[shortdesc]FortiGate firewall, 1RU, 4x25GE SFP28 ULL, 4x10GE/GE SFP+/SFP, 16xGE RJ45, 960GB SSD, dual DC PSU[/shortdesc]

[properties]

Product Name	FortiGate 901G-DC
SKU	FG-901G-DC
Form Factor	Rack Mount, 1 RU
Firewall Throughput (Max)	164 Gbps (1518 byte UDP)
Interfaces	4x 25GE/10GE SFP28/SFP+ ULL, 4x 10GE/GE SFP+/SFP, 8x GE SFP, 16x GE RJ45, 1x GE RJ45 Management, 1x 2.5 GE/GE RJ45 HA
Internal Storage	960 GB (2x 480 GB SSD)
Power Input	48–60VDC
Dimensions	1.5 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	16.53 lbs (7.5 kg)
Operating Temperature	32°F to 113°F (0°C to 45°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; USGv6/IPv6

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	42 Gbps
NGFW Throughput	31 Gbps
Threat Protection Throughput	30 Gbps
System Performance and Capacity
IPv4 Firewall Throughput	164 / 163 / 153 Gbps (1518/512/64 byte, UDP)
Firewall Throughput (Packet per Second)	229.5 Mpps
Firewall Latency (64 byte UDP)	3.78 / 2.5 μs*
Concurrent Sessions (TCP)	16 Million
New Sessions/Second (TCP)	720,000
Firewall Policies	50,000
IPsec VPN Throughput	55 Gbps (512 byte)
Gateway-to-Gateway IPsec VPN Tunnels	2,000
SSL-VPN Throughput	10 Gbps
Concurrent SSL-VPN Users	10,000 (Recommended Max, Tunnel Mode)
SSL Inspection Throughput	16.7 Gbps (IPS, avg. HTTPS)
Application Control Throughput	74.8 Gbps (HTTP 64K)
CAPWAP Throughput	133 Gbps (HTTP 64K)
Virtual Domains (Default / Maximum)	10 / 50
Maximum FortiSwitches Supported	196
Maximum FortiAPs Supported	2048 / 1024 (Total / Tunnel)
Maximum FortiTokens Supported	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware and Interfaces
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ ULL Slots	4
Hardware Accelerated 10 GE SFP+ / GE SFP Slots	4
Hardware Accelerated GE SFP Slots	8
Hardware Accelerated GE RJ45 Slots	16
2.5 GE/GE HA Port	1
GE Management Port	1
USB Ports (Client/Server)	2 / 2
Console Port	1
Trusted Platform Module (TPM)	Yes
Dimensions and Power
Power Consumption (Average/Maximum)	184 W / 323 W
Heat Dissipation	1103 BTU/h
Redundant Power Supplies	Yes (comes with 2PSU default)
Operating Environment and Certifications
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	58 dBA
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB

[/specifications]

[accesories]

Included Accessories	2x SFP SX Transceivers, Dual DC Power Supplies
Optional Accessories	1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), DAC Cables (10 GE SFP+, 25 GE SFP28)

[/accesories]

The Fortinet FortiGate 901G-DC Series Next-Generation Firewall (NGFW) is engineered to deliver unified threat management and secure networking for demanding enterprise and service provider environments. It achieves up to 42 Gbps of IPS throughput and 31 Gbps of NGFW throughput, accelerated by the NP7 and CP9 security processors. This model is designed for continuous operation and provides dual DC power supplies for data center and telecom rack deployments.

The FG-901G-DC provides deep visibility and advanced security functions, leveraging the integrated 960GB of onboard SSD storage for local logging and analytics. The flexible, high-density interface configuration includes 25 GE SFP28 ultra-low latency slots, 10GE/GE SFP+/SFP slots, 8x GE SFP slots, and 16x GE RJ45 switch ports plus dedicated management and HA ports for segmenting and connecting critical network zones at multi-gig speeds.

Data Center Resilience with 960GB Storage and 30 Gbps Threat Protection

Key Benefits

• Telecom-Ready Power: Features dual DC power supplies (48–60VDC input) for resilient rack deployments.
• High-Performance Security: Delivers 42 Gbps IPS throughput and 31 Gbps NGFW throughput via NP7 and CP9 processors.
• Integrated Storage: Includes 960 GB (2x 480 GB SSD) onboard storage for local logging and data retention.
• Ultra-Low Latency: Achieves up to 3.78 / 2.5 μs firewall latency (64 byte UDP, ULL ports).
• Encrypted Traffic Inspection: Provides 16.7 Gbps of SSL inspection throughput (IPS, avg. HTTPS).
• Extensive Port Density: Offers 4x 25GE/10GE SFP28/SFP+ ULL, 4x 10GE/GE SFP+/SFP, 8x GE SFP, 16x GE RJ45 switch ports, 1x GE RJ45 management port, and 1x 2.5 GE/GE HA port.

Ideal Use Cases

• Data Center Core Security: Providing high-throughput firewall and VPN termination with DC power.
• Telecom/Service Provider PoP: Integration into DC power distribution for consistent power management and uptime.
• Large Enterprise Campus Edge: Securing high-bandwidth perimeters that require port density and onboard storage.
• High-Speed Secure SD-WAN: Delivering converged networking and security with operational efficiency and analytics.

Technical Specifications Summary

• IPS Throughput (Enterprise Traffic Mix): 42 Gbps
• NGFW Throughput (Enterprise Traffic Mix): 31 Gbps
• Threat Protection Throughput (Enterprise Traffic Mix): 30 Gbps
• IPv4 Firewall Throughput (1518/512/64 byte, UDP): 164 / 163 / 153 Gbps
• Firewall Performance: 229.5 Mpps; 3.78 / 2.5 μs latency (64 byte UDP, ULL ports)
• VPN Performance: 55 Gbps IPsec VPN throughput (512 byte); 10 Gbps SSL-VPN throughput
• SSL Inspection: 16.7 Gbps SSL inspection throughput (IPS, avg. HTTPS)
• Session Capacity: 16 Million concurrent sessions (TCP); 720,000 new sessions/second (TCP)
• Interfaces: 4x 25GE/10GE SFP28/SFP+ ULL; 4x 10GE/GE SFP+/SFP; 8x GE SFP; 16x GE RJ45; 1x GE MGMT; 1x 2.5GE/GE HA
• Onboard Storage: 2x 480 GB SSD (960 GB total)
• Power and Physical: 48–60VDC; 184 W / 323 W (avg/max); 1103 BTU/h; 1RU (1.5 x 17.0 x 15.0 in); 16.53 lbs (7.5 kg)

Upgrade Your Network Security

Deploy the FortiGate 901G-DC for high-throughput security and DC power integration.
