Mikrotik SXT SA5 ac Antenna (RBSXTG-5HPacD-SA-US)

Product image 1
Product image 2

Mikrotik SXT SA5 ac Antenna (RBSXTG-5HPacD-SA-US)

Mikrotik SXT SA5 ac Antenna (RBSXTG-5HPacD-SA-US)

[shortdesc]
  • 802.11ac up to 540Mbit, high output, wide beamwidth sector antenna
[/shortdesc]

[properties]

Properties MikroTik SXT SA5 ac RBSXTG-5HPACD-SA-US
Description 802.11ac up to 540Mbit, high output, wide beamwidth sector antenna
Product Family SXT Series
Product Type Access Point
Features Extended temperature range -30C to +80C
• Up to 540Mbps throughput
• Low latency Point to Point
• Supports passive PoE and 802.3af/at PoE input (15-60V)
10/100/1000 Ethernet ports 1
Number of USB ports 1 USB type A
Extras PCB temperature monitor
Voltage Monitor
Beeper
Dimensions 140 x 140 x 56mm
Weight without packaging, adapters and cables 265g
Number of DC inputs 1 (PoE-IN)
Max power consumption 12 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 12-57 V

[/properties][specifications]

Specifications RBSXTG-5HPACD-SA-US
Memory 128 MB
NAND Storage size 128 MB
CPU QCA9557 720 MHz
CPU core count 1
OS RouterOS level 3 license
Wireless capabilities
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 14
Wireless 5 GHz chip model QCA9892
Wireless 5 GHz generation Wi-Fi 5
Wireless specifications
5 GHz
6MBit/s Transmit (dBm): 31
Receive Sensitivity: -96
54MBit/s Transmit (dBm): 28
Receive Sensitivity: -81
MCS0 Transmit (dBm): 30
Receive Sensitivity: -96
MCS7 Transmit (dBm): 27
Receive Sensitivity: -77
MCS9 Transmit (dBm): 22
Receive Sensitivity: -72
MTBF Approximately 200.000 hours at 25C
Temperature -40°C to 70°C tested
Certification CE, FCC, IC, EAC, ROHS
IP IP54

[/specifications][accesories]

24V 0.8A power adapter
Metal ring (one)
Gigabit PoE injector
Pole mounting bracket

[/accesories]

MikroTik RBSXTG-5HPacD-SA-US Antenna

The RBSXTG-5HPacD-SA model features a 90-degree wide beam-width sector antenna and is equipped to support 802.11ac mode. It is also compatible with all legacy RouterBOARD devices, including Nstream and Nv2 protocols, and includes a Gigabit Ethernet port. This product supports passive PoE and 802.3af/at PoE input (15-60V). The RBSXTG-5HpacD-Sar2-US (USA) is factory locked for 5170-5250 MHz and 5725-5835 MHz frequencies. This lock can not be removed due to country regulations.

Quick Specs:

  • 1x 10/100/1000 Ethernet Port
  • QCA9557, 1 core, 720MHz CPU
  • Low latency Point to Point
  • RouterOS

Please see the related tabs for the RBSXTG-5HPacD-SA-US datasheet and compatible accessories.

$48.12

Original: $137.50

-65%
Mikrotik SXT SA5 ac Antenna (RBSXTG-5HPacD-SA-US)—

$137.50

$48.12
