[shortdesc]24x multigig PoE++ RJ45 ports, 2x 100G QSFP28 uplinks, Layer 3 switching, 1440W PoE budget, dual hot-swappable power supplies[/shortdesc]

[properties]

Model	FortiSwitch T1024F-FPOE
SKU	FS-T1024F-FPOE
Product Type	Managed Ethernet Switch
Switching Layer	Layer 2 / Layer 3
Form Factor	1 RU Rack-mountable
Total Ports	24 + 2 uplink ports
Access Ports	24 × 10G / 5G / 2.5G / 1G RJ-45
Uplink Ports	2 × 100G / 40G QSFP28
PoE Standard	IEEE 802.3af / 802.3at / 802.3bt (Type 4)
PoE Ports	24
Total PoE Budget	1440 W
Switching Capacity	880 Gbps
Forwarding Rate	1309 Mpps
MAC Address Table	64K entries
Latency	~1 μs
Memory	8 GB DDR4
Flash Storage	32 MB
Airflow	Front to back
Power Supply	Dual hot-swappable AC
Redundant Power	Yes
Dimensions (H × D × W)	43.5 × 460 × 438.5 mm
Weight	7.5 kg

[/properties]

[specifications]

Supported VLANs	4096
Link Aggregation	Up to 24 groups
Packet Buffer	8 MB
Queues per Port	8
Routing Protocols	BGP, OSPF, RIP, VRRP, IS-IS
Multicast Support	IGMP Snooping, MLD Snooping, PIM-SSM
Security Features	ACL, 802.1X, DHCP Snooping, Dynamic ARP Inspection, MACsec
QoS	802.1p, DSCP, ECN, Rate Control
Management Interfaces	CLI, Web GUI, SNMP v1/v2c/v3, SSH, Telnet, REST API
Operating Temperature	0 °C to 45 °C
Storage Temperature	−40 °C to 70 °C
Operating Humidity	10% to 95% RH (non-condensing)
Power Input	AC 100–240 V, 50–60 Hz
Maximum Power Consumption	1660 W
MTBF	> 10 years
Compliance	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS 2

[/specifications]

[accesories]

Included	Dual hot-swappable AC power supplies; rack-mount kit (included in the box)
Optional	FortiSwitch Advanced Features License; Fortinet QSFP28 transceivers; spare AC power supplies

[/accesories]

High-Density PoE++ Switching for Campus Core and Data Center Edge

The Fortinet FortiSwitch T1024F-FPOE is engineered for environments that demand extreme power delivery, multigigabit access, and high-speed aggregation. Designed for campus core, SD-Branch, and data center top-of-rack deployments, this switch combines advanced Layer 2 and Layer 3 capabilities with enterprise-grade PoE++ to support modern, power-hungry devices at scale.

With seamless integration into the Fortinet Security Fabric via FortiLink, the FortiSwitch T1024F-FPOE enables centralized policy enforcement, simplified operations, and unified visibility when managed through FortiGate. It can also operate as a fully capable standalone switch, offering flexibility for diverse network architectures.

Key Benefits & Features

• High-Power PoE++ Access: Delivers up to 1440W of PoE across 24 RJ45 ports supporting IEEE 802.3af, 802.3at, and 802.3bt for cameras, Wi-Fi 6 access points, and IoT devices.
• Multigigabit Performance: Supports 1G, 2.5G, 5G, and 10G speeds per port, ensuring optimal throughput for modern endpoints without recabling.
• Ultra-Fast Aggregation: Dual 100G QSFP28 uplinks provide massive bandwidth for aggregation, backbone connectivity, or data center interconnects.
• Advanced Layer 3 Routing: Hardware-based routing with support for BGP, OSPF, VRRP, ECMP, and VXLAN enables scalable and resilient network designs.
• Enterprise Reliability: Dual hot-swappable AC power supplies, front-to-back airflow, and a compact 1RU design ensure uptime in mission-critical environments.

Ideal Use Cases

• Campus core and distribution layer deployments
• High-density Wi-Fi 6 and Wi-Fi 6E access networks
• SD-Branch and secure enterprise edge architectures
• Data center top-of-rack PoE aggregation
• IoT, surveillance, and unified communications infrastructure

Technical Specifications

• Switching Capacity: 880 Gbps
• Forwarding Rate: 1309 Mpps
• Access Ports: 24x 10G 5G 2.5G 1G RJ45 PoE++
• Uplink Ports: 2x 40G 100G QSFP28
• PoE Budget: 1440W total
• Latency: Approximately 1 microsecond
• Form Factor: 1RU rack-mountable
• Power Supplies: Dual hot-swappable AC
• Airflow: Front-to-back
• Memory: 8 GB DDR4 with 32 MB flash

Power Your Network Without Compromise

Deploy high-density PoE, multigig access, and 100G aggregation with confidence. Order the FortiSwitch T1024F-FPOE today and build a scalable, secure, and future-ready network.
