[shortdesc]24x 2.5GBase-T RJ45 ports, 6x 10G SFP+ uplinks, managed Layer 2 switching, 1U rack-mount form factor, fanless low-noise design[/shortdesc]

[properties]

Brand	Fortinet
Model	FortiSwitch 124G
SKU	FS-124G
Product Type	Managed Ethernet Switch
Switch Series	FortiSwitch Secure Access 100G Series
Management Type	Managed
Form Factor	Rack-mountable (1 RU)
Layer Support	Layer 2
Total Ports	24 x 2.5G RJ45, 6 x 10G/1G SFP+
Airflow Direction	Side-to-back
Cooling	Fanless
Power Supply	Internal AC power supply
Ingress Protection	IP20

[/properties]

[specifications]

Switching Capacity	240 Gbps
Forwarding Rate	355 Mpps
MAC Address Table	32K entries
Packet Buffer	2 MB
Latency	< 1 µs
VLAN Support	Up to 4094 VLANs
Link Aggregation Groups	16
Spanning Tree Instances	32
Memory	1 GB DDR4
Flash Memory	256 MB NAND
Jumbo Frame Support	Yes
Management Interfaces	CLI, Web GUI, SNMP v1/v2c/v3, SSH, Telnet, HTTP, HTTPS
Routing Support	Static routing, OSPF, BGP, RIP, VRRP
Operating Temperature	23°F to 113°F (-5°C to 45°C)
Storage Temperature	-49°F to 158°F (-40°C to 70°C)
Operating Humidity	5% to 95% RH non-condensing
Power Consumption	43.5 W
Dimensions (H × D × W)	1.71 × 12.2 × 17.3 in (44 × 310 × 440 mm)
Weight	8.75 lbs (3.97 kg)
Compliance	FCC, CE, UKCA, RCM, VCCI, BSMI, UL, CB, RoHS2

[/specifications]

High-Performance Secure Access Switching for Modern Networks

The Fortinet FortiSwitch FS-124G is a high-density, multi-gigabit access switch designed for enterprise branches, campus environments, and high-performance edge networks. Built to integrate seamlessly with Fortinet security architecture, it delivers fast 2.5G access speeds with 10G uplinks while maintaining centralized control and operational simplicity.

With support for FortiLink integration, the FS-124G can be managed directly from a FortiGate firewall, unifying switching and security under a single platform. Its fanless design and efficient power profile make it ideal for wiring closets and noise-sensitive deployments without sacrificing throughput or reliability.

Key Benefits & Features

• Multi-Gigabit Access Performance: Twenty-four 2.5GBase-T ports support high-bandwidth endpoints such as Wi-Fi 6 and Wi-Fi 6E access points.
• High-Speed Uplink Connectivity: Six 10G SFP+ uplinks provide ample backhaul capacity for aggregation or core connectivity.
• FortiLink Centralized Management: Seamlessly integrates with FortiGate for unified policy control, visibility, and automation.
• Enterprise-Grade Switching Capacity: Delivers up to 240 Gbps switching capacity with sub-microsecond latency for demanding workloads.
• Fanless Rack-Mount Design: Silent operation with side-to-back airflow, optimized for data closets and branch deployments.

Ideal Use Cases

• Enterprise branch and campus access layer deployments
• Wi-Fi 6 and multi-gigabit wireless infrastructure
• Secure SD-Branch architectures with FortiGate integration
• High-density user and device connectivity environments
• IT teams requiring centralized and scalable network management

Technical Specifications

• Switching Capacity: 240 Gbps
• Ports: 24x 2.5GBase-T RJ45, 6x 1G/10G SFP+
• Layer Support: Layer 2 managed switching
• Latency: Less than 1 microsecond
• MAC Address Table: 32K entries
• Form Factor: 1U rack-mountable
• Power Supply: Internal AC power supply
• Cooling: Fanless with side-to-back airflow

Upgrade Your Access Network with Confidence

Deploy high-speed, secure access switching with the Fortinet FortiSwitch FS-124G. Order today.
