Properties	MikroTik LtAP LTE6 Kit (LtAP-2HnD&FG621-EA)
Description	The MikroTik LtAP LTE6 Kit (LtAP-2HnD&FG621-EA) is a compact, high-speed wireless access point designed for outdoor and indoor use. It offers LTE Category 6 support, dual-band Wi-Fi, and dual Ethernet ports for reliable internet connectivity in remote locations. Ideal for rural internet, surveillance, and IoT applications.
Product Family	MikroTik LtAP Wireless Access Point
Product Type	Access Point
Key Features	• Wireless access point with integrated LTE modem • LTE Category 6 support for high-speed connectivity • Dual-band Wi-Fi (2.4 GHz and 5 GHz) for versatile coverage • Dual Ethernet ports for flexible network setups • Compact and weatherproof design for outdoor use • Ideal for rural internet, surveillance, and IoT applications

[/properties] [specifications]

Specifications	MikroTik LtAP LTE6 kit (LtAP-2HnD&FG621-EA)
Product code	LtAP-2HnD&FG621-EA
CPU	Dual-core MT7621AT 880 MHz
CPU architecture	MMIPS
Size of RAM	128 MB
RAM type	DDR3
Storage	16 MB, Flash
Number of 1G Ethernet ports	1
MiniPCIe slots	2
SIM slots	3
USB port	1 USB 2.0 port type A
Wireless interface model	AR9382
Wireless	802.11b/g/n dual-chain
Antenna gain	2.5 dBi
GNSS	GPS / GLONAS / Galileo / Beidou
LTE modem	R11eL-FG621-EA
TAC	86335904
LTE Category	6 (300Mbit/s Downlink, 50Mbit/s Uplink)
MIMO DL	2x2
MIMO UL	1x1
LTE FDD bands	1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) /28 (700 MHz)
LTE TDD bands	38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
3G Category	R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G bands	1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
Dimensions	170 x 162 x 40 mm
Operating system	RouterOS v7 only, License level 4
Operating temperature	-40°C to +70°C
Certification & Approvals
Certification	CE, FCC, IC, E-MARK, EAC, ROHS
IP	IP54
Powering
Number of DC inputs	3 (PoE-In, Automotive, DC jack)
PoE-In Input Voltage	12-30 V
PoE-In Max current at Min voltage	1.48 A
PoE-In Max current at Max voltage	0.59 A
Automotive input Voltage	12-27 V
Automotive Max current at Min voltage	1.31 A
Automotive Max current at Max voltage	0.59 A
DC jack input Voltage	12-30 V
DC jack Max current at Min voltage	1.31 A
DC jack Max current at Max voltage	0.59 A
Power adapter nominal voltage	24 V
Power adapter nominal current	1.2 A
PoE-In	Passive PoE
Max power consumption without attachments	12 W
Max power consumption	24 W
Wireless specifications (2.4 GHz)
1MBit/s	Transmit (dBm): 25 Receive Sensitivity: -100
11MBit/s	Transmit (dBm): 25 Receive Sensitivity: -94
6MBit/s	Transmit (dBm): 26 Receive Sensitivity: -96
54MBit/s	Transmit (dBm): 23 Receive Sensitivity: -78
MCS0	Transmit (dBm): 26 Receive Sensitivity: -96
MCS7	Transmit (dBm): 22 Receive Sensitivity: -73
Supported 2xCA LTE bands
1+1/3/5/7/8/20/28	40+40
3+3/5/7/8/20/28	8+8
5+5/7	38+38
7+7/8/20/28	41+41
Included parts	• 24 V 1.2 A power adapter • Screw set • Automotive cable

[/specifications] [accesories] [/accesories]

The LtAP-2HnD&FG621-EA is a member of the MikroTik LtAP series. The LtAP LTE6 kit is furnished with an integrated CAT6 cellular modem that delivers rapid 4G (LTE) connectivity, enabling download speeds of up to 300 Mbps, thereby guaranteeing constant connectivity regardless of location. The LtAP LTE6 kit boasts a range of functionalities, including three Mini SIM slots that permit seamless switching between cellular service providers, ensuring optimal connectivity and serving as a backup in the event of provider disruptions. Additionally, the device is equipped with a Gigabit Ethernet port to accommodate wired devices, facilitating swift and dependable data transmission.

Quick Specs:

• MT7621AT, 2 core, 880 MHz CPU
• 128MB RAM
• 1x 10/100/1000 Ethernet port
• 3x SIM Slots (3 Modem – Mini SIM) – 2x miniPCI-e slots

Please see the related tabs for the LtAP-2HnD&FG621-EA datasheet and compatible accessories.
