Fortinet FGR-60F-BDL-809-12 Rugged Industrial Firewall
[shortdesc] Ruggedized NGFW, 6 Gbps firewall throughput, 3.5 Gbps IPsec VPN, fanless industrial design, wide temperature support, including 1 year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]
[properties]
| Model | FortiGate Rugged 60F |
| SKU | FGR-60F-BDL-809-12 |
| Product Type | Industrial Next-Generation Firewall |
| Form Factor | Desktop / DIN-rail / Wall Mount |
| Processor | FortiSoC4 |
| Ethernet Interfaces | 4 × GE RJ45 ports; 2 × GE RJ45 / SFP shared media ports |
| Bypass Ports | 1 × GE RJ45 bypass pair (between PORT4 and WAN1) |
| Serial Interfaces | 1 × RJ45 console; 1 × DB9 serial (data) |
| USB Ports | 1 × USB (Client / Server) |
| IP Rating | IP20 |
| Power Supply | 12 V to 125 V DC, redundant dual inputs |
| Operating Temperature | -40 °C to 75 °C (-40 °F to 167 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × L) | 42.7 × 216 × 165 mm (1.68 × 8.50 × 6.50 in) |
| Weight | 1.75 kg (3.85 lb) |
[/properties]
[specifications]
| IPv4 Firewall Throughput | 6 / 6 / 5.95 Gbps (1518 / 512 / 64 byte UDP) |
| Firewall Latency | 3.10 µs (64 byte UDP) |
| Firewall Throughput | 8.9 Mpps |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions per Second | 19,000 |
| IPsec VPN Throughput | 3.5 Gbps |
| Gateway-to-Gateway IPsec Tunnels | 200 |
| Client-to-Gateway IPsec Tunnels | 500 |
| SSL-VPN Throughput | 400 Mbps |
| Concurrent SSL-VPN Users | 100 (recommended maximum) |
| IPS Throughput | 950 Mbps |
| NGFW Throughput | 550 Mbps |
| Threat Protection Throughput | 500 Mbps |
| Virtual Domains | 10 (default / maximum) |
| Maximum FortiAPs | 30 total / 10 tunneled |
| Maximum FortiSwitches | 16 |
| High Availability | Active-Active, Active-Passive, Clustering |
| Power Consumption | 15 W average / 21 W maximum |
| Operating Altitude | Up to 3,048 m (10,000 ft) |
[/specifications]
[accesories]
| Included | FortiGate Rugged 60F hardware appliance (bundle contents depend on subscription SKU) |
| Optional – Transceivers | GE SFP RJ45, SX, LX, FX, ZX transceiver modules (industrial temperature rated) |
| Optional – Power | FortiPSU Rugged DIN Rail 240W PSU (SP-RGDIN-240-PS) |
[/accesories]
Industrial-Grade Security for Harsh Environments
The Fortinet FortiGate Rugged 60F Enterprise Protection firewall is engineered to deliver advanced network security in demanding industrial and operational technology environments. Built on Fortinet FortiOS and powered by purpose-built security processors, this rugged firewall protects critical infrastructure without compromising performance or reliability. Its fanless, hardened design ensures stable operation in locations exposed to temperature extremes, electrical noise, and vibration.
Key Benefits & Features
- Ruggedized Fanless Design: Designed for harsh industrial deployments, the fanless architecture improves reliability while supporting extended operating temperature ranges.
- High-Performance Firewalling: Delivers up to 6 Gbps firewall throughput and 950 Mbps IPS performance to secure industrial networks without bottlenecks.
- Advanced Threat Protection: Integrated Enterprise Protection services provide intrusion prevention, malware protection, application control, and web filtering.
- Secure SD-WAN Ready: Built-in SD-WAN capabilities enable resilient and cost-efficient connectivity across distributed industrial sites.
- Industrial Network Visibility: Deep packet inspection for OT protocols enhances visibility and control across industrial control systems.
Ideal Use Cases
- Industrial control and SCADA network security
- Manufacturing plants and factory floor segmentation
- Transportation and railway infrastructure networks
- Energy, utilities, and substation environments
- Remote or unmanned industrial sites
Technical Specifications
- Firewall Throughput: Up to 6 Gbps
- IPS Throughput: Up to 950 Mbps
- IPsec VPN Throughput: Up to 3.5 Gbps
- Network Interfaces: 4x GE RJ45 ports, 2x shared RJ45/SFP ports
- Bypass Ports: 1x GE RJ45 bypass pair
- Form Factor: Desktop, DIN-rail, or wall mount
- Operating Temperature: -40°C to 75°C
- Power Input: Dual redundant 12V to 125V DC
Included Security Subscription (1 Year)
- FortiCare Premium support with ticket handling, advanced hardware replacement (NBD), and access to firmware and general upgrades.
- FortiGuard Enterprise Protection services bundle including IPS, AI-based Inline Malware Prevention, Advanced Malware Protection, Inline CASB Database, and Data Loss Prevention.
- Additional Enterprise Protection services including Application Control, URL DNS and Video Filtering, Anti-spam, Attack Surface Security, and FortiConverter Service.
