[shortdesc] High-performance Layer 2/3 Data Center Switch featuring 32x 100GE QSFP28 ports and 2x 10GE SFP+ ports. optimized for FortiGate integration with dual hot-swappable AC power supplies. [/shortdesc]

[properties]

Model	FortiSwitch FS-3032G
Product Type	Layer 2/3 Switch Managed via FortiGate
Total Network Interfaces	32 x 100GE / 40GE QSFP28 / QSFP+ ports; 2 x 10GE / 1GE SFP+ / SFP ports
Switching Capacity	6440 Gbps
Packets Per Second	4000 Mpps
MAC Address Storage	65K
Form Factor	1 RU Rack Mount
VLAN Support	4K
IPv4 / IPv6 Routing	Supported
Memory	8 GB DDR4
Storage Drive	128 GB SSD
Power Supply	Dual hot-swappable AC power supplies
Power Consumption (Maximum)	548.94 W
Air Flow	Front to back
Dimensions (H x D x W)	1.69 x 18.11 x 17.26 in (43 x 460 x 438.5 mm)
Weight	18.45 lbs (8.37 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% RH non-condensing

[/properties]

[specifications]

Layer Support	Layer 2 and Layer 3 switching
Network Latency	< 1 µs
Queues per Port	8
Packet Buffer	32 MB
Link Aggregation Group Size	Up to number of ports
Routing Protocols	OSPF, RIP, VRRP, BGP, IS-IS
Multicast Support	PIM-SSM
VXLAN	Supported
Security Features	ACLs, 802.1X authentication, DHCP snooping, Dynamic ARP inspection
Management	Managed via FortiGate using FortiLink; SNMP v1/v2c/v3; CLI and Web GUI
High Availability	MCLAG supported
Quality of Service	802.1p priority queuing; DSCP-based priority queuing; ECN
Certifications	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

[/specifications]

[accesories]

Optional

Advanced Features License for FS-3000 Series; compatible Fortinet transceiver modules

[/accesories]

High-Density 100G Switching for Modern Data Centers

The FortiSwitch FS-3032G is a high-performance Layer 2/3 data center switch designed for ultra-high-bandwidth aggregation and core deployments. Built to integrate seamlessly with FortiGate via FortiLink, it delivers centralized management, security enforcement, and simplified operations across data center and campus core environments.

With dense 100-gigabit Ethernet connectivity, low latency performance, and enterprise-grade resiliency, the FS-3032G supports virtualization, cloud workloads, and east-west traffic at scale while maintaining operational efficiency.

Key Benefits & Features

• Ultra-Dense 100G Connectivity: 32 QSFP28/QSFP+ ports support 100GE and 40GE links for high-capacity aggregation and spine-leaf architectures.
• FortiGate Switch Controller Integration: Operates as a logical extension of FortiGate, enabling unified policy enforcement, segmentation, and visibility.
• Layer 2 and Layer 3 Capabilities: Supports advanced routing, VXLAN, multicast, and policy-based routing for scalable data center designs.
• High Availability Architecture: Dual hot-swappable AC power supplies and support for MCLAG ensure continuous uptime.
• Low-Latency Performance: Optimized hardware delivers sub-microsecond latency for latency-sensitive applications.

Ideal Use Cases

• Data center spine or aggregation layer deployments
• High-performance virtualization and cloud environments
• Enterprise campus core switching
• Secure fabric architectures with FortiGate NGFWs
• East-west traffic-intensive workloads

Technical Specifications

• Total Ports: 32x 100GE/40GE QSFP28/QSFP+ and 2x 10GE/1GE SFP+
• Switching Capacity: 6.44 Tbps
• Forwarding Rate: 4000 Mpps
• Latency: Less than 1 microsecond
• Form Factor: 1RU rack-mountable
• Power Supply: Dual hot-swappable AC
• Management: FortiLink, FortiGate, FortiCloud, CLI, Web GUI
• Operating System: FortiSwitch OS

Build a Scalable and Secure 100G Core

Deploy the FortiSwitch FS-3032G to power high-bandwidth data center fabrics with integrated security and simplified management. Order today.
