[shortdesc] Desktop firewall, 8x GE PoE/+ ports, 2x GE RJ45/SFP WAN, 128GB SSD, SD-WAN, up to 10 Gbps firewall [/shortdesc]

[properties]

Model / SKU	FortiGate / FG-81F-POE
Form Factor	Desktop / Wall Mount / Rack Tray
Internal Storage	1x 128 GB SSD
Total PoE Power Budget	96 W
Firewall Throughput (Max)	10 Gbps
Interfaces	8x GE RJ45 PoE/+ Ports, 2x GE RJ45/SFP Shared Media Ports
Power Input	+54V DC, 3A
Dimensions (H x W x L)	60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)
Weight	1.4 kg (3.1 lbs)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Compliance / Certifications	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance - Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance and Capacity
Firewall Throughput (1518/512/64 byte UDP)	10 / 10 / 7 Gbps
Firewall Latency (64 byte UDP)	3.23 μs
New Sessions/Second (TCP)	45,000
Concurrent Sessions (TCP)	1.5 Million
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
SSL-VPN Throughput	950 Mbps
Concurrent SSL-VPN Users (Tunnel Mode)	200
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	24
Hardware & Interfaces
GE RJ45 PoE/+ Ports (Total)	8 (6 PoE/+ ports + 2 PoE/+ FortiLink ports, default)
GE RJ45/SFP Shared Media Pairs	2
USB Ports 3.0	1
Console Port (RJ45)	1
Environment & Power
Power Consumption (Average / Maximum)	98 W / 137 W
Heat Dissipation	467.5 BTU/h
Storage Temperature	-35°C to 70°C (-31°F to 158°F)
Humidity	10% to 90% non-condensing
Noise Level	31.56 dBA
Operating Altitude	Up to 2250 m (7400 ft)

[/specifications]

[accesories]

Included Accessories	External DC Power Adapter (1 adapter included)
Optional Accessories	Rack Mount Tray (SP-RACKTRAY-02) Wall Mount Kit (SP-FG60F-MOUNT-20) AC Power Adaptor (SP-FG80E-POE-PDC) 1 GE SFP RJ45 Transceiver Module (FN-TRAN-GC) 1 GE SFP SX Transceiver Module (FN-TRAN-SX) 1 GE SFP LX Transceiver Module (FN-TRAN-LX) 1GE SFP Transceiver, 90km Range (FR-TRAN-ZX)

[/accesories]

The FortiGate 81F-POE is the ideal secure networking device for organizations looking to consolidate branch office connectivity without sacrificing performance. By integrating 8 Power over Ethernet (PoE/+) ports with a 96W budget, the device can power access points, IP phones, and cameras directly, reducing cabling and complexity. The FG-81F-POE also includes 128GB onboard storage.

This firewall operates on FortiOS, the industry’s first converged networking and security operating system, enabling unified protection and secure SD-WAN capabilities. Accelerated by the patented SD-WAN-based ASIC SP4, the FG-81F-POE delivers fast application identification and ultra-low latency, achieving 1.4 Gbps of IPS throughput and 6.5 Gbps of IPsec VPN throughput to ensure a robust user experience and centralized protection.

Secure Networking Power with 96W PoE+ and 128GB SSD

Key Benefits

• Integrated Power Delivery: Features 8x GE PoE/+ ports with a 96W total power budget for powering edge devices directly.
• Integrated Storage: Includes 128GB onboard SSD storage.
• ASIC-Accelerated Performance: Delivers high-speed security functions, including up to 10 Gbps Firewall and 1.4 Gbps IPS throughput, via the purpose-built Fortinet SP4 ASIC.
• Converged Security Fabric: Acts as a cornerstone of the Fortinet Security Fabric, integrating control over connected FortiAPs (up to 96) and FortiSwitches (up to 24).
• Resilient Design: Supports optional dual DC power adapters for power redundancy and continuous network protection.
• Optimal Network Latency: Maintains ultra-low firewall latency of 3.23 μs (64 byte UDP) for critical applications.

Ideal Use Cases

• Branch Office Consolidation: Consolidates firewall security and PoE connectivity in a single desktop appliance.
• Retail and POS Locations: Securely power and manage edge devices, including cameras and point-of-sale systems, from one unit.
• Distributed Enterprises: Deployments requiring consistent firewall performance and integrated SD-WAN across branch locations.
• Secure Remote Work Hubs: Centralized security and management for remote users connecting via 2,500 Client-to-Gateway IPsec VPN Tunnels.

Technical Specifications Summary

• IPS Throughput: 1.4 Gbps
• NGFW Throughput: 1 Gbps
• Threat Protection Throughput: 900 Mbps
• Firewall Throughput (IPv4, 1518/512/64 byte UDP): 10 / 10 / 7 Gbps
• VPN Throughput: 6.5 Gbps (IPsec, 512 byte)
• SSL-VPN Throughput: 950 Mbps
• Concurrent Sessions (TCP): 1.5 Million
• Interfaces: 8x GE RJ45 PoE/+ Ports, 2x GE RJ45/SFP Shared Media Ports
• Total PoE Power Budget: 96 W (max 30 W per PoE/+ port)
• Power Consumption (Average / Maximum): 98 W / 137 W
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Dimensions (H x W x L): 60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches)

Upgrade Your Network Security

Streamline your branch operations with the high-performance, consolidated FortiGate 81F-POE.
