• PoE+
• 8 Ports
• Industrial Ethernet
• Gigabit Ports

[/shortdesc]
[properties]

Properties	TSW200 SWITCH (TSW200000050)
Description	Teltonika TSW200 is an industrial unmanaged switch with 2 SFP ports, 8 Gigabit Ethernet ports (IEEE802.3af/at), perfect for high-bandwidth applications needing reliable data connection and power."
Product Family	Teltonika TWS Switches
Product Type	Switch
PoE standart	802.3af/at (up to 30 W per port, total power budget - 240 W)
Ethernet	8 x 10/100/1000 Mbps Ethernet ports
Fiber	2 x SFP ports
Housing	Aluminium housing with wall or DIN rail mounting option and grounding capability
Dimensions	132 x 44.2 x 95.1 mm
Weight	456 g
Mounting	DIN rail and surface mounting options
Input voltage range	7 - 57 VDC
Input voltage range for PoE	44 - 57 VDC
Power consumption (idle/max no PoE/max)	1.81 W /  5.5 W / 245.5 W

[/properties] [specifications]

Bandwidth	10 Gbps
Packet buffer	128 KB
MAC address table size	2K entries
Jumbo frame support	9216 bytes
Status LEDs	16 x Ethernet, 1 x Power, 2 x SFP activity
Ingress protection rating	IP30
Operating temperature	-40 °C to 75 °C
Operating humidity	10 % to 90 % non-condensing

[/specifications] [accesories] [/accesories]

The Teltonika TSW200 Industrial Ethernet Switch provides reliable networking with Gigabit ports. Designed for demanding industrial environments, it ensures robust performance and efficient data transmission. Choose the TSW200 for high-quality, reliable networking.
