[shortdesc]48x Multi-Gig PoE++ access ports, 8x 25G SFP28 uplinks, 1800W PoE budget, Layer 2/3 switching, FortiLink managed, 1RU rack-mount[/shortdesc]

[properties]

Model	FortiSwitch 648F-FPoE
SKU	FS-648F-FPOE
Brand	Fortinet
Product Type	Managed Ethernet Switch
Switching Layer	Layer 2 / Layer 3
Form Factor	1U Rack-mountable
Total Ports	48 RJ-45, 8 SFP28
RJ-45 Ports	32 x 1GE/2.5GE, 16 x 1GE/2.5GE/5GE
Uplink Ports	8 x 1GE/10GE/25GE SFP/SFP+/SFP28
PoE Standard	IEEE 802.3af / 802.3at / 802.3bt (Type 4)
PoE Ports	48
Total PoE Budget	1800 W
Switching Capacity	720 Gbps
Forwarding Rate	1071 Mpps
MAC Address Table	64K entries
VLAN Support	Up to 4096 VLANs
Management	FortiLink, CLI, Web GUI, SNMP
Power Supply	Dual hot-swappable AC
Redundant Power	Yes
Dimensions (H x W x D)	44 x 440 x 442 mm
Weight	7.834 kg
Operating Temperature	0 °C to 45 °C
Operating Humidity	5% to 95% RH non-condensing

[/properties]

[specifications]

Switching Architecture	Non-blocking, wire-speed
Packet Buffer	8 MB
Latency	< 1 µs
Spanning Tree	STP, RSTP, MSTP, Rapid PVST
Link Aggregation	LACP, MCLAG supported
Routing Protocols	OSPF, OSPFv2, BGP, RIP-2, IS-IS, VRRP, ECMP
Multicast	IGMP Snooping, IGMP Querier, MLD Snooping
Security Features	802.1X, ACLs, DHCP Snooping, IP Source Guard, MACsec
QoS	802.1p, DSCP, Priority Queuing
Jumbo Frames	Supported
Management Protocols	SNMP v1/v2c/v3, RMON, Syslog, SSH, HTTPS
Time Services	SNTP, IEEE 1588 PTP
MTBF	> 10 years
Certifications	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

[/specifications]

[accesories]

Included in the box	Rack mounting kit, USB to RJ-45 console cable, AC power cables
Optional Power Supplies	FS-600-PSU-1200 redundant AC power supply
Optional Accessories	Fortinet SFP/SFP+/SFP28 transceiver modules

[/accesories]

High-Density Secure Switching for Modern Campus Networks

The Fortinet FortiSwitch 648F-FPOE is a high-performance enterprise campus switch designed to deliver secure, scalable, and power-dense access layer connectivity. Built for modern environments running Wi-Fi 6, IoT devices, IP cameras, and unified communications, it combines Multi-Gigabit Ethernet, advanced PoE++, and deep FortiGate integration in a compact 1RU form factor.

When deployed with FortiGate using FortiLink, the FortiSwitch 648F-FPOE becomes a fully integrated extension of the Fortinet Security Fabric, enabling centralized management, automated policy enforcement, and dynamic segmentation across the wired network.

Key Benefits & Features

• Ultra-High PoE++ Capacity: Delivers up to 1800W of IEEE 802.3bt PoE to power high-demand devices such as Wi-Fi 6 access points, PTZ cameras, and IoT gateways.
• Multi-Gigabit Access Ports: Combines 32x 1G/2.5G and 16x 1G/2.5G/5G RJ45 ports to eliminate access layer bottlenecks.
• 25G Uplink Performance: Eight SFP28 uplinks provide high-speed aggregation and future-ready backbone connectivity.
• Integrated Security Fabric: FortiLink enables centralized control, NAC, microsegmentation, and policy enforcement directly from FortiGate.
• Enterprise-Grade Reliability: Dual hot-swappable power supplies and high reliability support nonstop campus operations.

Ideal Use Cases

• Enterprise and university campus access layers
• High-density Wi-Fi 6 and Wi-Fi 6E deployments
• IP surveillance and IoT-powered facilities
• Secure branch or headquarters network expansion
• Organizations standardizing on Fortinet Security Fabric

Build a Secure, High-Power Campus Network Today

Deploy the Fortinet FortiSwitch 648F-FPOE to unify performance, power, and security at the access layer. Order today.
