Cisco PWR-C2-640WAC Power Supply
- Power Supply (plug-in module)
- AC 100-240 V
- 640 Watt
- FRU
- for Catalyst 2960XR-24
- 2960XR-48
- 3650-24
- 3650-48
[specifications]
| Maximum output power | 640 W |
| Input voltage range and frequency | 640 W, 100 to 240 VAC (autoranging), 50 to 60 Hz |
| Input current | 8-4 A |
| Output ratings | 12 V @ 20.83 A, -54 [email protected] A |
| Total input BTU | 2371 BTUs per hour, 695 W |
| Total output BTU | 2183 BTUs per hour, 640 W |
| Storage temperature | -40 to 158 F (-40 to 70 C) |
| Relative humidity | 5 to 96% (noncondensing) |
| Altitude | AC power supply: Up to 16,400 feet (5,000 m) |
| Net Weight | 3.1 lb (1.41 kg) |
| Physical Specifications: Dimensions (H x W x D) | 1.58 x 3.75 x 11.75 in. (4.0 x 9.5 x 29.8 cm) |
[/specifications]
Cisco PWR-C2-640WAC Power Supply
The power supply Cisco PWR-C2-640WAC is intended for use with some switches of the Catalyst 2960 and 3650 Series. It can provide an output power of 640W and is constructed using high-quality materials to ensure dependable performance, even in challenging environments. This power supply is equipped with internal fans to prevent overheating.Ā
Key Features:
- 640W
- Input voltages 100 - 240 VAC
- For Catalyst 2960 and 3650 Series
For detailed specifications, refer to the Cisco PWR-C2-640WAC datasheet in the tabs.
