Ubiquiti USW-PRO-XG-24-POE UniFi Switch 24xGE PoE+++

The Ubiquiti USW-PRO-XG-24-POE is a powerful 24-port managed Layer 3 switch designed for enterprise-grade networks demanding extreme bandwidth, advanced PoE delivery, and seamless performance. It offers a flexible port mix including 8x 2.5 GbE and 16x 10 GbE RJ45 ports—all PoE+++ capable—plus 2x 25G SFP28 uplinks. With a total non-blocking throughput of 230 Gbps, 720W PoE power budget, and Etherlighting™ smart port indicators, this switch is built for high-speed aggregation, AV applications, and future-ready deployments. Designed for rack mounting and backed by rich L2/L3 features, it supports VLANs, DHCP server/relay, inter-VLAN routing, static routes, QoS, and extensive ACL options.

Key Features:

• 24 x multi-gig PoE+++ RJ45 ports (8x 2.5GbE, 16x 10GbE)
• 2 x 25G SFP28 uplink ports for fiber connectivity
• Layer 3 switching with DHCP server, inter-VLAN routing, static routing
• Total PoE budget: 720W, supports PoE+++/PoE++/PoE+/PoE
• 460 Gbps switching capacity and 342 Mpps forwarding rate
• Etherlighting™ for intuitive port status indicators
• 1.3” touchscreen LCM display and DC power backup support
• Pro AV profiles including Dante, Q-SYS, NDI, Shure, and Crestron
• Enterprise security: ACLs, MAC/IP filtering, DHCP snooping, and 802.1X
• Designed for 1U rack mounting with internal power supply

Technical Specifications:

• Switching Capacity: 460 Gbps
• Non-Blocking Throughput: 230 Gbps
• Forwarding Rate: 342 Mpps
• PoE Support: PoE+/PoE++/PoE+++ (90W max per port)
• Total PoE Availability: 720W
• Ports: 8x 2.5 GbE RJ45, 16x 10 GbE RJ45, 2x 25G SFP28
• Layer 3 Routing: DHCP Server, Relay, Inter-VLAN, Static Routing
• MAC Table Size: 128,000 entries
• IPv4 Routes: 256,000
• Supported VLANs: 1,000
• Power Supply: Internal 870W AC/DC, 100–240V AC
• Max Power Consumption: 870W (with PoE), 150W (device only)
• ESD Protection: ±30kV air, ±20kV contact
• Operating Temperature: -5°C to 40°C
• Dimensions: 442 x 480 x 44 mm
• Weight: 7.9 kg (without brackets), 8.0 kg (with)
• Compliance: CE, FCC, IC, NDAA
