[shortdesc]

• 13th Gen Intel Core i7-1360P processor
• Barebone model


[/shortdesc]

[properties]

Properties	Intel NUC 13 Pro - NUC13ANKi7 Mini PC
Description	The Intel NUC 13 NUC13ANKi7 is a compact and powerful Mini PC, featuring a high-performance the 13th Gen Intel Core i7 processor and 5.0GHz Turbo. Ideal for space-saving computing needs, it offers impressive processing capabilities and versatility.
Product Family	Intel NUC 13
Product Type	Mini PC
Graphics	Intel Iris® Xe Graphics
Graphics Output	2x HDMI 2.1 TMDS Compatible, 2x DP 1.4a via Type C
Numbers of Displays Supported	4
Numbers of Thunderbolt Ports	2x Thunderbolt 4
Numbers of USB Ports	4
USB Configuration	Front: 2x USB 3.2 Rear: 2x USB 4 (type C), 1x USB 3.2, 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22x42 (pins), 2x USB 2.0 (headers)
Serial Port via Internal Header	No
Audio (back channel + front channel)	Front panel: 3.5mm headphone/mic jack
Integrated LAN	Intel® Ethernet Controller i226-V
Wireless Included	Intel® Wi-Fi 6E AX211 (Gig+)
Bluetooth Version	5.3
M.2 Card Slot (wireless)	22x30 (E)
Additional Headers	Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector
DC Input Voltage Supported	12-20 VDC
Chassis Dimensions	117 x 112 x 37 mm
Board Form Factor	UCFF (4" x 4")

[/properties][specifications]

Processor	Intel® Core™ i7-1360P Processor (18M Cache, up to 5.00 GHz)
Total Cores	12
Total Threads	16
Max Turbo Frequency	5.00 GHz
Max Memory Size (dependent on memory type)	64 GB
Number of Memory Slots	2
Memory Types	DDR4-3200 1.2V SODIMMs
Max Numbers of Memory Channels	2
ECC Memory Supported	No
Internal Drive Form Factor	M.2 SSD
Number of Internal Drives Supported	2
M.2 Card Slot (storage)	22x80 NVMe (M); 22x42 SATA (B)
PCI Express Revision	Gen 4 (m.2 22x80 slot); Gen 3 (otherwise)
PCI Express Configurations	PCIe x4 Gen 4: M.2 22x80 (key M) PCIe x1 Gen 3: M.2 22x42 (key B) PCIe x1: M.2 22x30 (key E)
Supported Operating Systems	Windows 11 Home, Windows 11 Pro, Windows 10 IoT Enterprise, Red Hat Linux, Ubuntu
Advanced Technologies	Intel HD Audio Technology Intel Virtualization Technology for Directed I/O (VT-d)  Intel Virtualization Technology (VT-x)
Intel® Platform Trust Technology (Intel® PTT)	Yes
Intel® ME Firmware Version	16.1
Intel® AES New Instructions	Yes

[/specifications][accesories]

Included Accessories

VESA bracket

[/accesories]

Intel NUC13 (NUC13ANKI7) MINI PC

The Intel NUC 13 (NUC13ANKi7) Mini PC is a powerful and versatile computer that can be used for a variety of tasks, including gaming, content creation, and business applications. It is powered by a 13th Gen Core i7-1360P processor. This product has 10/100/1000/2500 Mbps RJ45 Ethernet port, 2x front and 1x rear USB 3.2 Gen 2 type A ports. This PC is an excellent choice for users who need a small, powerful, and portable computer. It is also an ideal choice for businesses that require a reliable and secure computer for their employees.

Quick Specs:

• Intel Core i7-1360 CPU (12 core, 5GHz)
• 2x ThunderBolt port
• 64 MB DDR4 RAM
• M.2 SSD

Please see the related tabs for the NUC13ANKi7 datasheet and compatible accessories.
