[shortdesc] Firewall, desktop/wall/rack-tray, 8x GE PoE/+ ports, 128GB SSD, 10 / 10 / 7 Gbps, including 5 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Model / SKU	FortiGate / FG-81F-POE-BDL-809-60
Bundle / Subscription	FortiGate Firewall plus FortiCare Premium and FortiGuard Enterprise Protection (5-Year Contract)
Form Factor	Desktop / Wall Mount / Rack Tray
Internal Storage	1x 128 GB SSD
Total PoE Power Budget	96 W
Firewall Throughput (Max)	10 / 10 / 7 Gbps (1518 / 512 / 64 byte UDP)
Interfaces	8x GE RJ45 PoE/+ ports (6 internal + 2 FortiLink), 2x GE RJ45/SFP shared media pairs
Power Input	+54V DC, 3A
Dimensions (H x W x L)	60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
Weight	1.4 kg (3.1 lbs)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Compliance / Certifications	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance - Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance and Capacity
Firewall Throughput (1518/512/64 byte UDP)	10 / 10 / 7 Gbps
Firewall Latency (64 byte UDP)	3.23 μs
New Sessions/Second (TCP)	45,000
Concurrent Sessions (TCP)	1.5 Million
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
SSL-VPN Throughput	950 Mbps
Concurrent SSL-VPN Users (Tunnel Mode)	200
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	24
Hardware & Interfaces
GE RJ45 PoE/+ Ports (Total)	8 (6 Internal + 2 FortiLink)
GE RJ45/SFP Shared Media Pairs	2
USB Ports 3.0	1
Console Port (RJ45)	1
Environment & Power
Power Consumption (Average / Maximum)	98 W / 137 W
Heat Dissipation	467.5 BTU/h
Storage Temperature	-35°C to 70°C (-31°F to 158°F)
Humidity	10% to 90% non-condensing
Noise Level	31.56 dBA
Operating Altitude	Up to 2250 m (7400 ft)

[/specifications]

[accesories]

Included Accessories	External DC Power Adapter (1 adapter included)
Optional Accessories	Rack Mount Tray (SP-RACKTRAY-02) Wall Mount Kit (SP-FG60F-MOUNT-20) AC Power Adaptor (SP-FG80E-POE-PDC) 1 GE SFP RJ45 Transceiver Module (FN-TRAN-GC) 1 GE SFP SX Transceiver Module (FN-TRAN-SX) 1 GE SFP LX Transceiver Module (FN-TRAN-LX) 1GE SFP Transceiver, 90km Range (FR-TRAN-ZX)

[/accesories]

The FortiGate 81F-POE-BDL-809-60 is the ideal secure networking device for organizations looking to consolidate their branch office infrastructure without sacrificing performance or visibility. By integrating 8 Power over Ethernet (PoE/+) ports with a 96W budget, the device eliminates the need for a separate switch to power access points, IP phones, and cameras, reducing cabling and complexity. Furthermore, the included 128GB SSD supports local storage for logs, helping improve visibility and on-device reporting capability.

This Firewall operates on FortiOS, enabling unified networking and security and secure SD-WAN capabilities. Accelerated by the Fortinet Secure SD-WAN ASIC SP4, the FG-81F-POE delivers low latency and strong performance, including up to 1.4 Gbps of IPS throughput and 6.5 Gbps of IPsec VPN throughput to support a robust user experience and centralized protection. This bundle includes FortiCare Premium and FortiGuard Enterprise Protection for 5 years.

Secure Networking Power and Visibility with 96W PoE+ and 128GB SSD

Key Benefits

• Integrated Power Delivery: Features 8x GE PoE/+ ports with a 96W total power budget for powering edge devices directly.
• Enhanced Local Visibility: Includes a 128GB SSD for local log storage and on-device reporting storage.
• Bundle + Support Included: FortiCare Premium and FortiGuard Enterprise Protection coverage included for 5 years.
• ASIC-Accelerated Performance: Delivers high-speed security functions, including up to 10 / 10 / 7 Gbps firewall throughput and 1.4 Gbps IPS throughput, via the Fortinet Secure SD-WAN ASIC SP4.
• Converged Security Fabric: Acts as a cornerstone of the Fortinet Security Fabric, integrating control over connected FortiAPs (up to 96) and FortiSwitches (up to 24).
• Resilient Design: Supports optional dual DC power adapters for power redundancy and continuous network protection.
• Optimal Network Latency: Maintains low firewall latency of 3.23 μs (64 byte UDP) for critical applications.

Ideal Use Cases

• Branch Office Consolidation: Replaces separate firewalls and power delivery needs with a single, consolidated appliance.
• Retail and POS Locations: Securely power and manage edge devices, including cameras and point-of-sale systems, from one unit.
• Distributed Enterprises: Deployments requiring local retention of detailed security and traffic logs for compliance and forensics.
• Secure Remote Work Hubs: Centralized security and management for remote users connecting via 2,500 Client-to-Gateway IPsec VPN tunnels.

Technical Specifications Summary

• IPS Throughput: 1.4 Gbps
• NGFW Throughput: 1 Gbps
• Threat Protection Throughput: 900 Mbps
• IPv4 Firewall Throughput (1518 / 512 / 64 byte UDP): 10 / 10 / 7 Gbps
• Firewall Latency (64 byte UDP): 3.23 μs
• Concurrent Sessions (TCP): 1.5 Million
• New Sessions/Second (TCP): 45,000
• IPsec VPN Throughput (512 byte): 6.5 Gbps
• Client-to-Gateway IPsec VPN Tunnels: 2,500
• PoE Interfaces and Budget: 8x GE RJ45 PoE/+ ports (6 internal + 2 FortiLink), 96W total PoE budget (max 30W per PoE/+ port)
• Power and Thermals: +54V DC, 3A input; 98 W / 137 W power consumption (average / maximum); 467.5 BTU/h heat dissipation
• Physical and Environment: 60 x 216 x 178 mm; 1.4 kg; operating temperature 0°C to 40°C (32°F to 104°F)

Upgrade Your Network Security

Streamline your branch operations with the high-performance, consolidated FortiGate 81F-POE-BDL-809-60.
