[shortdesc] Firewall, desktop, 8x GE PoE/+ ports, 2x GE RJ45/SFP, 128GB SSD, including 3 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Model / SKU	FortiGate / FG-81F-POE-BDL-809-36
Bundle / Subscription	Firewall plus FortiCare Premium and FortiGuard Enterprise Protection (3-Year Contract)
Form Factor	Desktop / Wall Mount / Rack Tray
Internal Storage	1x 128 GB SSD
Total PoE Power Budget	96 W
Firewall Throughput (Max)	10 Gbps
Interfaces	8x GE RJ45 PoE/+ Ports (6 Internal + 2 FortiLink), 2x GE RJ45/SFP Shared Media Ports
Power Input	+54V DC, 3A
Dimensions (H x W x L)	60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
Weight	1.4 kg (3.1 lbs)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Compliance / Certifications	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance - Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance and Capacity
Firewall Throughput (1518/512/64 byte UDP)	10 / 10 / 7 Gbps
Firewall Latency (64 byte UDP)	3.23 μs
New Sessions/Second (TCP)	45,000
Concurrent Sessions (TCP)	1.5 Million
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
SSL-VPN Throughput	950 Mbps
Concurrent SSL-VPN Users (Tunnel Mode)	200
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	24
Hardware & Interfaces
GE RJ45 PoE/+ Ports (Total)	8 (6 Internal + 2 FortiLink)
GE RJ45/SFP Shared Media Pairs	2
USB Ports 3.0	1
Console Port (RJ45)	1
Environment & Power
Power Consumption (Average / Maximum)	98 W / 137 W
Heat Dissipation	467.5 BTU/h
Storage Temperature	-35°C to 70°C (-31°F to 158°F)
Humidity	10% to 90% non-condensing
Noise Level	31.56 dBA
Operating Altitude	Up to 2250 m (7400 ft)

[/specifications]

[accesories]

Included Accessories	External DC Power Adapter (1 adapter included)
Optional Accessories	Rack Mount Tray (SP-RACKTRAY-02) Wall Mount Kit (SP-FG60F-MOUNT-20) AC Power Adaptor (SP-FG80E-POE-PDC) 1 GE SFP RJ45 Transceiver Module (FN-TRAN-GC) 1 GE SFP SX Transceiver Module (FN-TRAN-SX) 1 GE SFP LX Transceiver Module (FN-TRAN-LX) 1GE SFP Transceiver, 90km Range (FR-TRAN-ZX)

[/accesories]

The FortiGate 81F-POE-BDL-809-36 is designed for distributed locations that need integrated firewall and SD-WAN capabilities in a compact desktop form factor. With 8 GE RJ45 PoE/+ ports and a 96W total PoE power budget, it can power compatible edge devices such as access points, IP phones, and cameras directly from the firewall. The unit also includes 128GB of onboard SSD storage.

This firewall runs on FortiOS and is accelerated by Fortinet’s proprietary SP4 ASIC to deliver high performance for security and connectivity use cases, including up to 1.4 Gbps IPS throughput and 6.5 Gbps IPsec VPN throughput. This bundle includes FortiCare Premium and FortiGuard Enterprise Protection for 3 years.

Secure Networking Power and Visibility with 96W PoE+ and 128GB SSD

Key Benefits

• Integrated Power Delivery: Features 8x GE PoE/+ ports with a 96W total power budget for powering edge devices directly.
• Onboard Storage: Includes a 128GB SSD for onboard storage.
• Bundle Included: FortiCare Premium and FortiGuard Enterprise Protection entitlement included for 3 years.
• ASIC-Accelerated Performance: Delivers up to 10 Gbps firewall and 1.4 Gbps IPS throughput via the purpose-built Fortinet SP4 ASIC.
• Converged Security Fabric: Acts as a cornerstone of the Fortinet Security Fabric, supporting up to 24 FortiSwitches and up to 96 FortiAPs (total) / 48 (tunnel).
• Power Redundancy Option: Supports optional dual external DC power adapters.
• Optimal Network Latency: Maintains firewall latency of 3.23 μs (64 byte UDP) for critical applications.

Ideal Use Cases

• Branch Sites: Integrated firewall and SD-WAN capabilities for distributed enterprise locations.
• Retail and POS Locations: Securely power and connect edge devices via PoE/+ while enforcing security policies at the branch edge.
• Distributed Enterprises: Compact desktop deployment with centralized management integration options across locations.
• Secure Remote Access: Supports SSL-VPN and IPsec VPN performance and capacity for remote connectivity.

Technical Specifications Summary

• IPS Throughput: 1.4 Gbps
• NGFW Throughput: 1 Gbps
• Threat Protection Throughput: 900 Mbps
• Firewall Throughput (IPv4, 1518/512/64 byte UDP): 10 / 10 / 7 Gbps
• IPsec VPN Throughput (512 byte): 6.5 Gbps
• SSL-VPN Throughput: 950 Mbps

• Concurrent SSL-VPN Users (Tunnel Mode): 200
• Concurrent Sessions (TCP): 1.5 Million

• New Sessions/Second (TCP): 45,000
• Interfaces: 6x GE RJ45 PoE/+ ports + 2x GE RJ45 PoE/+ FortiLink ports, 2x GE RJ45/SFP shared media pairs
• Total Available PoE Power Budget: 96 W (max 30 W per PoE/+ port)
• Internal Storage: 1x 128 GB SSD
• Power Consumption (Average / Maximum): 98 W / 137 W
• Dimensions (H x W x L): 60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)

Upgrade Your Network Security

Streamline your branch operations with the high-performance, consolidated FortiGate 81F-POE-BDL-809-36.
