[shortdesc] Next-generation firewall with integrated WiFi 6, SD WAN support, dual band 802.11ax wireless, up to 500 Mbps threat protection, compact desktop design [/shortdesc]

[properties]

Product Series	FortiWiFi 30G
SKU	FWF-30G-A
Form Factor	Desktop
Wireless Standard	Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax (Wi-Fi 6 / 802.11ax)
Firewall Throughput (UDP)	4 / 4 / 3.9 Gbps (IPv4, 1518 / 512 / 64 byte, UDP)
Threat Protection Throughput	500 Mbps
Interfaces	4x GE RJ45 ports (including 3x internal ports and 1x WAN port)
Power Input	12VDC, 2A
Dimensions (H x W x L)	1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm)
Weight	1.5 lbs (0.7 kg)

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	800 Mbps
NGFW Throughput	570 Mbps
System Performance
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	4 / 4 / 3.9 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	4 / 4 / 3.9 Gbps
Firewall Latency (64 byte UDP)	2.87 μs
Firewall Throughput (Packets Per Second)	5.85 Mpps
IPsec VPN Throughput (512 byte)	3.5 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	400 Mbps
Application Control Throughput (HTTP 64K)	830 Mbps
System Capacity
Concurrent Sessions (TCP)	600,000
New Sessions/Second (TCP)	30,000
Firewall Policies	2,000
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	250
Maximum Number of FortiSwitches Supported	8
Maximum Number of FortiAPs (Total/Tunnel)	16 / 8
Maximum Number of FortiTokens	500
Wireless Specifications
Wireless Antenna Ports	3 x WiFi Antenna Ports
Hardware & Interfaces
Hardware Accelerated GE RJ45 WAN Port	1
Hardware Accelerated GE RJ45 Ports	2
Hardware Accelerated GE RJ45 FortiLink Port	1 (Can be used as Internal)
Console Port (RJ45)	1
Environment & Power
Power Consumption (Average / Maximum)	11.3 W / 13.6 W
Heat Dissipation	46 BTU/hr
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	20% to 90% non-condensing
Operating Altitude	10,000 ft (3048 m)
Noise Level	N/A
Physical Dimensions
Dimensions (H x W x L)	1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm)
Weight	1.5 lbs (0.7 kg)
Certifications
Compliance	FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-30G-PA-10(-XX))

[/accesories]

Converged Next-Generation Firewall and SD-WAN with Built-in Wi-Fi 6

The Fortinet FortiWiFi 30G Series integrates advanced firewalling, SD-WAN, and security functions into a single appliance, making it perfect for building secure networks at distributed enterprise sites. Powered by FortiOS and Fortinet's patented SD-WAN-based ASIC, the FWF-30G-A delivers unmatched performance with lower cost and reduced power consumption compared to traditional CPU-based firewalls.

This model features a built-in dual-band, dual-stream access point providing high-speed Wi-Fi 6 (802.11ax) wireless access, eliminating the need for separate hardware in small environments. It offers comprehensive security through natively integrated FortiGuard AI-Powered Security Services, protecting against file-based threats and web-based attacks in real time.

Key Benefits

• Unparalleled Performance: The patented SD-WAN-based ASIC delivers accelerated application identification and steering, ensuring optimal user experience and efficient business operations.
• Integrated Wireless: Built-in Wi-Fi 6 (802.11ax) dual-radio support provides superior wireless coverage and high-speed connectivity for branch locations.
• AI-Powered Security: Integrated with FortiGuard Labs, the appliance defends against modern threats with advanced security services and deep inspection capabilities.
• Operational Efficiency: Centralized management via FortiManager and simplified operations through FortiGate Cloud reduce complexity and streamline workflows.
• Access Layer Security: The FortiLink protocol allows the integration of FortiSwitch as a logical extension of the firewall for unified protection and management.

Ideal Use Cases

• Secure SD-WAN: Delivers fast application identification and overlay performance for reliable connectivity in hybrid working environments.
• Small Business & Branch Offices: A compact, all-in-one solution that combines networking, security, and wireless access to minimize hardware footprint.
• Retail & POS: Provides secure, compliant connectivity for distributed retail sites with integrated Wi-Fi for staff and guest access.

Technical Specifications

• Threat Protection Throughput: 500 Mbps
• NGFW Throughput: 570 Mbps
• IPS Throughput: 800 Mbps
• Firewall Throughput: 4 / 4 / 3.9 Gbps (IPv4, 1518 / 512 / 64 byte, UDP)
• IPsec VPN Throughput: 3.5 Gbps (512 byte)
• SSL Inspection Throughput: 400 Mbps (IPS, avg. HTTPS)
• Concurrent Sessions: 600,000 (TCP) | New Sessions/Second: 30,000 (TCP)
• Ports: 1x GE RJ45 WAN, 2x GE RJ45, 1x GE RJ45 FortiLink (default), 1x Console (RJ45), 3x WiFi antenna ports
• Wireless: Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax (Wi-Fi 6 / 802.11ax)
• Power: 12VDC, 2A | Consumption: 11.3 W avg / 13.6 W max
• Dimensions: 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm) | Weight: 1.5 lbs (0.7 kg)
• Operating Temperature: 32°F to 104°F (0°C to 40°C)

Upgrade Your Network Security

Deploy the FortiWiFi 30G today for a compact, high-performance security solution that simplifies your branch network infrastructure.
