[shortdesc] Next-generation firewall with integrated Wi-Fi 6, Secure SD-WAN support, dual-band 802.11ax wireless, up to 500 Mbps threat protection, compact desktop design, including 3-year Enterprise Protection bundle [/shortdesc]

[properties]

Product SKU	FWF-30G-A-BDL-809-36
Bundle Type	Hardware + 3 Year Enterprise Protection
Form Factor	Desktop
Wi-Fi Standard	Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
Firewall Throughput	IPv4 firewall throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
Threat Protection Throughput	500 Mbps
Network Interfaces	4x GE RJ45 ports (1x WAN, 2x LAN, 1x FortiLink)
Dimensions (H x W x L)	1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm)
Weight	1.5 lbs (0.7 kg)
Power Input	External DC power adapter; 12VDC, 2A (100–240V AC, 50/60 Hz input)

[/properties]

[specifications]

System Performance
IPS Throughput	800 Mbps
NGFW Throughput	570 Mbps
Wireless Specifications
Radio Specifications	Dual Radio (2.4 GHz, 5 GHz)
MIMO	Dual-stream
Antenna Type	3x WiFi antenna ports (external antennas)
System Capacity
Concurrent Sessions (TCP)	600,000
New Sessions/Second (TCP)	30,000
Firewall Policies	2,000
Hardware & Environment
USB Ports	—
Console Port	1x Console Port (RJ45)
Power Consumption (Avg / Max)	11.3 W / 13.6 W
Heat Dissipation	46 BTU/h
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	20% to 90% non-condensing
Noise Level	N/A

[/specifications]

[accesories]

Included Hardware	FortiWiFi 30G device, external DC power adapter
Included Services	3 Year Enterprise Protection bundle with FortiGuard AI-Powered Security Services and FortiCare Premium Services (24x7x365 availability; one-hour response for critical issues; next-business-day response for noncritical matters).
Optional Accessories	Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-30G-PA-10(-XX))

[/accesories]

The FortiWiFi 30G 3-Year Enterprise Protection Bundle (FWF-30G-A-BDL-809-36) is designed for secure connectivity at distributed sites, combining NGFW security, Secure SD-WAN, and integrated Wi-Fi 6 for branch offices and small environments. Built on FortiOS and Fortinet’s patented SD-WAN ASIC (SP4), it helps deliver consistent protection and efficient network operations from a single platform.

With integrated security services and centralized management options, FortiWiFi 30G provides real-time visibility and policy enforcement for users, devices, and applications. It supports deep inspection features and delivers up to 800 Mbps IPS throughput, up to 570 Mbps NGFW throughput, and up to 500 Mbps threat protection throughput in a compact desktop appliance suitable for fast deployments.

Advanced Security for IoT and Modern Networks

• 3-Year Enterprise Protection: Includes a 3-year Enterprise Protection bundle with FortiGuard AI-Powered Security Services and FortiCare Premium Services (service coverage depends on the subscribed bundle).
• Wi-Fi 6 Connectivity: Built-in dual-radio wireless interface supports 2.4 GHz and 5 GHz operation with 802.11ax (Wi-Fi 6) capability.
• SP4 ASIC + FortiOS: Powered by Fortinet’s patented SD-WAN ASIC (SP4) and the FortiOS operating system for converged networking and security.
• Secure SD-WAN: Integrates SD-WAN and NGFW functions in a single appliance to streamline branch WAN architecture.
• Trusted Platform Module (TPM): Includes a dedicated TPM module to harden the appliance for secure cryptographic operations.
• Compact Desktop Deployment: Desktop form factor with optional wall-mounting support for flexible placement in small environments.

Ideal Use Cases

• Branch offices requiring integrated NGFW security and Secure SD-WAN
• Small offices needing built-in Wi-Fi 6 for secure wireless access
• Distributed sites requiring centralized visibility and consistent security policies
• Deployments needing compact, reliable hardware for desktop placement

Technical Specifications

• IPS Throughput (Enterprise Mix): 800 Mbps
• NGFW Throughput (Enterprise Mix): 570 Mbps
• Threat Protection Throughput (Enterprise Mix): 500 Mbps
• IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
• IPsec VPN Throughput (512 byte): 3.5 Gbps
• Concurrent Sessions (TCP): 600,000
• New Sessions/Second (TCP): 30,000
• Interfaces: 1x GE RJ45 WAN, 2x GE RJ45 LAN, 1x GE RJ45 FortiLink (4x GE RJ45 total) + 1x console (RJ45)
• Wireless Interface: Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
• Power: 12VDC, 2A; average/max power consumption 11.3 W / 13.6 W
• Physical: 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm); 1.5 lbs (0.7 kg)
• Environment & Compliance: 0°C to 40°C operating; FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; USGv6/IPv6

Upgrade Your Network Security

Secure your branch network with integrated NGFW protection, Secure SD-WAN, and Wi-Fi 6 connectivity using the FortiWiFi 30G Enterprise Bundle.
