[shortdesc] Next-generation firewall with integrated Wi-Fi 6, Secure SD-WAN support, dual-band 802.11ax wireless, up to 500 Mbps threat protection, including 5-year FortiGuard Enterprise Protection bundle [/shortdesc]

[properties]

Product SKU	FWF-31G-A-BDL-809-60
Bundle Type	Hardware + 5 Year Enterprise Protection Bundle
Internal Storage	30GB SSD
Form Factor	Desktop
Wi-Fi Standard	802.11ax Wi-Fi 6 (Dual Radio)
Firewall Throughput	4 Gbps
Threat Protection Throughput	500 Mbps
Network Interfaces	4x GE RJ45 Ports (1x WAN, 2x LAN, 1x FortiLink)
Dimensions (H x W x L)	1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm)
Weight	1.5 lbs (0.7 kg)
Power Input	External DC power adapter (12VDC, 2A; 100–240V AC, 50/60 Hz)

[/properties]

[specifications]

System Performance
IPS Throughput	800 Mbps
NGFW Throughput	570 Mbps
Wireless Specifications
Radio Specifications	Dual Radio (2.4 GHz, 5 GHz)
Antenna Type	3x WiFi Antenna Ports
System Capacity
Concurrent Sessions (TCP)	600,000
New Sessions/Second (TCP)	30,000
Firewall Policies	2,000
Hardware & Environment
Console Port	1x RJ45 Console Port
Power Consumption (Avg / Max)	12.85 W / 14.2 W
Heat Dissipation	48.42 BTU/hr
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	20% to 90% non-condensing
Noise Level	N/A

[/specifications]

[accesories]

Included Hardware	FortiWiFi 31G device and external DC power adapter
Included Services	5 Year FortiCare Premium and FortiGuard Enterprise Protection subscription
Optional Accessories	Wall Mount Kit (SP-FG60F-MOUNT-20) and AC Power Adaptor pack (SP-FG-30G-PA-10(-XX))

[/accesories]

Integrated Wireless Security with Enterprise-Level Protection

The FortiWiFi 31G Enterprise Bundle (FWF-31G-A-BDL-809-60) delivers an integrated next-generation firewall, secure Wi-Fi 6 connectivity, and advanced FortiGuard security services designed for branch offices and distributed environments. This model includes 30GB of onboard SSD storage to support enhanced local logging and analytics.

Powered by Fortinet SoC4 and the Secure SD-WAN ASIC SP4, the FortiWiFi 31G maintains high performance while running advanced security inspection services. Integrated dual-radio Wi-Fi 6 enables secure, high-speed wireless access without the need for external access points, all within a compact desktop form factor.

Key Specifications

• 5-Year FortiGuard Enterprise Protection: Includes advanced IPS, application control, web filtering, and malware protection services.
• FortiCare Premium Support: Provides enhanced support coverage and firmware updates for the duration of the subscription.
• 30GB Onboard SSD: Supports local log storage and reporting.
• Wi-Fi 6 Connectivity: Dual-radio 802.11ax wireless for improved performance and client density.
• SoC4 and Secure SD-WAN ASIC SP4: Accelerates firewall, SD-WAN, and VPN workloads.
• Unified Management: Centralized control of security, networking, and wireless through FortiOS.

Ideal Use Cases

• Branch offices requiring enterprise-grade security with integrated Wi-Fi
• Retail and distributed locations needing advanced threat inspection
• Remote sites benefiting from local logging and Secure SD-WAN
• Small and mid-sized businesses seeking an all-in-one NGFW with enterprise protection

Technical Specifications

• IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
• IPS Throughput (Enterprise Mix): 800 Mbps
• NGFW Throughput: 570 Mbps
• Threat Protection Throughput: 500 Mbps
• IPsec VPN Throughput (512 byte): 3.5 Gbps
• Concurrent Sessions (TCP): 600,000
• New Sessions per Second (TCP): 30,000
• Interfaces: 1x GE WAN, 2x GE LAN, 1x GE FortiLink, 1x RJ45 console
• Wireless Interface: Dual Radio (2.4 GHz / 5 GHz), 802.11ax Wi-Fi 6
• Power & Environment: 12VDC, 2A; 12.85 W / 14.2 W avg/max; operating temperature 0°C to 40°C

Strengthen Your Network Security

Deploy enterprise-grade protection, Secure SD-WAN, and integrated Wi-Fi 6 in a single compact appliance with the FortiWiFi 31G Enterprise Bundle.
