Fortinet FortiWiFi FWF-70G-POE-A Secure SD-WAN Firewall
[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 6 (802.11ax) and 4x PoE+ ports, powered by SP5 ASIC, delivering up to 10 Gbps firewall throughput for branch deployments [/shortdesc]
[properties]
| SKU | FWF-70G-POE-A |
| Form Factor | Desktop |
| Wireless Standard | 802.11 a/b/g/n/ac/ax (Wi-Fi 6) |
| PoE Interfaces | 4x GE RJ45 PoE/+ Ports |
| Firewall Throughput | 10 Gbps |
| Interfaces | 2x GE WAN, 4x GE Internal, 4x GE PoE/+, 1x USB, 1x Console |
| Dimensions (H x W x L) | 40.5 x 216 x 160 mm (1.6 x 8.5 x 6.3 inches) |
| Weight | 1.07 kg (2.36 lbs) |
| Power Input | Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) | |
| IPS Throughput | 2.5 Gbps |
| NGFW Throughput | 1.5 Gbps |
| Threat Protection Throughput | 1.3 Gbps |
| System Performance & Capacity | |
| Firewall Latency | 2.46 μs |
| Concurrent Sessions (TCP) | 1.4 Million |
| New Sessions/Second (TCP) | 100,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput | 7.1 Gbps |
| SSL Inspection Throughput | 1.4 Gbps |
| Wireless Specifications | |
| Radio | Dual Radio (2.4 GHz / 5 GHz) |
| Antenna Ports | 3x SMA (External) |
| Hardware Specifications | |
| USB Port | 1x USB Port |
| Console Port | 1x RJ45 Console Port |
| Total Available PoE Power Budget | 60 W |
| Environment & Power | |
| Power Consumption (Avg / Max) | 74.9 W / 77.7 W |
| Heat Dissipation | 264.96 BTU/hr |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Noise Level | 17.75 dBA |
| Certifications | |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | USGv6/IPv6 |
[/specifications]
[accesories]
| Optional Accessories | Rack Mount Tray (SP-RACKTRAY-02), Mounting Ear Bracket (SP-EAR-FG90G-10), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG50G-POE-PDC-5), AC Power Adaptor (SP-FG60E-PDC-5) |
[/accesories]
Integrated PoE+ and Wi-Fi 6 Security
The FortiWiFi 70G-POE (FWF-70G-POE-A) streamlines branch office networking by combining high-speed security, Wi-Fi 6 connectivity, and Power over Ethernet (PoE) capabilities into a single device. Powered by the Fortinet SP5 ASIC, it delivers up to 10 Gbps firewall throughput while providing a total PoE budget of 60W to power devices such as IP phones, cameras, or additional access points directly from the firewall.
This consolidated appliance reduces hardware clutter and simplifies management via FortiOS. With its integrated dual-band Wi-Fi 6 radio and Secure SD-WAN capabilities, the FWF-70G-POE ensures robust, high-performance connectivity for users and IoT devices alike.
Key Benefits
- Integrated PoE+ Ports: Features 4x GE RJ45 PoE/+ ports with a total 60W budget to power downstream peripherals, reducing cabling and switch requirements.
- Powered by SP5 ASIC: Achieves up to 10 Gbps firewall throughput and up to 7.1 Gbps IPsec VPN throughput for bottleneck-free performance.
- Integrated Wi-Fi 6: Built-in 802.11ax dual-radio access point provides secure, high-speed wireless coverage.
- Secure SD-WAN: Unified SD-WAN functionality optimizes application performance and secures direct internet access.
- Unified Management: Manages security, Wi-Fi, switching, and PoE power from a single pane of glass.
- Compact & Quiet: Desktop form factor with low noise output (17.75 dBA) suitable for office environments.
Ideal Use Cases
- Retail Branches: Powers POS systems, cameras, or IP phones while providing secure Wi-Fi and SD-WAN connectivity.
- Small Offices: All-in-one networking solution that eliminates the need for separate switches, access points, and power injectors.
- Distributed Enterprises: Scalable, secure connectivity with centralized management for remote locations.
Technical Specifications Summary
- Firewall Throughput: 10 Gbps (1518/512/64 byte UDP)
- IPS Throughput: 2.5 Gbps
- NGFW Throughput: 1.5 Gbps
- Threat Protection Throughput: 1.3 Gbps
- IPsec VPN Throughput: 7.1 Gbps (512 byte)
- SSL Inspection Throughput: 1.4 Gbps (IPS, avg. HTTPS)
- Concurrent Sessions (TCP): 1.4 Million
- New Sessions/Second (TCP): 100,000
- Total PoE Budget: 60W (max 30W per PoE/+ port)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
Upgrade Your Network Security
Simplify your branch deployment with the power and versatility of the FortiWiFi 70G-POE.
