[shortdesc] Secure SD-WAN appliance with integrated Wi-Fi 6, embedded 3G/4G LTE, 128 GB onboard SSD, and 8x PoE+ ports with a 96W power budget, delivering up to 10/10/7 Gbps firewall throughput. [/shortdesc]

[properties]

SKU	FWF-81F-2R-3G4G-POE-A
Form Factor	Desktop / Wallmount (optional)
Wireless Standard	802.11a/b/g/n/ac/ax (Wi-Fi 6) + 1 Scanning Radio
Internal Storage	1x 128 GB SSD
PoE Power Budget	96W
WAN Interfaces	Embedded 3G/4G/LTE modem (dual Nano SIM), 2x GE RJ45/SFP Shared Media Pairs
IPv4 Firewall Throughput	10/10/7 Gbps (1518/512/64 byte UDP)
Dimensions (H x W x L)	60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
Weight	1.6 kg (3.5 lbs)
Noise Level	31.56 dBA

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance & Capacity
Firewall Latency	3.23 μs
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	45,000
Firewall Policies	5,000
IPsec VPN Throughput	6.5 Gbps
SSL-VPN Throughput	950 Mbps
SSL Inspection Throughput	715 Mbps
Wireless Specifications
Wireless Interface	Dual WiFi Radio (5 GHz, 2.4 GHz) 802.11a/b/g/n/ac/ax + 1 Scanning Radio
Antenna Ports (SMA)	6
Hardware Specifications
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 PoE/+ Ports	6
GE RJ45 PoE/+ FortiLink Ports (Default)	2
Cellular Modem	3G/4G LTE
SIM Slots (Nano SIM)	2
USB Ports 3.0	1
Console (RJ45)	1
Trusted Platform Module (TPM)	Yes
Environment & Power
Power Consumption (Average / Maximum)	98 W / 137 W
Heat Dissipation	467.5 BTU/h
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Operating Altitude	Up to 7400 ft (2250 m)
Certifications
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG80E-POE-PDC), Transceivers: FN-TRAN-GC, FN-TRAN-SX, FN-TRAN-LX, FR-TRAN-ZX

[/accesories]

Consolidated SD-Branch Security with PoE, 4G LTE, and Onboard Storage

The FortiWiFi 81F-2R-3G4G-POE (FWF-81F-2R-3G4G-POE-A) is the ultimate convergence appliance for branch offices, combining network security, switching, wireless access, and multi-WAN redundancy. The appliance features 8x PoE+ ports with a 96W budget, enabling simplified deployment of connected devices like IP phones and access points. It includes 128GB of SSD storage for local logging and reporting. Powered by the specialized SD-WAN ASIC, it delivers high-performance IPv4 firewall throughput up to 10/10/7 Gbps and accelerates deep security inspection.

The integrated dual-band Wi-Fi 6 radio and embedded 3G/4G/LTE cellular modem provide both high-speed local access and reliable WAN failover, ensuring business continuity without needing external modems or injectors.

Key Benefits

• Built-in PoE+ Switching: Features 8x GE RJ45 PoE+ ports (including 2x dedicated FortiLink ports) with a 96W total budget, reducing cabling and complexity for powering access points and VOIP phones.
• 128GB Onboard SSD: Dedicated internal storage for local logging, reporting, and operational visibility at the branch edge.
• Embedded 4G LTE WAN: Provides automatic failover via an integrated 3G/4G/LTE cellular modem with dual Nano SIM slots, ensuring robust WAN redundancy and uptime.
• High-Performance Wi-Fi 6: Features built-in dual-band 802.11ax wireless with a dedicated scanning radio for secure, high-speed wireless access.
• Accelerated SD-WAN & Security: Custom SPU delivers up to 10/10/7 Gbps IPv4 firewall throughput and 6.5 Gbps IPsec VPN throughput for secure direct internet access.
• SD-Branch Ready: Uses 2x GE RJ45 PoE+ FortiLink ports to converge security and manage downstream FortiSwitch and FortiAP devices from a single console.

Ideal Use Cases

• Consolidated Branch Office: Ideal for locations requiring PoE functionality and cellular failover for critical business applications.
• Retail and Kiosks: Centralized security and power distribution for POS terminals, digital signage, and surveillance cameras in compact environments.
• Remote Sites: Ensures maximum uptime and security in environments where primary wired WAN links may be unreliable.

Technical Specifications Summary

• IPS Throughput (Enterprise Mix): 1.4 Gbps
• NGFW Throughput (Enterprise Mix): 1 Gbps
• Threat Protection Throughput (Enterprise Mix): 900 Mbps
• IPv4 Firewall Throughput (1518/512/64 byte UDP): 10/10/7 Gbps
• IPsec VPN Throughput (512 byte): 6.5 Gbps
• SSL-VPN Throughput: 950 Mbps
• Internal Storage: 1x 128 GB SSD
• PoE Power Budget: 96W (8x PoE+ ports total)
• Wireless Interface: Dual WiFi Radio (2.4 GHz/5 GHz) 802.11a/b/g/n/ac/ax + 1 Scanning Radio
• Form Factor: Compact Desktop or Wall Mountable
• Dimensions (H x W x L): 60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
• Noise Level: 31.56 dBA

Upgrade Your Network Security

Simplify and secure your branch with the converged FortiWiFi 81F-2R-3G4G-POE for high-performance protection and connectivity.
