overview. The camera includes horizon straightening for an excellent viewing experience and is built on ARTPEC-8, supporting advanced analytics based on deep learning on the edge. With one IP address, cybersecurity features are built-in to prevent unauthorized access and safeguard your system.
Product Family	AXIS P3827-PVE Panoramic Camera
Product Type	Panoramic Camera

[/properties] [specifications]

Specifications	AXIS P3827-PVE Panoramic Camera
Camera
Image sensor	4 x 1/2.8” progressive scan RGB CMOS
	Pixel size 2.9 µm
Lens	Fixed 3.3 mm, F2.0
	Horizontal field of view: 180°
	Vertical field of view: 90°
Day and night	Automatic IR-cut filter
	Hybrid IR filter
Minimum illumination	Color: 0.15 lux at 50 IRE, F2.0
	B/W: 0.05 lux at 50 IRE, F2.0
Shutter speed	1/31500 s to 1.5 s
Camera angle adjustment	Pan ±180°
	Tilt 0° to 50°
	Roll ±5°
System on chip (SoC)
Model	ARTPEC-8
Memory	2048 MB RAM, 8192 MB Flash
Compute capabilities	Deep learning processing unit (DLPU)
Video
Video compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
	H.265 (MPEG-H Part 2/HEVC) Main Profile
	Motion JPEG
Resolution	3712x1856 to 640x320
Frame rate	Up to 25/30 fps (50/60 Hz) in all resolutions
Video streaming	Up to 20 unique and configurable video streams*
	Axis Zipstream technology in H.264 and H.265
	Controllable frame rate and bandwidth
	VBR/ABR/MBR H.264/H.265
	Low latency mode
	Video streaming indicator
	*: We recommend a maximum of 3 unique video streams for optimized user experience, network bandwidth, and storage utilization. A unique video stream can be served to many video clients in the network using multicast or unicast transport method via built-in stream reuse functionality.
Signal-to-noise ratio	>55 dB
Forensic WDR	Up to 120 dB depending on scene
Multi-view streaming	Up to 8 individually cropped out view areas
Noise reduction	Spatial filter (2D noise reduction)
	Temporal filter (3D noise reduction)
Image settings	Saturation, contrast, brightness, sharpness, Forensic WDR: up to
	120 dB depending on scene, white balance, day/night threshold,
	exposure mode, compression, dynamic text, and image overlay,
	orientation aid, exposure mode, noise reduction,polygon privacy masks,
	Horizon straightening, Local contrast, Tone mapping
Audio
Audio features	AGC automatic gain control
	Network speaker pairing
Audio streaming	Configurable duplex:
	One-way (simplex, half duplex)
	Two-way (half duplex, full duplex)
Audio input	Input for external unbalanced microphone, optional 5 V
	microphone power
	Digital input, optional 12 V-ring power
	Unbalanced line input
Audio output	Output via network speaker pairing
Audio encoding	24bit LPCM, AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726
	ADPCM 8 kHz, Opus 8/16/48 kHz
	Configurable bit rate
Network
Network protocols	IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS*, HTTP/2, TLS*, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf), IEEE 802.1X (EAP-TLS), IEEE 802.1AR
	*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (openssl.org), and cryptographic software written by Eric Young
System Integration
Application Programming Interface	Open API for software integration, including VAPIX®, metadata
	and AXIS Camera Application Platform (ACAP); specifications at
	axis.com/developer-community.
	One-click cloud connection
	ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and
	ONVIF® Profile T
Video management systems	Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro
	AXIS Camera Station 5 and video management software from
	Axis’ partners are available at axis.com/vms
Onscreen controls	Privacy masks
	Media clip
Event conditions	Device status: above operating temperature, above or below
	operating temperature, below operating temperature, within
	operating temperature, IP address removed, new IP address,
	network lost, system ready, ring power overcurrent protection,
	live stream active, casing open
	Digital audio input status
	Edge storage: recording ongoing, storage disruption, storage
	health issues detected
	I/O: digital input, manual trigger, virtual input
	MQTT: subscribe
	Scheduled and recurring: schedule
	Video: average bitrate degradation, day-night mode, live stream,
	tampering
Event actions	Audio clips: play, stop
	Day-night mode
	I/O: toggle I/O once, toggle I/O while the rule is active
	MQTT: Publish
	Notification: HTTP, HTTPS, TCP and email
	Overlay text
	Recordings: SD card and network share
	SNMP traps: send, send while the rule is active
	Upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network
	share and email
Built-in installation aids	Pixel counter, level grid
Analytics
AXIS Object Analytics	Object classes: humans, vehicles (types: cars, buses, trucks, bikes, other)
	Scenarios: line crossing, object in area, time in area, crossline counting, occupancy in area
	Up to 10 scenarios
	Metadata visualized with trajectories, color-coded bounding
	boxes and tables
	Polygon include/exclude areas
	Perspective configuration
	ONVIF Motion Alarm event
Metadata	Object data: Classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates
	Attributes: Vehicle color, upper/lower clothing color, confidence, position
	Event data: Producer reference, scenarios, trigger conditions
Applications	Included
	AXIS Object Analytics, AXIS Video Motion Detection, active
	tampering alarm, audio detection
	Support for AXIS Camera Application Platform enabling
	installation of third-party applications, see axis.com/acap
Approvals
Product markings	CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM
Supply chain	TAA compliant
EMC	CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A,
	EN 50121-4, EN 61000-6-1, EN 61000-6-2, IEC 62236-4
	Australia/New Zealand: RCM AS/NZS CISPR 32 Class A
	Canada: ICES-3(A)/NMB-3(A)
	Japan: VCCI Class A
	Korea: KS C 9835, KS C 9832 Class A
	USA: FCC Part 15 Subpart B Class A
Safety	CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, IS 13252
Environment	IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9), MIL-STD-810H (Method 501.7, 502.7, 505.7, 506.6, 507.6, 509.7, 512.6)
	*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (openssl.org), and cryptographic software written by Eric Young
Network	NIST SP500-267
Cybersecurity
Edge security	Software: Signed firmware, brute force delay protection, digest
	authentication and OAuth 2.0 RFC6749 OpenID Authorization
	Code Flow for centralized ADFS account management, password
	protection, AES-XTS-Plain64 256bit SD card encryption
	Hardware: Secure boot, Axis Edge Vault with Axis device ID,
	signed video, secure keystore (CC EAL4+, FIPS 140-2 level 2
	certified hardware protection of cryptographic operations and keys)
Network security	IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)* , IEEE 802.1AR, HTTPS/HSTS* , TLS v1.2/v1.3*, Network Time Security (NTS), X.509 Certificate PKI, IP address filtering, host-based firewall
	*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (openssl.org), and cryptographic software written by Eric Young
Documentation	AXIS OS Hardening Guide
	Axis Vulnerability Management Policy
	Axis Security Development Model
	AXIS OS Software Bill of Material (SBOM)
	To download documents, go to axis.com/support/cybersecurity/resources
	To read more about Axis cybersecurity support, go to axis.com/cybersecurity
General
Casing	IP66/IP67-, NEMA 4X- and IK10-rated aluminum casing
	Polycarbonate hard-coated dome
	Color: white NCS S 1002-B
	For repainting instructions, go to the product’s support
	page. For information , go to
	axis.com
Mounting	Mounting bracket with junction box holes (double-gang, single-gang, 4” square, and 4” octagon) and for wall or ceiling mount
	¾” (M25) conduit side entries
Power	Power over Ethernet (PoE) IEEE 802.3at Type 2 Class 4
	Typical 12 W, max 18 W
Connectors	Network: Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE
	I/O: Terminal block for two configurable supervised inputs /
	digital outputs (12 V DC output, max load 50 mA)
	Audio: 3.5 mm analog/digital mic/line in
Storage	Support for microSD/microSDHC/microSDXC card
	Recording to network-attached storage (NAS)
	For SD card and NAS recommendations see axis.com
Operating conditions	(-40 °C to 55 °C) (-40 °F to 131 °F)
	Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C
	(165 °F)
	Start-up temperature: -40 °C
	Humidity 10–100% RH (condensing)
Storage conditions	(-40 °C to 65 °C) (-40 °F to 149 °F)
	Humidity 5–95% RH (non-condensing)
Dimensions	Height: 169 mm (6.7 in)
	ø 195 mm (7.7 in)
	Effective Projected Area (EPA): 0.025 m² (0.27 ft²)
Weight	2300 g (5.1 lb)
Box content	Camera, installation guide, terminal block connector, connector
	guard, cable gaskets, owner authentication key
System tools	AXIS Site Designer, AXIS Device Manager, product selector,
	accessory selector, lens calculator
Languages	English, German, French, Spanish, Italian, Russian, Simplified
	Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese
Sustainability
Substance control	PVC free, BFR/CFR free in accordance with JEDEC/ECA Standard
	JS709
	RoHS in accordance with EU RoHS Directive 2011/65/EU/ and
	EN 63000:2018
	REACH in accordance with (EC) No 1907/2006. For SCIP UUID
Materials	Renewable carbon-based plastic content: 19% (biobased)
	Screened for conflict minerals in accordance with OECD
	guidelines
Environmental responsibility	axis.com/environmental-responsibility
	Axis Communications is a signatory of the UN Global Compact,
	read more at unglobalcompact.org