Secure Your Industrial Network Today
Deploy proven industrial-grade firewall protection with Fortinet FortiGate Rugged 60F. Order today and safeguard critical operations with confidence.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Fortinet FGR-60F-BDL-809-12 Rugged Industrial Firewall
Fortinet FGR-60F-BDL-809-12 Rugged Industrial Firewall
[shortdesc] Ruggedized NGFW, 6 Gbps firewall throughput, 3.5 Gbps IPsec VPN, fanless industrial design, wide temperature support, including 1 year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]
[properties]
| Model | FortiGate Rugged 60F |
| SKU | FGR-60F-BDL-809-12 |
| Product Type | Industrial Next-Generation Firewall |
| Form Factor | Desktop / DIN-rail / Wall Mount |
| Processor | FortiSoC4 |
| Ethernet Interfaces | 4 × GE RJ45 ports; 2 × GE RJ45 / SFP shared media ports |
| Bypass Ports | 1 × GE RJ45 bypass pair (between PORT4 and WAN1) |
| Serial Interfaces | 1 × RJ45 console; 1 × DB9 serial (data) |
| USB Ports | 1 × USB (Client / Server) |
| IP Rating | IP20 |
| Power Supply | 12 V to 125 V DC, redundant dual inputs |
| Operating Temperature | -40 °C to 75 °C (-40 °F to 167 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × L) | 42.7 × 216 × 165 mm (1.68 × 8.50 × 6.50 in) |
| Weight | 1.75 kg (3.85 lb) |
[/properties]
[specifications]
| IPv4 Firewall Throughput | 6 / 6 / 5.95 Gbps (1518 / 512 / 64 byte UDP) |
| Firewall Latency | 3.10 µs (64 byte UDP) |
| Firewall Throughput | 8.9 Mpps |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions per Second | 19,000 |
| IPsec VPN Throughput | 3.5 Gbps |
| Gateway-to-Gateway IPsec Tunnels | 200 |
| Client-to-Gateway IPsec Tunnels | 500 |
| SSL-VPN Throughput | 400 Mbps |
| Concurrent SSL-VPN Users | 100 (recommended maximum) |
| IPS Throughput | 950 Mbps |
| NGFW Throughput | 550 Mbps |
| Threat Protection Throughput | 500 Mbps |
| Virtual Domains | 10 (default / maximum) |
| Maximum FortiAPs | 30 total / 10 tunneled |
| Maximum FortiSwitches | 16 |
| High Availability | Active-Active, Active-Passive, Clustering |
| Power Consumption | 15 W average / 21 W maximum |
| Operating Altitude | Up to 3,048 m (10,000 ft) |
[/specifications]
[accesories]
| Included | FortiGate Rugged 60F hardware appliance (bundle contents depend on subscription SKU) |
| Optional – Transceivers | GE SFP RJ45, SX, LX, FX, ZX transceiver modules (industrial temperature rated) |
| Optional – Power | FortiPSU Rugged DIN Rail 240W PSU (SP-RGDIN-240-PS) |
[/accesories]
Industrial-Grade Security for Harsh Environments
The Fortinet FortiGate Rugged 60F Enterprise Protection firewall is engineered to deliver advanced network security in demanding industrial and operational technology environments. Built on Fortinet FortiOS and powered by purpose-built security processors, this rugged firewall protects critical infrastructure without compromising performance or reliability. Its fanless, hardened design ensures stable operation in locations exposed to temperature extremes, electrical noise, and vibration.
Key Benefits & Features
- Ruggedized Fanless Design: Designed for harsh industrial deployments, the fanless architecture improves reliability while supporting extended operating temperature ranges.
- High-Performance Firewalling: Delivers up to 6 Gbps firewall throughput and 950 Mbps IPS performance to secure industrial networks without bottlenecks.
- Advanced Threat Protection: Integrated Enterprise Protection services provide intrusion prevention, malware protection, application control, and web filtering.
- Secure SD-WAN Ready: Built-in SD-WAN capabilities enable resilient and cost-efficient connectivity across distributed industrial sites.
- Industrial Network Visibility: Deep packet inspection for OT protocols enhances visibility and control across industrial control systems.
Ideal Use Cases
- Industrial control and SCADA network security
- Manufacturing plants and factory floor segmentation
- Transportation and railway infrastructure networks
- Energy, utilities, and substation environments
- Remote or unmanned industrial sites
Technical Specifications
- Firewall Throughput: Up to 6 Gbps
- IPS Throughput: Up to 950 Mbps
- IPsec VPN Throughput: Up to 3.5 Gbps
- Network Interfaces: 4x GE RJ45 ports, 2x shared RJ45/SFP ports
- Bypass Ports: 1x GE RJ45 bypass pair
- Form Factor: Desktop, DIN-rail, or wall mount
- Operating Temperature: -40°C to 75°C
- Power Input: Dual redundant 12V to 125V DC
Included Security Subscription (1 Year)
- FortiCare Premium support with ticket handling, advanced hardware replacement (NBD), and access to firmware and general upgrades.
- FortiGuard Enterprise Protection services bundle including IPS, AI-based Inline Malware Prevention, Advanced Malware Protection, Inline CASB Database, and Data Loss Prevention.
- Additional Enterprise Protection services including Application Control, URL DNS and Video Filtering, Anti-spam, Attack Surface Security, and FortiConverter Service.
Secure Your Industrial Network Today
Deploy proven industrial-grade firewall protection with Fortinet FortiGate Rugged 60F. Order today and safeguard critical operations with confidence.
