[shortdesc] Firewall, 10x GE RJ45, fanless desktop, SD-WAN, 10/10/6 Gbps throughput, including 5 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Feature	Details
Product SKU	FG-70F-BDL-809-60
Bundle Includes	FG-70F firewall appliance plus FortiCare Premium and FortiGuard Enterprise Protection (5 Year contract)
Form Factor	Desktop (Fanless)
Firewall Throughput	10 / 10 / 6 Gbps (1518 / 512 / 64 byte UDP packets)
Interfaces	10x GE RJ45 Ports (2x WAN, 1x DMZ, 2x FortiLink (default), 5x Internal), plus 1x USB and 1x RJ45 Console
Threat Protection	800 Mbps
Power Input	12VDC, 3A
Dimensions (H x W x L)	1.5 x 8.5 x 6.3 inches (38.5 x 216 x 160 mm)
Weight	2.23 lbs (1.01 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)

[/properties]

[specifications]

System Performance & Capacity
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Firewall Latency	2.54 μs
New Sessions/Second (TCP)	35,000
Firewall Policies	5,000
VPN Performance
IPsec VPN Throughput (512 byte)	6.1 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	500
SSL-VPN Throughput	405 Mbps
SSL Inspection Throughput	700 Mbps
Hardware & Environment
USB Port	1x USB
Console Port	1x RJ45
Power Consumption (Average / Max)	10.17 W / 12.43 W
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	Fanless 0 dBA
Compliance & Certifications	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB, USGv6/IPv6

[/specifications]

[accesories]

Accessory Type	Description
Optional	Rack Mount Tray (SP-RACKTRAY-02), AC Power Adaptor (SP-FG60E-PDC-5), Wall Mount Kit (SP-FG60F-MOUNT-20)

[/accesories]

The FortiGate 70F-BDL-809-60 bundle runs on FortiOS, the industry's first converged networking and security operating system, enabling businesses to gain benefits of operational efficiency and unified protection. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate NGFW works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time.

The 70F family is built on the patented SD-WAN-based ASIC, which delivers unmatched performance over traditional CPUs with lower cost and reduced power consumption. This application-specific design and embedded multi-core processor further accelerate the convergence of networking and security functions in the 70F family to optimize secure connections and deliver a robust user experience at branch locations.

Converged Next-Generation Firewall and SD-WAN

Key Benefits

• Unparalleled Performance: Enabled by Fortinet's patented ASIC and the FortiOS operating system to deliver industry-leading throughput and faster security inspections.
• Enterprise-Grade Protection: Includes FortiCare Premium and FortiGuard Enterprise Protection (5 Year contract) alongside FortiGuard AI-Powered Security Services to protect against malicious traffic, file-based threats, and web-based attacks.
• Simplified Operations: Centralized management for networking and security with automated workflows, deep analytics, and self-healing capabilities.
• Integrated SD-WAN: Delivers faster application identification to avoid delays in accessing applications and accelerates overlay performance regardless of location.
• Compact & Fanless: Small, lightweight desktop form factor suitable for noise-sensitive environments.

Ideal Use Cases

• Secure Branch: Extends security to WAN, LAN, and WLAN at branch offices for unified protection and reliable connectivity.
• Perimeter Protection: Inspects and controls incoming and outgoing traffic based on defined security policies to guard against defined and unknown threats.
• Secure SD-WAN: Enables best-of-breed WAN edge with integrated SD-WAN, WAN optimization, and security from a single OS.
• Universal ZTNA: Controls access to applications no matter where the user is and no matter where the application is hosted for universal application of access policies.

Technical Specifications Summary

• Firewall throughput: 10 / 10 / 6 Gbps (1518 / 512 / 64 byte UDP packets) and 9 Mpps (packets per second).
• Security performance: IPS 1.4 Gbps, NGFW 1 Gbps, Threat Protection 800 Mbps (Enterprise Traffic Mix).
• Interfaces: 10x GE RJ45 (2x WAN, 1x DMZ, 2x FortiLink default, 5x internal), plus 1x USB and 1x RJ45 console.
• Latency & session capacity: 2.54 μs latency, 1.5 M concurrent sessions (TCP), 35,000 new sessions/second (TCP).
• Policy capacity: Supports up to 5,000 firewall policies.
• IPsec VPN: 6.1 Gbps (512 byte), up to 200 gateway-to-gateway and 500 client-to-gateway IPsec VPN tunnels.
• SSL VPN: 405 Mbps SSL-VPN throughput with up to 200 concurrent SSL-VPN users (recommended maximum, tunnel mode).
• SSL inspection: 700 Mbps SSL inspection throughput (IPS, avg. HTTPS) with 500 SSL inspection CPS and 100,000 concurrent SSL inspection sessions.
• Power: 12VDC, 3A; 10.17 W average / 12.43 W maximum power consumption.
• Physical: 1.5 x 8.5 x 6.3 in (38.5 x 216 x 160 mm) and 2.23 lbs (1.01 kg).
• Environment: 0°C to 40°C operating, -35°C to 70°C storage, 10% to 90% non-condensing humidity; fanless 0 dBA.
• Compliance & certifications: FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB; USGv6/IPv6.

Upgrade Your Network Security

Deploy the FortiGate 70F-BDL-809-60 bundle today for a compact, high-performance security solution that unifies networking and protection with FortiCare Premium and FortiGuard Enterprise Protection.
