[shortdesc] Next-generation firewall with integrated Wi-Fi 6, Secure SD-WAN support, dual-band 802.11ax wireless, up to 500 Mbps threat protection, including 3-year Unified Threat Protection bundle [/shortdesc]

[properties]

Product SKU	FWF-31G-A-BDL-950-36
Bundle Type	Hardware + 3 Year UTP Bundle
Internal Storage	30GB SSD
Form Factor	Desktop
Wi-Fi Standard	802.11ax Wi-Fi 6 (Dual Radio)
Firewall Throughput	4 Gbps
Threat Protection Throughput	500 Mbps
Network Interfaces	4x GE RJ45 Ports (1x WAN, 2x LAN, 1x FortiLink)
Dimensions (H x W x L)	1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm)
Weight	1.5 lbs (0.7 kg)
Power Input	External DC power adapter (12VDC, 2A; 100–240V AC, 50/60 Hz)

[/properties]

[specifications]

System Performance
IPS Throughput	800 Mbps
NGFW Throughput	570 Mbps
Wireless Specifications
Radio Specifications	Dual Radio (2.4 GHz, 5 GHz)
Antenna Type	3x WiFi Antenna Ports
System Capacity
Concurrent Sessions (TCP)	600,000
New Sessions/Second (TCP)	30,000
Firewall Policies	2,000
Hardware & Environment
Console Port	1x RJ45 Console Port
Power Consumption (Avg / Max)	12.85 W / 14.2 W
Heat Dissipation	48.42 BTU/hr
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	20% to 90% non-condensing
Noise Level	N/A

[/specifications]

[accesories]

Included Hardware	FortiWiFi 31G device and external DC power adapter
Included Services	3 Year Unified Threat Protection (UTP) bundle subscription with FortiGuard security services
Optional Accessories	Wall Mount Kit (SP-FG60F-MOUNT-20) and AC Power Adaptor pack (SP-FG-30G-PA-10(-XX))

[/accesories]

Integrated Wireless Security with Local Storage

The FortiWiFi 31G 3-Year UTP Bundle (FWF-31G-A-BDL-950-36) is an integrated security platform designed for branch offices and distributed locations that require advanced protection, secure wireless connectivity, and local data handling. Unlike the standard 30G model, this variant includes 30GB of onboard SSD storage to support enhanced local logging and reporting.

Powered by Fortinet SoC4 and the Secure SD-WAN ASIC SP4, the FortiWiFi 31G maintains consistent performance even with inspection features such as IPS and web filtering enabled. Built-in Wi-Fi 6 (802.11ax) provides secure, high-speed wireless access without the need for separate access points, all within a compact desktop appliance.

Key Specifications

• 3-Year Unified Threat Protection: Includes a 36-month UTP subscription covering IPS, web filtering, anti-malware, and application control.
• 30GB Onboard SSD: Enables local logging and reporting directly on the appliance.
• Wi-Fi 6 Connectivity: Dual-radio 802.11ax wireless supports modern client devices with improved efficiency.
• SoC4 and Secure SD-WAN ASIC SP4: Accelerates firewall inspection, SD-WAN, and VPN performance.
• Compact Desktop Design: Suitable for desktop placement with optional wall-mounting support.
• Unified Management: Converges networking, security, and wireless management under FortiOS.

Ideal Use Cases

• Retail locations requiring secure Wi-Fi and local log retention
• Branch offices needing integrated NGFW and Secure SD-WAN
• Remote sites preferring local reporting and reduced uplink usage
• Small businesses seeking an all-in-one security appliance with a 3-year protection bundle

Technical Specifications

• IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
• IPS Throughput (Enterprise Mix): 800 Mbps
• NGFW Throughput: 570 Mbps
• Threat Protection Throughput: 500 Mbps
• IPsec VPN Throughput (512 byte): 3.5 Gbps
• Concurrent Sessions (TCP): 600,000
• New Sessions per Second (TCP): 30,000
• Interfaces: 1x GE WAN, 2x GE LAN, 1x GE FortiLink, 1x RJ45 console
• Wireless Interface: Dual Radio (2.4 GHz / 5 GHz), 802.11ax Wi-Fi 6
• Power & Environment: 12VDC, 2A; 12.85 W / 14.2 W avg/max; operating temperature 0°C to 40°C

Upgrade Your Network Security

Secure your branch network with integrated NGFW protection, Secure SD-WAN, Wi-Fi 6 connectivity, and local logging using the FortiWiFi 31G 3-Year UTP Bundle.
