Ubiquiti USW-PRO-48-POE Switch
- Managed, 8 x Gigabit RJ45 802.3bt PoE++ ports, 40 x Gigabit RJ45 802.3at PoE+ ports, 4 x 10G SFP+ ports, Layer 2 and Layer 3 features, 600W maximum PoE power, UniFi SmartPower RPS DC input, Near-silent cooling, 1.3" touchscreen display, Managed with UniFi Network application
[properties]Ā
| Properties | USW-PRO-48-POE |
| Description | 48x Gigabit Ethernet ports, 4 SFP+ Ports, 40x POE+ IEEE 802.3af/at, 8x 60W PoE++ IEEE 802.3bt output ports |
| Product Family | UniFi Switch USW Pro PoE |
| Product Type | Switch Professional |
| Overview | |
| Total Non-Blocking Line Rate | 88 Gbps |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.944 Mpps |
| USW-PRO-48-POE provides these features: | ā¢ 3" LCM color touchscreen with AR switch management ā¢ (40) GbE, 802.3at PoE+ RJ45 ports ā¢ (8) GbE, 802.3bt PoE++ RJ45 ports ā¢ (4) 10G SFP+ ports ā¢ USP RPS DC input ā¢ 600W total PoE supply ā¢ Near-silent cooling ā¢ Layer 3 switching features |
[/properties] [specifications]Ā
| Specifications | USW-PRO-48-POE |
| DimensionsĀ | 442.4 x 399.6 x 43.7 mm (17.42 x 15.73 x 1.72") |
| Weight With Rackmount BracketsĀ |
6.25 kg (13.78 lb) 6.34 kg (13.98 lb) |
| Interfaces Ā Ā Ā Ā Ā Networking Ā Ā Ā Ā Ā Management |
(48) 10/100/1000 RJ45 Ports (4) 1/10G SFP+ Ethernet PortsĀ Ethernet In-Band |
| Power Method Ā Ā Ā Universal Input Ā Ā Ā USP RPS DC Input |
100-240VAC/50-60 Hz 52VDC, 11.54A; 11.5VDC, 5.22A |
| Power Supply | AC/DC, Internal, 660W |
| Supported Voltage Range | 100 to 240VAC |
| Max. Power Consumption (Excluding PoE Output) | 60W |
| LEDs System RJ45 Data Ports SFP+ Data Ports |
Status PoE; Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: Ā± 16 kV, Contact: Ā± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40Ā° C (23 to 104Ā° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| PoEĀ | |
| Total Available PoE | 600W |
| PoE Interfaces Ports 1-40Ā |
POE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-) |
| PoE Interfaces Ports 41-48 802.3af/at 802.3bt |
60W PoE++ IEEE 802.3af/at/bt (Pins 1, 2+; 3, 6-) (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-) |
| Max. PoE Wattage per Port by PSE 802.3at 802.3bt |
32W 64W |
| Voltage Range 802.3af ModeĀ | 44-57V |
| Voltage Range 802.3at/bt ModeĀ | 50-57V |
| Sound Level* | |
| 25% PoE Load, 25Ā° C Room Temperature |
0.9 dBr |
| 50% PoE Load, 25Ā° C Room Temperature |
7.3 dBr |
| 100% PoE Load, 40Ā° C | 22.5 dBr |
| * Background noise level: 27.5 dBa |
Ā [/specifications] [accesories] [/accesories]
Ubiquiti USW-PRO-48-POE Switch
The USW-PRO-48-PoE is a fully managed Layer 3 switch with 8x 802.3bt (PoE++) and 40x 802.3at (PoE+) Gigabit Ethernet ports. It also includes 4x 10G SFP+ uplinks supporting link aggregation for increased capacity and availability. This switch offers a comprehensive set of Layer 2 functionalities and incorporates Layer 3 features such as inter-VLAN routing, static routing, and DHCP server. It is designed to be the access layer switch for any UniFi solution, providing up to 600W of nearly silent PoE power and UniFi SmartPower RPS power redundancy.
Quick Specs:
- 48x 10/100/1000 Ethernet RJ45 Ports
- 4x 1/10G SFP+ ports
- Non-blocking throughput: 88 Gbps
- Switching Capacity: 176 Gbps
Please see the related tabs for the USW-PRO-48-POE datasheet and compatible accessories.
