AXIS Q1656-DLE Radar-Video Fusion Camera (02420-001)

The AXIS Q1656-DLE Radar-Video Fusion Camera integrates video and radar analytics to enhance wide area intrusion protection with advanced detection and visualization capabilities. The AXIS Object Analytics feature combines deep learning for accurate object localization and classification, as well as radar-based distance and speed measurements to provide reliable 24/7 surveillance.

Quick Specs:

• Two powerful technologies in one device
• Increased scene intelligence
• Reliable detection 24/7
• Built-in cybersecurity features

Please see the related tabs for the 02420-001 datasheet and compatible accessories.

Feature	AXIS Q1615-LE Mk III	AXIS Q1656	AXIS Q1656-B	AXIS Q1656-BE	AXIS Q1656-BLE	AXIS Q1656-DLE	AXIS Q1656-LE	AXIS Q1686-DLE
Max video resolution H.264	1920x1080	2688x1512	2688x1512	2688x1512	2688x1512	2688x1512	2688x1512	2688x1512
Max frames per second	100/120	50/60	50/60	50/60	50/60	50/60	50/60	50/60
Image sensor size	1/2.8	1/1.8	1/1.8	1/1.8	1/1.8	1/1.8	1/1.8	1/1.8
Lens mount	CS	CS	CS	CS	CS	CS	CS	CS
Horizontal field of view	102 - 40	120 - 47	120 - 47	120 - 47	96 - 44	96 - 44	113 - 47	46.22 - 9.16
Alarm inputs/outputs	4	4	4	4	4	4	4	4
Lightfinder	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0
Zipstream	✔	✔	✔	✔	✔	✔	✔	✔
Two-way audio	✔	✔	✔	✔	✔	✔	✔	✔
TPM	✔	✔	✔	✔	✔	✔	✔	✔
Electronic image stabilization	✔	✔	✔	✔	✔	✔	✔	✔
Axis Edge Vault	✔	✔	✔	✔	✔	✔	✔	✔
Analytics compute capability	DLPU	DLPU	DLPU	DLPU	DLPU	DLPU	DLPU	DLPU
