[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 5, powered by SoC4 ASIC, delivering up to 10 / 10 / 6 Gbps firewall throughput and including a 1-Year Enterprise Protection bundle [/shortdesc]

[properties]

SKU	FWF-60F-A-BDL-809-12
Form Factor	Desktop
Wireless Standard	802.11 a/b/g/n/ac-W2 (WiFi 5)
Firewall Throughput	10/10/6 Gbps (1518/512/64 byte UDP packets)
Interfaces	2x GE WAN, 1x GE DMZ, 2x GE FortiLink, 5x GE Internal
Dimensions (H x W x L)	38.5 x 216 x 160 mm (1.5 x 8.5 x 6.3 inches)
Weight	1.01 kg (2.23 lbs)
Power Input	12Vdc, 3A (External Adapter)
Bundle Included	1 Year Enterprise Protection (FortiCare Premium Services included; curated FortiGuard AI-Powered Security services)

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	700 Mbps
System Performance & Capacity
IPv4 Firewall Throughput	10/10/6 Gbps (1518/512/64 byte UDP packets)
Firewall Latency	3.3 μs
Concurrent Sessions (TCP)	700,000
New Sessions/Second (TCP)	35,000
Firewall Policies	2,000
IPsec VPN Throughput	6.5 Gbps
SSL-VPN Throughput	900 Mbps
SSL Inspection Throughput	630 Mbps
Wireless Specifications
Radio	Single Radio (2.4GHz/5GHz)
MIMO	3x3
Max WiFi Speeds	1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz
Antenna Gain	3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz
Hardware Specifications
USB Port	1x USB Port
Console Port	1x RJ45 Console Port
Environment & Power
Power Consumption (Avg / Max)	17.2 W / 18.7 W
Heat Dissipation	63.8 BTU/hr
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	Fanless 0 dBA
Certifications
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Rack Mount Tray (SP-RACKTRAY-02), AC Power Adaptor (SP-FG60E-PDC-5), Wall Mount Kit (SP-FG60F-MOUNT-20)

[/accesories]

High-Performance Security with Enterprise Protection

The FortiWiFi 60F (FWF-60F-A-BDL-809-12) sets a new standard for desktop security appliances with its purpose-built SoC4 SD-WAN ASIC. This 1-Year Enterprise Protection bundle strengthens defense-in-depth with FortiCare Premium Services and FortiGuard AI-Powered Security services.

Delivering up to 10 Gbps firewall throughput, the FWF-60F ensures that security never becomes a bottleneck. The integrated 802.11 a/b/g/n/ac-W2 Wi-Fi eliminates the need for separate access points, while the fanless design allows for silent operation in noise-sensitive environments like retail stores and branch offices.

Key Benefits

• 1-Year Enterprise Protection: Includes FortiCare Premium Services and FortiGuard AI-Powered Security services for enterprise-grade protection.
• Powered by SoC4 ASIC: Delivers industry-leading performance with 10 Gbps firewall throughput and 6.5 Gbps IPsec VPN throughput.
• Integrated Wireless: Built-in 802.11 a/b/g/n/ac-W2 Wi-Fi with 3x3 MIMO technology provides reliable, high-speed wireless connectivity.
• Fanless Operation: Silent 0 dBA noise level ensures suitability for desktop use in open office environments.
• Unified Management: Consolidates SD-WAN, NGFW, and Wi-Fi management into a single console, reducing operational complexity.
• Secure SD-WAN: Delivers application-aware steering and fast application identification and application-aware steering for optimized performance.

Ideal Use Cases

• Small & Medium Business: All-in-one enterprise-grade security and Wi-Fi solution without the complexity of multiple devices.
• Branch Offices: Secure SD-WAN connectivity with integrated wireless for direct internet access and cloud applications.
• Retail Environments: Reliable connectivity for POS systems and guest Wi-Fi, protected by advanced threat intelligence.

Technical Specifications Summary

• Firewall Throughput: 10/10/6 Gbps (1518/512/64 byte UDP packets)
• IPS Throughput (Enterprise Mix): 1.4 Gbps
• NGFW Throughput: 1 Gbps
• Threat Protection Throughput: 700 Mbps
• IPsec VPN Throughput (512 byte): 6.5 Gbps
• SSL Inspection Throughput (IPS, avg. HTTPS): 630 Mbps
• Concurrent Sessions (TCP): 700,000
• New Sessions/Second (TCP): 35,000
• Wireless: Single radio (2.4GHz/5GHz) 802.11 a/b/g/n/ac-W2, 3x3 MU-MIMO; max 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz
• Interfaces: 10x GE RJ45 (2x WAN, 1x DMZ, 2x FortiLink, 5x Internal), 1x USB, 1x RJ45 Console
• Power & Form Factor: 12Vdc, 3A; 17.2 W avg / 18.7 W max; fanless 0 dBA

Upgrade Your Network Security

Secure your business with the high-performance FortiWiFi 60F and 1-Year Enterprise Protection bundle today.
