[shortdesc] 10-port managed PoE++ switch, 200W PoE budget, 2.5G and 5G Ethernet, 4x 10G SFP+ uplinks, fanless desktop form factor [/shortdesc]

[properties]

Model	FortiSwitch 110G-FPOE
SKU	FS-110G-FPOE
Brand	Fortinet
Product Series	FortiSwitch Secure Access Series
Product Type	Managed Ethernet Switch
Layer Support	Layer 2
Form Factor	Desktop
Total Ports	10
RJ-45 Ports	2 × 5GBase-T PoE++ (802.3bt), 8 × 2.5GBase-T PoE+ (802.3af/at)
Uplink Ports	4 × 10 Gigabit SFP+
PoE Type	PoE++ and PoE+
Total PoE Budget	200 W
Switching Capacity	140 Gbps
Forwarding Rate	208 Mpps
Latency	< 1 µs
MAC Address Table	32K entries
Packet Buffer	2 MB
Management	CLI, Web GUI, SNMP, FortiLink
Airflow	Side-to-back
Cooling	Fanless
Ingress Protection	IP30
Power Supply	External AC power adapter (100–240V AC / 54V DC)
Power Consumption	250 W (maximum)
Operating Temperature	0 °C to 45 °C (32 °F to 113 °F)
Operating Humidity	5% to 95% RH non-condensing
Dimensions (H × W × D)	44 × 228 × 270 mm (1.7 × 9 × 10.6 in)
Weight	1.84 kg (4.05 lb)

[/properties]

[specifications]

Ethernet Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3bz, 802.3ae, 802.3af, 802.3at, 802.3bt
VLAN Support	Up to 4,000 VLANs
Link Aggregation	LACP, up to 12 total LAGs
Spanning Tree	STP, RSTP, MSTP (32 instances)
QoS	IEEE 802.1p, DSCP, traffic shaping
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Multicast	IGMP Snooping
Monitoring	sFlow, NetFlow, IPFIX, RMON
High Availability	MC-LAG supported
Routing	Static routing (via FortiGate)
Management Protocols	SNMP v1/v2c/v3, SSH, HTTPS, Syslog, REST API
MTBF	> 10 years
Certifications	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

[/specifications]

[accesories]

Included	External power adapter (included in the box)
Optional	FS-110G-PSU-250-4PACK external power supply kit

[/accesories]

Enterprise-Grade Multi-Gig Switching with Integrated Power

The Fortinet FortiSwitch 110G-FPOE is a compact yet powerful managed Ethernet switch designed for modern branch offices and high-performance edge deployments. Built to deliver multi-gigabit access and advanced Power over Ethernet, it enables organizations to connect, power, and secure demanding devices through a single, centrally managed platform.

With native integration into the Fortinet Security Fabric via FortiLink, the FortiSwitch 110G-FPOE extends FortiGate-based security and visibility directly to the access layer. This unified approach simplifies operations while ensuring consistent policy enforcement across wired infrastructure.

Key Benefits & Features

• Multi-Gigabit Access Ports: Combines 2x 5GBASE-T and 8x 2.5GBASE-T ports to support high-throughput endpoints such as Wi-Fi 6/7 access points, cameras, and edge devices.
• Advanced PoE++ Power Delivery: Provides up to 200W total PoE budget with IEEE 802.3bt support, enabling power-hungry devices without external injectors.
• 10G SFP+ Uplinks: Four dedicated 10 Gigabit SFP+ slots ensure high-speed aggregation and seamless uplink to core or distribution layers.
• Centralized Secure Management: Fully manageable through FortiGate using FortiLink or via cloud and on-prem management tools for simplified deployment.
• Fanless, Silent Operation: Desktop form factor with fanless cooling for noise-sensitive environments.

Ideal Use Cases

• Enterprise branch offices and retail locations
• Powering Wi-Fi 6E/7 access points and PTZ IP cameras
• Secure access layer for Fortinet-based networks
• Small to mid-size business core or aggregation switch
• High-performance edge networking deployments

Technical Specifications

• Total Ports: 10 Ethernet ports
• Port Configuration: 2x 5G PoE++, 8x 2.5G PoE+
• Uplinks: 4x 10G SFP+
• PoE Budget: 200 W total
• Switching Capacity: 140 Gbps
• Forwarding Rate: 208 Mpps
• Latency: < 1 µs
• Form Factor: Desktop, fanless
• Management: Managed, FortiLink compatible

Build a Faster and More Secure Access Network

Deploy multi-gig performance, integrated power, and Fortinet-grade security in one compact switch. Order today.
