Palo Alto PA-7500-MPC-A Management Processing Card
[shortdesc]
QSFP28 logging 2x100G, QSFP-DD HA 2x400G, SFP28 mgmt 2x25G, RJ-45 & USB console, USB port
[/shortdesc]
[properties]
| Brand | Palo Alto Networks |
| Model | PA-7500-MPC-A |
| Product Type | Management Processing Card for PA-7500 Chassis |
| Form Factor | Modular Card (Chassis Component) |
| Compatible Chassis | PA-7500 Series |
| Cooling | Integrated with chassis cooling system |
[/properties] [specifications]
| Management I/O | 2 x QSFP28 logging ports (100 Gbps/40 Gbps), 2 x QSFP-DD HA ports (400 Gbps/100 Gbps), 2 x SFP28 management ports (1 Gbps/10 Gbps/25 Gbps), 1 x Combo RJ-45 console port, 1 x Micro USB console port, 1 x USB |
| Trusted Platform Module | Integrated TPM for secure boot, hardware root of trust, and securing system secrets |
| Supported Networking Features | Full Layer 3, tap, and virtual wire modes; IPv4/IPv6; NAT; VPN; VLAN; high availability clustering |
| Compatible Modules in Chassis | PA-7500-NPC-A, PA-7500-DPC-A, PAN-PA-7500-SFC-A |
| Certifications | cMETus, CB, FCC Class A, CE Class A, VCCI Class A |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Operating Humidity | 5% to 90% non-condensing |
[/specifications] [accesories]
| Installation Guide | Included in the box |
| Mounting Hardware | Included in the box |
| Console Cable | Included in the box |
[/accesories]
Advanced Management for High-Performance PA-7500 Deployments
The Palo Alto PA-7500-MPC-A is built to handle the command, control, and coordination of your PA-7500 chassis. Designed for high-throughput environments, it ensures efficient load distribution and maximizes reliability for mission-critical security operations.
Key Benefits & Features
- Centralized Management Control: Consolidates administrative and orchestration tasks for precise resource allocation and consistent policy enforcement.
- High-Speed Management I/O: Two QSFP28 logging ports (100/40 Gbps) and two QSFP-DD HA ports (400/100 Gbps) for rapid log ingestion and HA synchronization.
- Flexible Management Port Options: Two SFP28 management ports (1/10/25 Gbps), plus combo RJ-45 and micro USB console ports, and a USB Type-A port.
- Redundancy & Scalability: Supports multiple MPC-As in the same chassis for high availability and failover protection.
Ideal Use Cases
- Enterprise data centers requiring robust firewall management
- Service providers with multi-tenant PA-7500 deployments
- High-security environments needing rapid log ingestion
- Organizations with zero-tolerance for downtime
Technical Specifications
- Logging Ports: 2 × QSFP28 (100/40 Gbps)
- High Availability Ports: 2 × QSFP-DD (400/100 Gbps)
- Management Ports: 2 × SFP28 (1/10/25 Gbps)
- Console Access: 1 × RJ-45 combo port, 1 × micro USB console port
- USB Ports: 1 × USB Type-A
- Chassis Compatibility: Palo Alto PA-7500 Series
- Redundancy: Supports multi-card configurations
Power Your PA-7500 with Ultimate Control
Equip your Palo Alto PA-7500 chassis with the MPC-A to achieve seamless management, high-speed logging, and secure high availability. Order today for peak performance.
