[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 6 (802.11ax) and 2x GE SFP/RJ45 shared media ports, powered by SP4 ASIC, delivering up to 10/10/7 Gbps firewall throughput for flexible branch connectivity [/shortdesc]

[properties]

SKU	FWF-80F-2R-A
Form Factor	Desktop/Wall Mount/Rack Tray
Wireless Standard	802.11a/b/g/n/ac/ax (Wi-Fi 6)
Firewall Throughput	10/10/7 Gbps (1518/512/64 byte UDP)
Interfaces	2x GE RJ45/SFP Shared Media Pairs, 6x GE RJ45 Internal Ports, 2x GE RJ45 FortiLink Ports (Default)
Dimensions (H x W x L)	60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
Weight	1.5 kg (3.3 lbs)
Power Input	12V DC, 5A (dual redundancy optional)

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance & Capacity
Firewall Latency	3.23 μs
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	45,000
Firewall Policies	5,000
IPsec VPN Throughput	6.5 Gbps
SSL-VPN Throughput	950 Mbps
SSL Inspection Throughput	715 Mbps
Wireless Specifications
Radio	Dual WiFi Radio (5 GHz, 2.4 GHz) 802.11a/b/g/n/ac/ax + 1 Scanning Radio
MU-MIMO	2x2
Max WiFi Speeds	574 Mbps @ 2.4 GHz, 1201 Mbps @ 5 GHz
Antenna Ports	3x SMA (External)
Hardware Specifications
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 Internal Ports	6
GE RJ45 FortiLink Ports (Default)	2
USB Ports	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Environment & Power
Power Consumption (Avg / Max)	22.9 W / 27.9 W
Heat Dissipation	95.26 BTU/h
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	24.14 dBA
Certifications
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FWF80F-PDC-5), 1 GE SFP RJ45 Transceiver Module (FN-TRAN-GC), 1 GE SFP SX Transceiver Module (FN-TRAN-SX), 1 GE SFP LX Transceiver Module (FN-TRAN-LX), 1GE SFP Transceiver 90km Range (FR-TRAN-ZX)

[/accesories]

Integrated SFP, Wi-Fi 6, and Secure SD-WAN for Branch Offices

The FortiWiFi 80F-2R (FWF-80F-2R-A) is a high-performance desktop firewall designed for modern branch environments that require flexible connectivity and integrated wireless. Powered by the Fortinet SP4 ASIC, it delivers consistent firewall performance while combining wired, fiber-ready, and Wi-Fi 6 networking in a compact form factor.

With 2x GE RJ45/SFP shared media pairs, the FortiWiFi 80F-2R supports both copper and fiber uplinks, enabling adaptable WAN and LAN deployment options. Integrated dual-band Wi-Fi 6 with a dedicated scanning radio provides reliable wireless access while supporting secure network operations across distributed sites.

Key Benefits

• Flexible SFP Connectivity: Two GE RJ45/SFP shared media pairs support copper or fiber connections for adaptable network design.
• Integrated Wi-Fi 6: Dual-band 802.11ax wireless with an additional scanning radio delivers high-speed and resilient wireless access.
• Powered by SP4 ASIC: Hardware acceleration enables consistent firewall and SD-WAN performance for branch deployments.
• SD-Branch Ready: Includes two GE RJ45 FortiLink ports (default) to extend network connectivity to access-layer devices.
• Compact Deployment Options: Desktop, wall-mount, or rack-tray installation flexibility for space-constrained environments.
• Hardware-Based Security: Integrated Trusted Platform Module (TPM) enhances device integrity and cryptographic protection.

Ideal Use Cases

• Branch Offices: Consolidates wired, fiber, and wireless connectivity into a single edge device.
• Retail Locations: Supports flexible WAN options and reliable Wi-Fi connectivity for distributed sites.
• Small to Medium Businesses: Enterprise-grade firewall hardware with integrated Wi-Fi 6 in a compact form factor.

Technical Specifications Summary

• Firewall Throughput (UDP): 10/10/7 Gbps (1518/512/64 byte)
• IPS Throughput: 1.4 Gbps
• NGFW Throughput: 1 Gbps
• Threat Protection Throughput: 900 Mbps
• IPsec VPN Throughput (512 byte): 6.5 Gbps
• SSL-VPN Throughput: 950 Mbps
• Wireless: Dual Wi-Fi radio (2.4 GHz and 5 GHz) with 802.11a/b/g/n/ac/ax support plus a dedicated scanning radio
• Interfaces: 2x GE RJ45/SFP shared media pairs, 6x GE RJ45 internal ports, 2x GE RJ45 FortiLink ports (default)
• Physical: 60 x 216 x 178 mm, 1.5 kg

Upgrade Your Network Infrastructure

Deploy flexible wired and wireless connectivity at the network edge with the FortiWiFi 80F-2R.
