Fortinet FGR-60F Firewall
[shortdesc]
- Ruggedized, 4 x GE RJ45 Switch ports, 2 x Shared Media pairs (Including 2 x GE RJ45 ports, 2 x SFP slots). 1x RJ45 by-pass can be set up between WAN1 and PORT4. DB9 Serial.
[properties]
| Properties | FGR-60F |
| Description |
Ruggedized, indoor, IP20, 4x GE RJ45 ports, 2x shared media ports (supports, 2x GE RJ45 ports or 2x SFP slots), 1x GE RJ45 bypass port pair (between PORT4 and WAN1), 1x RJ45 serial port (console), 1x DB9 serial port (data), 1x USB port, dual power inputs.
|
| Product Family |
Early Level Fortigate Rugged Firewalls
|
| Product Type | Firewall |
| GE RJ45 Internal Ports | 5 |
| GE RJ45 WAN Port | 2/1 |
| USB Port | 1 |
| Console (RJ45) | 1 |
| Wireless Interface | 0 |
[/properties][specifications]
| System Performance | |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) | 6/6/5.95 Gbps |
| Firewall Latency (64 byte UDP packets) | 3.10 μs |
| Firewall Throughput (Packets Per Second) | 8.9 Mpps |
| Concurrent Sessions (TCP) | 600 000 |
| New Sessions/Second (TCP) | 319.000 |
| Firewall Policies | 5.000 |
| IPsec VPN Throughput (512 byte packets) | 3.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 500 |
| SSL-VPN Throughput | 400 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum) | 100 |
| IPS Throughput | 950 Mbps |
| SSL Inspection Throughput | 460 Mbps |
| Application Control Throughput | 1.3 Gbps |
| NGFW Throughput | 550 Mbps |
| Threat Protection Throughput | 500 Mbps |
| CAPWAP Throughput | - |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 16 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 30 / 10 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active/Active, Active/Passive, Clustering |
| Dimensions in. | 1.68 x 8.50 x 6.70 |
| Form Factor |
Desktop/ DIN-rail/ Wall Mount
|
| Power Required |
Redundant dual inputs, 2 pins per terminal block, supports negative (+12V to +125V DC) and positive ground (-12V to -125V DC) power sources, DC cables are not included
|
| Maximum Current | 12V DC / 2A |
| Power Consumption (Average / Maximum) | 15 W / 21 W |
| Operating Temperature |
-40°167°F (-40°75°C)
|
| Regulatory Compliance |
FCC Part 15 Class A, RCM, VCCI Class A, CE, UL/cUL, CB
|
| EMC |
EN 55032:2015, Class A EN 55035: 2017 EN IEC 61000-6-4:2019 IEC 61850-3:2013
|
| Electric Power Industry |
IEC 61850-3 and IEEE 1613 Certified
|
| Health and Safety |
IEC 62368-1:2014, 2nd Ed. EN 62368-1:2014 IEC 62368-1:2018, 3rd Ed. EN IEC 62368-1:2020
|
[/specifications][accesories]
| FN-TRAN-LX |
1 GE SFP LX transceiver module, -40°C85°C, over SMF, for all systems with SFP and SFP/SFP+ slots
|
| FN-TRAN-SX |
1 GE SFP SX transceiver module, -40°C85°C, over MMF, for all systems with SFP and SFP/SFP+ slots
|
| FN-TRAN-ZX |
1 GE SFP transceivers, -40°C85°C operation, 90 km range for all systems with SFP slots.
|
| FN-TRAN-FX |
100 Mb multimode SFP transceiver module, -40° to 85°C, 2 km range for systems with SFP Slots and capable of 10/100 Mb mode selection
|
[/accesories]
Fortinet FGR-60F Firewall
The FGR-60F is a member of the FortiGate Rugged series. This product is a compact, comprehensive security device specifically engineered to meet the needs of challenging infrastructures. It is well-suited for small businesses, remote locations, small branch offices, customer premise equipment (CPE), and small retail outlets. Unlike conventional firewall security solutions primarily intended for indoor use, the FortiGate Rugged Series is specifically designed to meet the rugged demands of outdoor environments.
Quick Specs:
- 4x GE RJ45 ports
- Bypass GE RJ45 Port Pair: PORT4 and WAN1
- Serial Interface: 1 DB9
- Processor: FortiSoC4
Please see the related tabs for the FGR-60F datasheet and compatible accessories.
