[shortdesc] WiFi 5 firewall, 10x GE ports, 1 Gbps NGFW, SD WAN, IPS 1.4 Gbps, fanless desktop [/shortdesc]

[properties]

Model	Fortinet FortiWiFi 60F
SKU	FWF-60F-A-BDL-950-12
Product Type	Security Appliance Firewall
Form Factor	Desktop
Wi-Fi Standard	Wi-Fi 5 (802.11a/b/g/n/ac Wave 2)
Wireless Bands	2.4 GHz, 5 GHz
Interfaces	2 x GE RJ45 WAN, 1 x GE RJ45 DMZ, 5 x GE RJ45 Internal, 2 x GE RJ45 FortiLink, 1 x USB, 1 x Console
Firewall Throughput	10 Gbps
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	700 Mbps
VPN Throughput	IPSec: 6.5 Gbps, SSL: 900 Mbps
Concurrent Sessions	700,000
New Sessions Per Second	35,000
Max Wi-Fi Speed	1300 Mbps (5 GHz), 450 Mbps (2.4 GHz)
Power Consumption	17.2 W
Power Supply	External DC Power Adapter 100–240V AC
Dimensions (H x W x D)	38.5 x 216 x 160 mm
Weight	1.01 kg
Operating Temperature	0 C to 40 C
Humidity	10% to 90% non-condensing

[/properties]

[specifications]

Processor	Fortinet FortiASIC SOC4
Operating System	FortiOS
Encryption	SSL, TLS 1.3
Data Link Protocols	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a/b/g/n/ac
Firewall Latency	3.3 us
Firewall Throughput (Packets)	9 Mpps
SSL Inspection Throughput	630 Mbps
SSL Inspection CPS	400
SSL Inspection Sessions	55,000
Application Control Throughput	1.8 Gbps
CAPWAP Throughput	8 Gbps
Max FortiAP Support	64 (32 tunnel mode)
Max FortiSwitch Support	24
Max FortiToken Support	500
Virtual Domains	10
High Availability	Active-Active, Active-Passive
Wireless MIMO	3x3
Max TX Power	20 dBm
Antenna Gain	3.5 dBi (5 GHz), 5 dBi (2.4 GHz)
Certifications	FCC, CE, UL, CB, VCCI

[/specifications]

[accesories]

Optional – Rack Mount	SP-RACKTRAY-02 Rack Mount Tray
Optional – Power Adapter	SP-FG60E-PDC-5 AC Power Adapter
Optional – Wall Mount	SP-FG60F-MOUNT-20 Wall Mount Kit

[/accesories]

Secure Branch Networks with Integrated Firewall and WiFi

The Fortinet FortiWiFi 60F (FWF-60F-A-BDL-950-12) delivers enterprise-grade security, SD-WAN, and wireless connectivity in a single compact appliance. Built on Fortinet’s SPU-powered architecture and FortiOS, it provides high-performance threat protection while simplifying network operations for distributed businesses and branch offices.

Key Benefits & Features

• Integrated NGFW and SD-WAN: Combines firewall, SD-WAN, and routing capabilities to optimize traffic and secure WAN connectivity from a single platform.
• WiFi 5 Connectivity: Built-in dual-band 802.11ac Wave 2 wireless supports up to 1300 Mbps at 5 GHz for reliable office connectivity.
• High Performance Security: Delivers up to 1 Gbps NGFW throughput and 1.4 Gbps IPS performance for real-time threat detection and prevention.
• Fortinet SPU Acceleration: Purpose-built ASIC technology enhances throughput, reduces latency, and improves energy efficiency compared to CPU-based firewalls.
• Unified Security Fabric: Seamlessly integrates with Fortinet Security Fabric and FortiGuard services for AI-driven threat intelligence and centralized control.

Ideal Use Cases

• Branch offices requiring secure SD-WAN and wireless connectivity
• Small to mid-sized businesses deploying all-in-one firewall solutions
• Retail locations with integrated WiFi and network security
• Distributed enterprises needing centralized security management
• Organizations implementing hybrid work and secure remote access

Technical Specifications

• Firewall Throughput: Up to 10 Gbps
• NGFW Throughput: 1 Gbps
• IPS Throughput: 1.4 Gbps
• Threat Protection: 700 Mbps
• VPN Throughput: 6.5 Gbps IPsec
• Interfaces: 10x GE RJ45 (2 WAN, 1 DMZ, 7 internal)
• Wireless: 802.11 a/b/g/n/ac Wave 2 dual-band
• Concurrent Sessions: 700,000
• Form Factor: Desktop, fanless design
• Management OS: FortiOS with centralized control

Upgrade Your Network Security Today

Deploy advanced protection and seamless connectivity with Fortinet FortiWiFi 60F. Order now to secure your network infrastructure.
