[shortdesc] 48× 10/100/1000 RJ-45, 4× 1/10GbE SFP+, Layer 3 (static/RIP/Access OSPF), VSF 8-member stacking, 176 Gbps switching, 112 Mpps throughput [/shortdesc]

[properties]

Model	HPE Aruba Networking 2930F 48G 4SFP+ Switch (JL254A)
Product Type	Layer 3 stackable access switch
Ports	48× RJ-45 autosensing 10/100/1000
Uplink Ports	4× SFP+ 1/10GbE
Stacking	Up to 8-member VSF
Switching Capacity	176 Gbps
Throughput	Up to 112 Mpps
Latency	<3.8 μs (1 Gb); <1.6 μs (10 Gb)
Power Consumption (Max)	46.6 W
Heat Dissipation	157.2 BTU/hr (165.8 kJ/hr)
Input Voltage	100–127/200–240 VAC, rated
Dimensions (H × W × D)	4.39 × 44.25 × 24.63 cm
Weight	3.1 kg

[/properties]

[specifications]

Product Number	JL254A
Differentiator	Popular 52-port Gig + 10G access switch; 48× 10/100/1000 + 4× 1/10G SFP+
PHY	PHY-less
Processor / Memory	Dual-core ARM Cortex-A9 @ 1016 MHz; 1 GB DDR3 SDRAM; 4 GB eMMC
Packet Buffer	12.38 MB total (4.5 MB ingress / 7.875 MB egress)
Latency	<3.8 μs (1000 Mb); <1.6 μs (10 Gbps)
Throughput	Up to 112 Mpps
Switching Capacity	176 Gbps
Management (selected)	Aruba AirWave; Central (cloud); IMC; CLI; Web; Config menu; SNMP manager; Telnet; RMON1; FTP; Out-of-band mgmt (serial RS-232C or micro USB)
Stacking	Aruba Virtual Switching Framework (VSF), up to 8 members
Out-of-Band Ethernet Mgmt Port	Dedicated RJ-45 Ethernet interface for out-of-band management; no user/data traffic.
Input Voltage	100–127/200–240 VAC, rated
Max Power / Heat	46.6 W max; 157.2 BTU/hr
Dimensions / Weight	4.39 × 44.25 × 24.63 cm; 3.1 kg

[/specifications]

[accesories]

Optional	Transceivers
Optional	Mounting / Other

[/accesories]

High-Performance Layer 3 Access for Modern Edge Networks

The HPE Aruba Networking 2930F 48G 4SFP+ Switch (JL254A) delivers enterprise-grade Layer 3 access with simple deployment and unified management. Built on Aruba’s ProVision ASIC, it provides low latency, robust QoS, and automation-ready interfaces to scale campus, SMB, and branch networks without extra software licenses. Virtual Switching Framework (VSF) enables up to eight switches to operate as one for resilient, easy-to-manage stacks.

Key Benefits & Features

• Enterprise Layer 3: Supports static routing, RIP, and Access OSPF to segment and scale networks efficiently.
• High-speed uplinks: Four 1/10GbE SFP+ slots provide flexible fiber uplinks for aggregation or core connectivity.
• VSF stacking: Combine up to 8 members into a single logical device for simplified operations and failover resilience.
• Performance ASIC: ProVision architecture delivers low latency, deep buffers, and SDN optimizations for busy edges.
• Operations ready: Zero-Touch Provisioning, Aruba Central/AirWave support, and REST/OpenFlow APIs streamline rollouts and monitoring.

Ideal Use Cases

• Enterprise access layers needing reliable Layer 3 segmentation and 10G uplinks.
• Branch or retail sites consolidating multiple switches into a resilient VSF stack.
• Education and healthcare networks requiring simple, license-free advanced features.
• SMBs standardizing on Aruba Central or AirWave for unified wired/wireless management.

Technical Specifications

• Model / SKU: JL254A
• Access Ports: 48× RJ-45 autosensing 10/100/1000
• Uplinks: 4× SFP+ 1/10GbE
• Switching Capacity: 176 Gbps
• Forwarding Throughput: Up to 112 Mpps
• Latency: <3.8 μs (1G), <1.6 μs (10G)
• Stacking: VSF up to 8 members
• Management: CLI, Web GUI, SNMP, AirWave, Aruba Central, ZTP
• Power Consumption (Max): 46.6 W
• Dimensions / Weight: 4.39 × 44.25 × 24.63 cm; 3.1 kg

Boost your edge with proven Aruba performance

Equip your access layer with a fast, stackable Layer 3 switch that’s easy to deploy and manage. Request a quote or order today.
