[shortdesc] Next-generation firewall with integrated Wi-Fi 6, SD-WAN support, dual-band 802.11ax wireless, up to 500 Mbps threat protection, 30GB onboard SSD for local logging, compact desktop design for small offices [/shortdesc]

[properties]

Product SKU	FWF-31G-A
Form Factor	Desktop
Internal Storage	30GB SSD
Wi-Fi Standard	802.11ax Wi-Fi 6 (Dual Radio)
Firewall Throughput	4 Gbps
Threat Protection Throughput	500 Mbps
Network Interfaces	4x GE RJ45 Ports (1x WAN, 2x LAN, 1x FortiLink)
Dimensions (H x W x L)	1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm)
Weight	1.5 lbs (0.7 kg)
Power Input	External DC power adapter (12VDC, 2A; 100-240V AC, 50/60 Hz)

[/properties]

[specifications]

System Performance
Firewall Throughput	4 Gbps
IPS Throughput	800 Mbps
NGFW Throughput	570 Mbps
Threat Protection	500 Mbps
Wireless Specifications
Radio Configuration	Dual Radio (2.4 GHz and 5 GHz)
Wireless Standards	802.11 a/b/g/n/ac/ax (Wi-Fi 6)
Antenna Ports	3x External Wi-Fi Antenna Ports
System Capacity
Concurrent Sessions (TCP)	600,000
New Sessions per Second	30,000
Firewall Policies	2,000
Hardware & Environment
Console Port	1x RJ45
Power Consumption	12.85 W average / 14.2 W maximum
Heat Dissipation	48.42 BTU/hr
Operating Temperature	0°C to 40°C
Storage Temperature	-35°C to 70°C
Humidity	20% to 90% non-condensing

[/specifications]

[accesories]

Included Hardware	FortiWiFi 31G Appliance, External DC Power Adapter (included in the box)
Additional Accessories	Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adapter (SP-FG-30G-PA-10(-XX))

[/accesories]

FortiWiFi 31G Next Generation Firewall

The FortiWiFi 31G (FWF-31G-A) is a compact next-generation firewall designed for edge deployments that require integrated security, wireless connectivity, and local data retention. With a built-in 30GB SSD, the device supports onboard event logging and reporting, making it well suited for environments with limited or intermittent connectivity.

Powered by Fortinet’s Secure SD-WAN ASIC SP4 architecture, the FortiWiFi 31G delivers consistent threat protection performance while enabling secure SD-WAN, firewall inspection, and IPsec VPN acceleration within a single platform.

Integrated Wireless and Security

• 30GB Onboard SSD: Enables local logging and reporting without reliance on constant cloud connectivity.
• Built-in Wi-Fi 6: Dual-band 802.11ax wireless provides high-speed and secure access for users and devices.
• Secure SD-WAN ASIC SP4: Accelerates security inspection and VPN performance.
• Compact Desktop Design: Suitable for desktops or wall-mounted deployments using an optional mount kit.
• All-in-One Platform: Combines firewall, SD-WAN, and wireless controller capabilities in a single appliance.

Typical Deployment Scenarios

• Branch offices requiring local log retention for compliance purposes
• Retail environments needing secure Wi-Fi and offline log buffering
• Small businesses seeking an integrated security and wireless solution
• Remote locations with limited uplink bandwidth

Key Technical Highlights

• Firewall Performance: Up to 4 Gbps IPv4 and IPv6 firewall throughput
• Threat Protection: 500 Mbps with enterprise traffic mix and logging enabled
• Wireless Connectivity: Dual radio Wi-Fi 6 with external antenna support
• Interfaces: 1x GE WAN, 2x GE LAN, 1x GE FortiLink, 1x RJ45 console
• Power & Environment: External 12VDC power adapter, operating range 0°C to 40°C

Upgrade Your Network Security

Enhance visibility, performance, and wireless connectivity at the network edge with the FortiWiFi 31G and its integrated storage and Wi-Fi 6 capabilities.
