[shortdesc] Secure SD-WAN firewall with integrated 802.11ac Wi-Fi, fanless desktop form factor, 5 Gbps firewall throughput, up to 600 Mbps threat protection, including 3-year FortiGuard Enterprise Protection bundle [/shortdesc]

[properties]

SKU	FWF-40F-A-BDL-809-36
Form Factor	Desktop (Fanless)
Wireless Standard	802.11 a/b/g/n/ac-W2 (MIMO 3x3)
Firewall Throughput	5 Gbps (1518/512/64 byte UDP)
Interfaces	5x GE RJ45 ports (1x GE WAN/DMZ, 4x GE Internal incl. 1x FortiLink)
Dimensions (H x W x L)	40.5 x 216 x 160 mm (1.6 x 8.5 x 6.3 inches)
Weight	1 kg (2.2 lbs)
Power Input	12Vdc, 3A (External Adapter)
Bundle Included	3 Year Enterprise Protection (IPS, AMP, Web Filtering, OT Security, and more)

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	1 Gbps
NGFW Throughput	800 Mbps
Threat Protection Throughput	600 Mbps
System Performance & Capacity
Firewall Latency	2.97 μs
Concurrent Sessions (TCP)	700,000
New Sessions/Second (TCP)	35,000
Firewall Policies	2,000
IPsec VPN Throughput	4.4 Gbps
SSL-VPN Throughput	490 Mbps (SSL VPN not supported on FortiOS 7.6.0 and above)
Wireless Specifications
Radio	Single Radio (2.4GHz/5GHz)
Max WiFi Speeds	1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz
Antennas	3 x SMA antenna ports (Antenna gain: 3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz)
Hardware Specifications
USB Port	1x USB Port
Console Port	1x RJ45 Console Port
Environment & Power
Power Consumption (Avg / Max)	14.6 W / 16.6 W
Heat Dissipation	56.64 BTU/h
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	Fanless 0 dBA
Certifications
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kits (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-40F-PA-10(-XX))

[/accesories]

Unified Security and Wireless Connectivity

The FortiWiFi 40F (FWF-40F-A) delivers a converged networking and security solution designed for small businesses and branch offices. Powered by Fortinet's patented SoC4 SD-WAN ASIC, it integrates Next-Generation Firewall (NGFW) capabilities with dual-band 802.11ac wireless. This 3-Year Enterprise Protection bundle ensures your network is defended against known, unknown, and zero-day threats through AI-powered security services.

With its fanless, compact desktop design, the FortiWiFi 40F operates silently, making it ideal for noise-sensitive environments like retail stores or home offices. The integrated Wi-Fi eliminates the need for separate access points, reducing hardware clutter while maintaining unified management through FortiOS.

Key Benefits

• Comprehensive Enterprise Protection: Includes a 3-Year subscription for IPS, Anti-Malware, URL Filtering, OT Security, and more.

• Integrated Wireless: Features built-in 802.11ac-W2 Wi-Fi with 3x3 MIMO technology for reliable, high-speed wireless connectivity.

• High-Performance ASIC: The SoC4 processor delivers 5 Gbps firewall throughput and accelerates SD-WAN application identification.

• Fanless Design: Operates silently (0 dBA), ensuring suitability for desktop use in open office environments.

• Unified Management: FortiOS provides a single pane of glass for managing both wired and wireless networking alongside advanced security policies.

• Secure SD-WAN: Delivers application-aware steering and fast IPsec VPN performance for efficient cloud access.

Ideal Use Cases

• Retail & Branch Offices: Unified security and Wi-Fi for point-of-sale systems and customer guest access in a single device.

• Small Business: Enterprise-grade threat protection without the complexity of managing multiple appliances.

• Remote Work: Secure connectivity for home offices requiring reliable VPN and wireless performance.

Technical Specifications Summary

• IPv4 Firewall Throughput: 5 Gbps (1518/512/64 byte UDP)
• IPS Throughput (Enterprise Mix): 1 Gbps
• NGFW Throughput: 800 Mbps
• Threat Protection Throughput: 600 Mbps
• IPsec VPN Throughput (512 byte): 4.4 Gbps
• SSL-VPN Throughput: 490 Mbps (SSL VPN not supported on FortiOS 7.6.0 and above)
• Wi-Fi Performance: 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz; Single Radio (2.4GHz/5GHz)
• Sessions: 700,000 concurrent TCP sessions; 35,000 new sessions/second
• Power & Acoustics: 12Vdc, 3A input; 14.6 W avg / 16.6 W max; Fanless 0 dBA
• Physical: 40.5 x 216 x 160 mm; 1 kg (2.2 lbs)
• Environment & Compliance: 0°C to 40°C operating; FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB; USGv6/IPv6

Upgrade Your Network Security

Secure your branch or small business with the FortiWiFi 40F and 3-Year Enterprise Protection bundle today.
