[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 6 (802.11ax) and 128 GB onboard SSD, powered by SP4 ASIC, delivering up to 10/10/7 Gbps firewall throughput and featuring 2x GE SFP/RJ45 shared media ports for flexible WAN connectivity[/shortdesc]

[properties]

SKU	FWF-81F-2R-A
Form Factor	Desktop/Wall Mount/Rack Tray
Wireless Standard	802.11a/b/g/n/ac/ax (Wi-Fi 6)
Internal Storage	1x 128 GB SSD
Firewall Throughput	10/10/7 Gbps (1518/512/64 byte UDP)
Interfaces	8x GE RJ45 ports (6x GE RJ45 internal + 2x GE RJ45 FortiLink, default) and 2x GE RJ45/SFP shared media pairs (WAN)
Dimensions (H x W x L)	60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
Weight	1.5 kg (3.3 lbs)
Power Input	12V DC, 5A (dual redundancy optional)

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance & Capacity
IPv4 Firewall Throughput	10/10/7 Gbps (1518/512/64 byte UDP)
Firewall Latency	3.23 μs
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	45,000
Firewall Policies	5,000
IPsec VPN Throughput	6.5 Gbps
SSL-VPN Throughput	950 Mbps
SSL Inspection Throughput	715 Mbps
Wireless Specifications
Radio	Dual WiFi Radio (5 GHz, 2.4 GHz) 802.11a/b/g/n/ac/ax + 1 Scanning Radio
MU-MIMO	2x2
Max WiFi Speeds	574 Mbps @ 2.4 GHz, 1201 Mbps @ 5 GHz
Antenna Ports (SMA)	3
Hardware Specifications
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 Internal Ports	6
GE RJ45 FortiLink Ports (Default)	2
USB Ports 3.0	1
Console (RJ45)	1
Trusted Platform Module (TPM)	Yes
Environment & Power
Power Consumption (Avg / Max)	24.79 W / 30.29 W
Heat Dissipation	103.29 BTU/h
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	24.14 dBA
Operating Altitude	Up to 7400 ft (2250 m)
Certifications
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FWF80F-PDC-5), SFP Transceiver Modules (FN-TRAN-GC, FN-TRAN-SX, FN-TRAN-LX, FR-TRAN-ZX)

[/accesories]

High-Performance Wi-Fi 6 Security with Onboard Storage

The FortiWiFi 81F-2R (FWF-81F-2R-A) is an advanced Secure SD-WAN appliance featuring 1x 128 GB internal SSD storage, making it ideal for distributed enterprises that require onboard storage for local data and reporting workflows. Built on the high-performance SP4 ASIC, it delivers IPv4 firewall throughput up to 10/10/7 Gbps (1518/512/64 byte UDP) and integrated dual-band Wi-Fi 6 (802.11ax) connectivity.

This model is designed for secure branch transformation, offering deployment flexibility with 2x GE RJ45/SFP shared media pairs for fiber or copper uplinks. The combination of onboard SSD storage, accelerated performance, and integrated Wi-Fi 6 helps deliver unified protection and reliable connectivity across the network edge.

Key Benefits

• 128GB Onboard SSD: 1x 128 GB internal SSD for onboard storage needs such as local data retention and reporting workflows.
• High-Speed Wi-Fi 6: Integrated dual-band 802.11ax wireless with a dedicated scanning radio for secure, high-speed access.
• Flexible WAN Uplinks: Includes 2x GE RJ45/SFP shared media pairs for adaptable fiber or copper WAN connectivity.
• Powered by SP4 ASIC: Delivers IPv4 firewall throughput up to 10/10/7 Gbps (1518/512/64 byte UDP) and accelerates IPsec VPN throughput up to 6.5 Gbps.
• SD-Branch Ready: Includes 2x GE RJ45 FortiLink ports (default) to converge security and access by integrating FortiSwitch and FortiAP.
• Trusted Platform Module (TPM): Hardware-backed security for cryptographic key protection and device integrity.

Ideal Use Cases

• Retail & Branch Offices: Secure connectivity with centralized management support and onboard storage capability for operational visibility needs.
• Small to Medium Businesses (SMB): All-in-one networking, security, Wi-Fi, and storage solution that reduces hardware footprint.
• Remote Work: Enterprise-grade protection and reliable Wi-Fi connectivity for home or small office deployments.

Technical Specifications Summary

• IPv4 Firewall Throughput: 10/10/7 Gbps (1518/512/64 byte UDP)
• IPS Throughput: 1.4 Gbps
• NGFW Throughput: 1 Gbps
• Threat Protection Throughput: 900 Mbps
• IPsec VPN Throughput (512 byte): 6.5 Gbps
• SSL-VPN Throughput: 950 Mbps
• Wireless: Dual WiFi Radio (2.4 GHz & 5 GHz) 802.11a/b/g/n/ac/ax + 1 Scanning Radio; MU-MIMO 2x2
• Max Wi-Fi Speeds: 574 Mbps @ 2.4 GHz; 1201 Mbps @ 5 GHz
• Interfaces: 2x GE RJ45/SFP shared media pairs; 6x GE RJ45 internal ports; 2x GE RJ45 FortiLink ports (default)
• Internal Storage: 1x 128 GB SSD
• Power: 12V DC, 5A input; 24.79 W / 30.29 W (average / maximum)
• Physical & Environment: 60 x 216 x 178 mm; 1.5 kg; operating 0°C to 40°C; noise level 24.14 dBA; compliance FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB; USGv6/IPv6

Upgrade Your Network Security

Enhance your branch capabilities with the storage-equipped FortiWiFi 81F-2R today.
