Fortinet FS-124F Switch
- FortiSwitch-124F is a performance/price competitive switch with 24x GE port + 4x SFP+ port + 1x RJ45 console. Fanless design.
[properties]
| Properties | FS-124F |
| Description | Layer 2 FortiGate switch controller compatible switch with 24 GE RJ45 + 4 10G SFP+ ports. Fanless. |
| Product Family | FortiSwitch |
| Product Type | Switch |
| Total Network Interfaces | 24x GE RJ45 and 4x 10GE SFP+ |
| Dedicated Management 10/100/1000 Ports |
0 |
| RJ-45 Serial Console Port | 1 |
| Form Factor | 1 RU Rack Mount |
| Power over Ethernet (PoE) Ports | 0 |
| PoE Power Budget (single/dual PSU) |
0 |
| Mean Time Between Failures | > 10 years |
[/properties]
[specifications]
| Switching Capacity (Duplex) | 128 Gbps |
| Packets Per Second (Duplex) | 190 Mpps |
| MAC Address Storage | 32 K |
| Network Latency | < 1µs |
| VLANs Supported | 4 K |
| Link Aggregation Group Size | 8 |
| Total Link Aggregation Groups | 16 |
| Packet Buffers | 2 MB |
| DRAM | 512 MB DDR3 |
| FLASH | 64 MB |
| ACL | 768 |
| Spanning Tree Instances | 16 |
| Route Entries (IPv4/IPv6) | - |
| Multicast Route Entries | - |
| Host Entries | - |
| Dimensions in. | 1.73 x 9.06 x 12.99 |
| Power Required | 100240V AC, 50-60 Hz |
| Power Supply | AC built in |
| Redundant Power | No |
| Power Consumption (Average / Maximum) | 24.8 W / 26.3 W |
| Heat Dissipation | 89.683 BTU/h |
| Operating Temperature | 32°113°F (0°45°C) |
| Certification | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
[/specifications]
Fortinet FS-124F Switch
The FS-124F is a fanless, stackable switch with 128 Gbps of switching capacity. It is ideal for SD-Branch and campus deployments, as it can be used in integration with your FortiGate NGFW by using the management protocol FortiLink. It supports non-FortiLink deployments as well.
Quick Specs:
- 24x GE RJ45 ports
- 4x 10GE SFP+ uplink ports
- Rack-mountable
- Non-PoE
Please see the related tabs for the FS-124F datasheet and compatible accessories.
