Fortinet FortiSwitch FS-624F-FPOE Managed Switch
[shortdesc]24x 1G/2.5G/5G PoE++ ports, 4x 25G SFP28 uplinks, Layer 2/3 switching, 1400W PoE budget capable, 1RU rack mount[/shortdesc]
[properties]
| Brand | Fortinet |
| Model | FortiSwitch 624F-FPOE |
| SKU | FS-624F-FPOE |
| Product Type | Managed Ethernet Switch |
| Series | FortiSwitch 600 Series |
| Layer Support | Layer 2 / Layer 3 |
| Form Factor | Rack-mountable (1U) |
| Total Ports | 24 |
| RJ45 Ports | 24 × 1G / 2.5G / 5GBase-T (PoE++) |
| Uplink Ports | 4 × 1G / 10G / 25G SFP / SFP+ / SFP28 |
| PoE Support | Yes (IEEE 802.3bt PoE++) |
| PoE Budget | Up to 1400 W (Depends on PSU) |
| Switching Capacity | 440 Gbps (full duplex) |
| Forwarding Rate | 654 Mpps |
| MAC Address Table | 64K entries |
| Packet Buffer | 8 MB |
| Memory | 4 GB DDR4 |
| Storage | 32 GB SSD |
| Airflow Direction | Front-to-back |
| Power Supply | Dual hot-swappable AC power supplies |
| Installed Power Supplies | 2 × 350 W |
| Maximum Power Consumption | 240 W (System only) |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Storage Temperature | −40 °C to 70 °C (−40 °F to 158 °F) |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (H × D × W) | 44 × 442 × 440 mm (1.75 × 17.4 × 17.3 in) |
| Weight | 6.925 kg |
[/properties]
[specifications]
| Switching Technology | Multi-Gigabit Ethernet |
| Supported Ethernet Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3ae, 802.3az, 802.3bz, 802.3x, 802.3bt |
| VLAN Support | Up to 4,000 VLANs |
| Link Aggregation | IEEE 802.1AX, up to 28 LAGs |
| Spanning Tree | STP, RSTP, MSTP |
| Routing Protocols | OSPFv2, BGP, RIP-2, IS-IS, VRRP, ECMP |
| Multicast Support | IGMP Snooping, MLD Snooping, PIM-SSM |
| Security Features | ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, MACSec, 802.1X |
| MACSec | Supported (IEEE 802.1ae) |
| Management Interfaces | CLI, Web GUI, SNMP v1/v2c/v3, SSH, HTTPS, RMON, Syslog |
| FortiGate Integration | FortiLink compatible |
| High Availability | MCLAG, redundant power |
| Latency | < 1 µs |
| MTBF | > 10 years |
| Certifications | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS 2 |
[/specifications]
[accesories]
| Included | Rack mounting kit; Console cable; AC power cables |
| Optional – Power Supplies | Spare AC power supply modules (Upgrade required for full PoE budget) |
| Optional – Transceivers | Fortinet SFP, SFP+, and SFP28 optical transceiver modules |
[/accesories]
High-Density Multi-Gigabit Switching for Secure Campuses
The Fortinet FortiSwitch 624F-FPOE is a high-performance enterprise access switch designed for modern campus and branch deployments that demand speed, power, and security. With multi-gigabit Ethernet, ultra-high PoE capacity, and seamless FortiGate integration, it delivers a future-ready access layer built to support Wi-Fi 6, high-power devices, and secure segmentation at scale.
Key Benefits & Features
- Multi-Gigabit PoE++ Access: Twenty-four RJ45 ports support 1G, 2.5G, and 5G speeds with IEEE 802.3bt PoE++ delivering up to 90W per port for access points, cameras, and IoT devices.
- Ultra-Fast 25G Uplinks: Four SFP28 ports provide 25 Gigabit uplink capacity, eliminating bottlenecks between access and aggregation layers.
- Enterprise Layer 2 and Layer 3 Capabilities: Supports advanced routing, multicast, QoS, and segmentation features for scalable campus architectures.
- FortiLink Integration: Operates as a native extension of FortiGate firewalls, enabling centralized policy enforcement, zero-touch deployment, and unified management.
- High-Capacity PoE Budget: Up to 1400W total PoE output capacity supports dense, high-power device deployments (requires compatible power supply configuration).
Ideal Use Cases
- Enterprise and university campus access networks
- High-density Wi-Fi 6 and Wi-Fi 6E deployments
- Security camera and IoT-heavy environments
- Organizations using FortiGate Secure Fabric
- Branch offices requiring scalable PoE switching
Technical Specifications
- Switching Capacity: 440 Gbps
- Forwarding Rate: 654 Mpps
- Access Ports: 24x 1G/2.5G/5G RJ45 PoE++
- Uplink Ports: 4x 25G SFP28
- PoE Budget: Up to 1400W total (max capacity)
- MAC Address Table: 64K entries
- Memory: 4 GB DDR4
- Form Factor: 1RU rack mountable
- Airflow: Front to back
Power Your Campus with Confidence
Deploy secure, high-speed, and high-power access switching with the Fortinet FortiSwitch 624F-FPOE. Order today.