[/specifications] [accesories]

Optional accessories

• AXIS T8415 Wireless Installation Tool • AXIS Surveillance Cards • AXIS TQ3102 Pendant Kit • AXIS TQ3101-E Pendant Kit • AXIS TQ3201-E Recessed Mount • AXIS T94V01C Dual Camera Mount

[/accesories]

AXIS P3827-PVE Panoramic Camera (02450-001)

The AXIS P3827-PVE is a 7-megapixel multisensor camera that provides a unified video stream with 180-degree panoramic coverage, capturing high-resolution images with intricate details at a frame rate of up to 30 frames per second. This product offers a panoramic overview of large areas, encompassing 180 degrees horizontally and 90 degrees vertically, without any blind spots.

Quick Specs:

• 7 MP multisensor camera with one IP address
• 180 horizontal, 90 vertical coverage
• Seamlessly stitched realistic images
• Horizon straightening

Please see the related tabs for the 02450-001 datasheet and compatible accessories.

Feature	AXIS P3818-PVE	AXIS P3827-PVE
Max video resolution	5120x2560	3712x1856
Horizontal field of view	180	180
Vertical field of view	90	90
OptimizedIR	-	-
Day and Night functionality	✔	✔
Lightfinder	Lightfinder	Lightfinder
Wide dynamic range	Forensic WDR	Forensic WDR
Zipstream	✔	✔
Alarm inputs/outputs	2	2
Audio Support	✔	✔
Axis Edge Vault	✔	✔
